- Page 1 Crestron SRD-ANT-1LD-PAK Antenna System Installation Guide...
-
Page 2: Important Safety Instructions
This document was prepared and written by the Technical Documentation department at: Important Safety Instructions • Read and Retain Instructions – Read all Instructions before operating equipment and save for future reference. • Outdoor Antenna Grounding – The antenna and coaxial cable connecting to the unit should be properly grounded to provide protection against voltage surges and built-up static charges. -
Page 3: Table Of Contents
Crestron SRD-ANT-1LD-PAK Contents Antenna System: SRD-ANT-1LD-PAK Introduction...1 Block Diagram...1 Specifications...2 Included Items ...2 Industry Compliance...3 Installation ...4 Installation Notes ...4 Wall Mounting...4 Pole Mounting ...4 Hookup ...5 Aiming the Antenna...5 Problem Solving...7 Troubleshooting...7 Further Inquiries ...7 Future Updates...7 Appendix: Azimuth and Elevation Pointing Guide...8 Return and Warranty Policies ...11 Merchandise Returns / Repair Service...11 CRESTRON Limited Warranty...11... -
Page 5: Antenna System: Srd-Ant-1Ld-Pak
Crestron SRD-ANT-1LD-PAK Antenna System: SRD-ANT-1LD-PAK Introduction The SRD-ANT-1LD-PAK is a high quality outdoor antenna system designed for use with a single Crestron SRD-AMP-1 High Gain Line Amplifier allows the antenna to be positioned up to 350 feet (cable length) from the tuner, using standard RG-6 cable (not included). The antenna features a considerably narrower beam width compared to standard consumer antennas, achieving superior gain and multi-path rejection. -
Page 6: Specifications
Antenna System Specifications Following are specifications for the SRD-ANT-1LD-PAK. SRD-ANT-1LD-PAK Specifications Included Items The items included in the SRD-ANT-1LD-PAK are listed below and illustrated on the following page. SRD-ANT-1LD-PAK Included Items 2 • Antenna System: SRD-ANT-1LD-PAK Crestron SRD-ANT-1LD-PAK SPECIFICATION Antenna Bandwidth Gain Polarization... -
Page 7: Industry Compliance
Crestron SRD-ANT-1LD-PAK The items included with the SRD-AMP-1 are listed in the following table. SRD-AMP-1 Included Items SRD-ANT-1LD-PAK Included Items Industry Compliance As of the date of manufacture, the SRD-ANT-1LD-PAK has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. -
Page 8: Installation
Antenna System Installation Installation Notes Wall Mounting Attach the wall mount assembly to a flat surface. Use the supplied screws to secure the mount in the position desired (use of the included anchors requires 5/16” holes). Elevation and Azimuth Adjustments Pole Mounting Attach the antenna to any pole (not larger than two inches in diameter) using the U-bolt and bracket with supplied attaching hardware as shown in the figures on the... -
Page 9: Hookup
Crestron SRD-ANT-1LD-PAK 2” DirecTV Pole Hookup After the antenna is mounted, refer to the diagram on page 1, connect cables, attach the in-line amplifier(s), adjust the antenna position, and finalize the installation as follows: NOTE: For best results in all configurations, use quad-shielded RG-6 cable whenever possible. - Page 10 Antenna System Initially set up the antenna with its orientation approximately due south, at an up elevation angle of approximately 45º. Use this as the starting spot and peak the signal reception for maximum on one of the XM satellites using the antenna alignment menu in the radio.
-
Page 11: Problem Solving
Crestron SRD-ANT-1LD-PAK Problem Solving Troubleshooting The table after this paragraph provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. SRD-ANTPAK-1 Installation Troubleshooting Further Inquiries If you cannot locate specific information or have questions after reviewing this guide, please take advantage of Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. -
Page 12: Appendix: Azimuth And Elevation Pointing Guide
Antenna System Appendix: Azimuth and Elevation Pointing Guide The following chart shows the optimum azimuth bearing and elevation pointing angles for locations throughout the US (below) and Canada (starts on page 10). The azimuth has been magnetically corrected. NOTE: Although in many locations it may be possible to receive signals from terrestrial repeaters, it is not recommended to use these signals at fixed locations. - Page 13 Crestron SRD-ANT-1LD-PAK SIRIUS and XM Satellite Azimuth and Elevation Angle Settings - US (Continued) CITY AZIMUTH ELEVATION AZIMUTH° St Louis 319.7 Billings 76.2 Kalispell 80.8 Winston-Salem 308.2 Minot 106.5 North Platte 33.8 Omaha 349.9 Cherry Hill 297.6 Albuquerque 33.1 Shiprock 41.9 Elco 61.0...
- Page 14 Antenna System SIRIUS and XM Satellite Azimuth and Elevation Angle Settings - Canada CANADA CITY PR AZIMUTH° ELEVATION° AZIMUTH° ELEVATION° AZIMUTH° ELEVATION° Vancouver BC 78.4 Prince Rupert BC 81.4 Calgary AB 89.7 Edmonton AB 129.7 Saskatoon SK 109.0 Toronto ON 287.9 Ottawa ON 282.6 Montreal...
-
Page 15: Return And Warranty Policies
Crestron SRD-ANT-1LD-PAK Return and Warranty Policies Merchandise Returns / Repair Service 1. No merchandise may be returned for credit, exchange or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact an authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory and request an RMA (Return Merchandise Authorization) number. - Page 16 Crestron Electronics, Inc. Installation Guide – DOC. 6722A 15 Volvo Drive Rockleigh, NJ 07647 (2021853) Tel: 888.CRESTRON 08.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
