Page 1 PC Cards cifX Compact PCI (CIFX 80) Mini PCI (CIFX 90) Mini PCI Express (CIFX 90E) PCI-104 (CIFX 104C) Installation, Operation and Hardware Description Hilscher Gesellschaft für Systemautomation mbH www.hilscher.com DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public...
Page 2: Table Of Contents
PC Cards cifX with integrated Interfaces ..............43 3.2.1 PC Cards Compact PCI CIFX 80-XX ..............43 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 3 CIFX 90-RE\F, CIFX 90E-RE\F and Variants ............82 5.2.2 CIFX 90-FB\F, CIFX 90E-FB\F and Variants .............83 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 4 8.10 EtherNet/IP Adapter (Slave) ...................125 8.11 Open Modbus/TCP ....................127 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 5 Pin Assignment Cable Connector Fieldbus X3, X304, X4 .......159 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 6 CIFX 104C-DP, CIFX 104C-DP-R..............214 10.1.24 CIFX 104C-DP\F, CIFX 104C-DP-R\F .............216 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 7 CIFX 80-DP ......................261 11.3.4 Front Panel CIFX 80-DP ..................261 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 8 11.12 List of Tables ......................285 11.13 Glossary........................290 11.14 Contacts........................299 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 9: Introduction
Support > Downloads > Manuals or under Products directly with the information about your product. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 10: List Of Revisions
(beginning from -20°C). Table 1: List of Revisions PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 11: Notes On Hardware, Firmware, Software And Driver Versions
4, 9 CIFX 90E-DN\NHS\F 1291.518 CANopen (AIFX CO) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 12 1270.741 Table 2: Reference on Hardware PC Cards cifX PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 13 The technical specifications in this manual refer to the fully assembled PC cards cifX with the respective detached network interface. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 14 PC Cards cifX Compact PCI, Mini PCI, Mini PCI Express and PCI-104. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 15 USB Driver of Windows Table 6: Reference on Driver and Software PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 16: Conventions In This Manual
The labeling of safety messages is explained in the chapter Safety. 1.1.4 Used Terminology PC Card cifX Communication Interfaces of the cifX family of Hilscher based on the netX technology. CIFX 80-RE Example for the product name for a PC card cifX Real-Time Ethernet.
Page 17: Contents Of The Product Dvd
V2.3.11.0 or higher must be done, in order to use the network scan function. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 18 This feature was rarely used and has been removed for better performance. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 19 Table 7: PROFINET IO-Controller Firmware V2 and V3 on the Product DVD PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 20 2. Adjust the configuration of your PROFINET IO Controller device. Use the new GSDML file in the configuration software of the PROFINET IO Controller for this: GSDML-V2.33-HILSCHER-CIFX RE PNS-xxxxxxxx.xml. 3. Update the PROFINET IO Device firmware in your device to version 3.13.
Page 21 But this firmware version will be delivered furthermore. • Due to the software design, the EtherCAT Master firmware V3 has considerable performance limitations on Hilscher products. • Compared to the EtherCAT Master firmware V3, the EtherCAT Master firmware V4 has major improvements, while keeping the backward compatibility to the firmware V3 as much as possible.
Page 22 2. Adjust the configuration of your EtherCAT Master device. Use the new XML file in the configuration software of the EtherCAT Master for this: Hilscher CIFX RE ECS V4.6.X.xml. 3. Update the EtherCAT Slave firmware in your device to version 4.7.
Page 23 • POWERLINK Controlled Node V3 uses the object dictionary V3 component, to achieve a common base with other Hilscher stacks. • Applications, which used configuration database (inibatch.nxd) or configuration API of POWERLINK Controlled Node V2, can be easily migrated to V3 because these configuration mechanisms are supported also for V3.
Page 24 Table 11: POWERLINK Controlled Node Firmware V2 and V3 on the Product DVD PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 25: Device Description Files Cifx
For the EtherCAT Slave Firmware with V4.6 CIFX 90E-RE\NHS\F\M12 the Hilscher CIFX RE ECS V4.6.X.xml is provided. CIFX 90E-RE\ET\F Note! If the XML file Hilscher cifX RE ECS V2.2.x.xml is used/re-installed, the CIFX 90E-RE\ET\F\M12 firmware must be used/re-installed at the Version 2.5.x. CIFX 90E-RE\MR\F...
Page 26 Table 13: Device Description Files for PC Cards cifX Fieldbus PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 27: Legal Notes
Liability disclaimer The hardware and/or software was created and tested by Hilscher Gesellschaft für Systemautomation mbH with utmost care and is made available as is. No warranty can be assumed for the performance or...
