hilscher CIFX 50-RE Training Manual

Universal real-time ethernet pc card ethernet/ip scanner configuration and testing - step by step
Hide thumbs Also See for CIFX 50-RE:
Table of Contents

Advertisement

Quick Links

Training Manual
EtherNet/IP Scanner
CIFX, COMX and netJACK - Configuration and Testing - Step by Step
Hilscher Gesellschaft für Systemautomation mbH
www.hilscher.com
DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIFX 50-RE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for hilscher CIFX 50-RE

Summary of Contents for hilscher CIFX 50-RE

  • Page 1 Training Manual EtherNet/IP Scanner CIFX, COMX and netJACK - Configuration and Testing - Step by Step Hilscher Gesellschaft für Systemautomation mbH www.hilscher.com DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public...

  • Page 2: Table Of Contents

    Required Hardware and Software ................3 List of Revisions......................3 GENERAL PROCEDURE ...................4 NETWORK SETUPS....................5 Setup 1: CIFX 50-RE with NXIO 50-RE..............5 Setup 2: CIFX 50-RE Added as Second Slave............5 STEP-BY-STEP CONFIGURATION ................6 Setup 1: CIFX 50-RE with NXIO 50-RE..............6 4.1.1 Set Up Network ....................6 4.1.2...

  • Page 3: Introduction

    Hardware • 1 x PC with standard equipment: monitor, keyboard, mouse, DVD drive, PCI slot • 1 x CIFX 50-RE acting as Real-Time Ethernet master (requires master license) • 1 x NXIO 50-RE Real-Time Ethernet slave with power supply unit •...

  • Page 4: General Procedure

    Network has not been Add slave to network (e. g. NXIO 50-RE). configured yet. If a full-scale Hilscher slave device is used (e. g. CIFX 50-RE), add also a Stand-Alone Slave. Open Configuration window for master device. Note: Hardware has been Select driver for access to the master device.

  • Page 5: Network Setups

    (flexible Real-Time Ethernet PCI card) Slave 1: NXIO 50-RE by Hilscher (simple Real-Time Ethernet test slave) Setup 2: CIFX 50-RE Added as Second Slave Setup 2 is a network consisting of a master and two slaves. Master: CIFX 50-RE\ML by Hilscher...

  • Page 6: Step-By-Step Configuration

    Step-By-Step Configuration 6/61 4 Step-By-Step Configuration Setup 1: CIFX 50-RE with NXIO 50-RE 4.1.1 Set Up Network 1. Create a new project in SYCON.net. In SYCON.net, choose File > New. 2. Insert Hilscher EtherNet/IP Scanner device in network. Select a CIFX RE/EIM from the Device Catalog (Master) and drag and drop it onto the upper line.
  • Page 7 Note: Skip the following step, because it does not need to be performed for Setup 1. 4. If a full-scale Hilscher EtherNet/IP Adapter device is used, place also the corresponding Stand-Alone Slave in the network. Select a CIFX RE/EIS from the Device Catalog (Gateway/Stand- Alone-Slave) and drag and drop it onto the EtherNet/IP network line.

  • Page 8: Assign Hardware And Load Firmware

    Right-click on the master device to open the context menu, then choose Configuration… EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 9 In the Navigation Area, choose Settings > Device Assignment and scan for available Hilscher devices. Click Scan button. Choose the CIFX 50-RE device by activating the check box EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public ©...
  • Page 10 Click Open button to load firmware into the PC card. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 11 Note: Click OK to finally confirm the assignment of the PC card and the download of the firmware. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 12: Configure Slave

    The IP address can either be set permanently by the user, or it can be received from a DHCP server. Note: The real IP addresses of Hilscher slaves are set via Stand-Alone Slave or by using the Ethernet Device Configuration tool.
  • Page 13 In the Navigation Area, choose Configuration > Electronic Keying, then select Keying Method or disable Keying. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 14 Only the quantity of the I/O data can be changed between 1 and 4 bytes. Keep the length at 4 bytes. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 15 Click Search Devices button to scan for connected Ethernet devices, then set IP addressing. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 16 In the context menu, choose Set IP Address… EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 17 Step-By-Step Configuration 17/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 18: Configure Hilscher Stand-Alone Slave

    Step-By-Step Configuration 18/61 4.1.4 Configure Hilscher Stand-Alone Slave Note: It is not necessary to configure a Hilscher Stand-Alone Slave for this example. 4.1.5 Configure Master 1. Open Configuration window for CIFX RE/EIM master. Right-click on the master device to open the context menu, then choose Configuration.
  • Page 19 (rotary switch at NXIO) or it can be set by using the Ethernet Device Configuration tool. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 20 In the Navigation Area, choose Configuration > Process Data to display the mapping of the input and output data. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 21 Under Configuration > Quick Connect Table, there are no settings to be made. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 22 6. Configure master settings. Under Configuration > Scanner Settings, use the default settings. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 23 The green highlighted display indicates an active connection to the master. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 24 Step-By-Step Configuration 24/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 25: Diagnosis And Testing

