Page 1: Installation Guide
Installation Guide 1175R Refrigerator, ® 1175WC Wine Captain 1175BEV Beverage Center www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2006 U-Line Corporation 06/2006... -
Page 2: Table Of Contents
Contents Exterior Cleaning ......Cut-Out Dimensions ......Product Dimensions . -
Page 3: Inspect And Plan
1175R, 1175WC and 1175BEV Models 2 Inspect and Plan You have received a carton containing your 1175R Refrigerator, 1175WC Wine Captain Beverage Center with a package inside containing a Use and Care Guide and a Product Registration Card. Complete and mail the Product Registration Card or register online at www.U-LineService.com. -
Page 4: Exterior Cleaning
1175R, 1175WC and 1175BEV Models 3 Prepare Site Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for electrical connection in the rear. -
Page 5: Product Dimensions
Product Dimensions 23-7/16" 25-7/16" Including Including Handle Handle 34-1/8" 23-15/16" Black and White Refrigerator 1175 23-7/16" 25-7/16" Including Including Handle Handle 34-1/8" 23-15/16" Black Wine Captain 1175 Stainless Wine Captain 1175 25-7/16" Including Handle 23-15/16" 1175 Beverage Center Figure 2... -
Page 6: Reversing The Door
Reversing the Door (1175 Black & White Units Only) All units may be left- or right-hand opening (All Stainless Steel and 1175 Beverage Center units cannot be field- reversed). Black and White 1175 Units To reverse the door on Black or White 1175 models: 1. -
Page 7: Other Site Requirements
The unit requires a grounded and polarized 115 VAC, 60 Hz, 15A circuit (normal household current). See Electrical Specifications on Page 11. Environmental Requirements Many U-Line models are designed to operate in harsh outdoor/marine environments. Special considerations include the following: (1175 REFRIGERATOR requirements) •... -
Page 8: Custom 1/4'' Thick Door Panel Insert
Side-By-Side Installation Instructions For a complete refreshment center, install two of the following 1175 series units side by side: 1175R, 1175WC or a 1175 BEV Center. Note that each Side-By-Side Installation will be different. • Cut-out width for a side-by-side installation is the total of the widths listed under Cut-Out Dimensions in each unit’s Installation Guide. -
Page 9: Adding A Final Finish Coat To Wood Trim
Figure 13 Figure 12 2. Pull door gasket out of groove (top edge of door only). Start in the middle and pull outward, moving toward the edge (see Figure 13). This may take some force. 3. Remove two outside screws holding door handle. -
Page 10: Wood Trim Finishing
Wood Trim Finishing Interior components of your U-Line unit are equipped with a natural wood trim for appearance and durability. Although this wood trim has been coated with a clear sealer at the factory, it is recommended that the trim be stained (if desired), and receive a final finish coating prior to the unit going into full-time service. -
Page 11: Checking Door Alignment
5 Adjust Door Checking Door Alignment The unit’s door is aligned at the factory before shipment. However, its alignment could have been disturbed during shipment or during door panel installation. IMPORTANT Properly aligned, the door's gasket should be firmly in contact with the cabinet all the way around the door (no gaps). -
Page 12: Leveling Information
Make any necessary adjustments. The unit’s top surface should be approximately 1/8" below the countertop. Glass Shelf Installation (1175R Refrigerator and 1175BEV Beverage Centers ) 1. Carefully remove the glass shelves from the packaging. ULIN_0041_A 2. Slide the shelves onto lower sets of ribs, making sure the decorative graphics are on the underside of the shelves. -
Page 13: Initial Start-Up
See the Use and Care Guide’s Troubleshooting Guide for more solutions. For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in undercounter icemakers, Combo refrigerators, refrigerated drawers and refrigerator/freezers.