    Connect. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 26 Enter output data, then click Update button. The input data area displays the received input data. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 27 Diagnosis and testing with cifX Test 4. Start cifX Test auxiliary tool. In Windows, choose Start > Control Panel > cifX Test. 5. Establish connection to Hilscher device. In the menu, choose Device > Open. Select cifX > Channel0. Note: If you open the cifX level, you can see and use all functions concerning the PC card, e.
  • Page 28 Step-By-Step Configuration 28/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 29 With the output data, you can use cyclic and auto increment. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 30 Step-By-Step Configuration 30/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 31: Setup 2: Cifx 50-Re Added As Second Slave

    Step-By-Step Configuration 31/61 Setup 2: CIFX 50-RE Added as Second Slave The following steps describe – on the basis of Setup 1 – how to integrate a CIFX 50-RE as second slave into the setup. 4.2.1 Set Up Network 1. Add EtherNet/IP Adapter device to network.

  • Page 32: Configure Slave

    The IP address can either be set permanently by the user or can be received from a DHCP server. Note: The real IP addresses of Hilscher slaves are set via Stand-Alone Slave or by using the Ethernet Device Configuration tool.
  • Page 33 In the Navigation Area, choose Configuration > Electronic Keying, then select Keying Method or disable Keying. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 34 In the Navigation Area, choose Configuration > Connection, then configure connections and I/O data for CIFX RE/EIS. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 35 Step-By-Step Configuration 35/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 36: Configure Hilscher Stand-Alone Slave

    Step-By-Step Configuration 36/61 4.2.4 Configure Hilscher Stand-Alone Slave 1. Open Configuration window for CIFX RE/EIS slave. Right-click on the slave device to open the context menu and choose Configuration… 2. Select driver for accessing the slave device. In the Navigation Area, choose Settings > Driver and select the appropriate driver.
  • Page 37 In the Navigation Area, choose Settings > Device Assignment and scan for available Hilscher devices. Click Scan button. Choose the CIFX 50-RE by activating the check box EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public ©...
  • Page 38 Click Open button to load firmware into the hardware. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 39 In the Navigation Area, choose Configuration > Electronic Keying, then select Keying Method or disable Keying. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 40 Make sure that these match the slave I/O data of the network configuration. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 41 Step-By-Step Configuration 41/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 42 Right-click on the Stand-Alone Slave device to open the context menu, then choose Download. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 43 Step-By-Step Configuration 43/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 44: Configure Master

    4.2.5 Configure Master Note: The basic configuration of the CIFX RE/EIM and the NXIO 50-RE has already been carried out during configuration of Setup 1: CIFX 50-RE with NXIO 50-RE. 1. Open Configuration window for CIFX RE/EIM master. Right-click on the master device to open the context menu, then choose Configuration…...
  • Page 45 (rotary switch at NXIO) or it can be set by using the Ethernet Device Configuration tool. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 46 In the Navigation Area, choose Configuration > Process Data to display the mapping of the input and output data. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 47 Under Configuration > Quick Connect Table, there are no settings to be made. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 48 6. Configure master settings. Under Configuration > Scanner Settings, use the default-settings. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 49 The green highlighted display indicates an active connection to the master. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 50: Diagnosis And Testing

    Configuration state > Bus ON This indicates a functioning communication. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 51 Enter output data, then click Update button. The input data area displays the received input data. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 52 4. Start cifX Test auxiliary tool. In Windows, choose Start > Control Panel > cifX Test. 5. Open the Hilscher device to which you want to establish a connection. In the menu, choose Device > Open. Select cifX > Channel0.
  • Page 53 Step-By-Step Configuration 53/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 54 With the output data, you can try cyclic and auto increment. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 55 Step-By-Step Configuration 55/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 56: Tips And Tricks

    Disconnect. Note: Licenses can easily be reordered by simply exporting the filled-in form and handing it over to Hilscher, as if in an ordinary ordering process. Use the Export License Request… button for this. A license is delivered as a license file with the ending .nxl. It can be transferred to the device from the same dialog sheet by clicking the Download License button.

  • Page 57: Setting Ip Addresses Of Ethernet/Ip Devices

    Click Search Devices button to scan for connected Ethernet devices and set the IP addressing. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 58 Tips and Tricks 58/61 EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 59 In the context menu, choose Set IP Address… EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...
  • Page 60 Note: With the Signal option, PROFINET devices can be identified by a flashing light. EtherNet/IP Scanner | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121002TM02EN | Revision 2 | English | 2012-11 | Released | Public © Hilscher, 2012...

  • Page 61: Contacts

    +49 (0) 6190 9907-50 E-Mail: info@hilscher.com Support Phone: +49 (0) 6190 9907-99 E-Mail: de.support@hilscher.com Subsidiaries China Japan Hilscher Systemautomation (Shanghai) Co. Ltd. Hilscher Japan KK 200010 Shanghai Tokyo, 160-0022 Phone: +86 (0) 21-6355-5161 Phone: +81 (0) 3-5362-0521 E-Mail: info@hilscher.cn E-Mail: info@hilscher.jp...