Page 28 Warranty Hilscher Gesellschaft für Systemautomation mbH hereby guarantees that the software shall run without errors in accordance with the requirements listed in the specifications and that there were no defects on the date of acceptance.
Page 29 The customer hereby expressly acknowledges that this document contains trade secrets, information protected by copyright and other patent and ownership privileges as well as any related rights of Hilscher Gesellschaft für Systemautomation mbH. The customer agrees to treat as confidential all of the information made available to customer by Hilscher Gesellschaft für...
Page 30 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 31: Registered Trademarks
All other mentioned trademarks are property of their respective legal owners. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 32: Ethercat Disclaimer
SYCON.net configuration software or with the netX Configuration Tool. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 33: Safety
Table 14: PC Cards cifX and the Real-Time Ethernet or Fieldbus Systems realizable PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 34 Table 15: PC Cards cifX with AIFX detached Network Interface PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 35: Personnel Qualification
• Open the PC cabinet and install or remove the PC Card cifX only after disconnecting power. Reference Safety [S2] PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 36: Communication Stop During Firmware Update Or Configuration Download
In the device use only a configuration suitable for the system. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 37: Property Damage
61. There the required and permitted supply voltage is provided by device type inclusively the permitted tolerance range. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 38: Exceeding Permissible Signaling Voltage
• When not in use, store the equipment in appropriate static-safe packaging. Reference Safety [S3] PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 39: Power Disconnect While Downloading Firmware Or Configuration
Avoid exceeding the maximum number of allowed write/delete accesses by excessive writing. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 40: Invalid Firmware
Information and Data Security Take all usual measures for information and data security, in particular for PC Cards cifX with Ethernet technology. Hilscher explicitly points out that a device with access to a public network (Internet) must be installed behind a firewall or only be accessible via a secure connection such as an encrypted VPN connection.
Page 41: Labeling Of Safety Messages
EN 61340-5-1 and EN 61340-5-2 as well as IEC 61340-5-1 and IEC 61340-5-2 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 42: Descriptions And Requirements
Description The PC cards cifX are communication interfaces of the cifX product family of Hilscher on the basis of the communication controller netX 100 for the Real-Time Ethernet or fieldbus communication. Depending of the loaded firmware, the protocol specific PC card cifX proceeds the communication of the corresponding Real-Time Ethernet or fieldbus system.
Page 43: Pc Cards Cifx With Integrated Interfaces
Table 19: PC Cards PCI-104: CIFX 104C-XX and CIFX 104C-XX-R PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 44: Pc Cards Cifx With Detached Network Interface Aifx
For 2-channel devices both detached network interfaces must be connected. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 45: Pc Cards Mini Pci Cifx 90-Xx\F And Variant
CIFX 90-DN\F do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 46: Pc Cards Mini Pci Express Cifx 90E-Xx\F And Variant
RE\F, CIFX 90E-RE\F\M12, CIFX 90E-DP\F, CIFX 90E-CO\F and CIFX 90E-DN\F do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 47: Pc Cards Mini Pci Express Cifx 90E-Xx\Nhs\F And Variant
CO\NHS\F, CIFX 90E-DN\NHS\F and CIFX 90E-CC\NHS\F do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 48: Pc Cards Mini Pci Express Cifx 90E-Xx\Et\F And Variant
(2) The device height and the power input of the PC cards do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 49: Pc Cards Mini Pci Express Cifx 90E-Xx\Mr\F And Variant
(2) The device height and the power input of the PC cards do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 50: Pc Cards Mini Pci Express Cifx 90E-Xx\Mr\Et\F And Variant
(3) The device height and the power input of the PC cards do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 51: Pc Cards Mini Pci Express (2 Channels) Cifx 90E-2Xx\Et\F, Cifx 90E-2Xx\Xx\Et\F
(2) The device height and the power input of the PC cards do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 52: Pc Cards Mini Pci Express (2 Channels) Cifx 90E-2Xx\Mr\Et\F, Cifx 90E- 2Xx\Xx\Mr\Et\F
(3) The device height and the power input of the PC cards do not comply with the standard specifications. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 53: Pc Cards Pci-104: Cifx 104C-Xx\F, Cifx 104C-Xx-R\F And Variants
Table 28: PC Cards PCI-104: CIFX 104C-XX\F, CIFX 104C-XX-R\F, CIFX 104C-RE\F\M12, CIFX 104C-RE-R\F\M12 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 54: Detached Network Interfaces Aifx
Table 29: Detached Network Interfaces AIFX for PC Cards cifX with Cable Connector PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 55: The Function „Dma Mode
CIFX 90E-CO\MR\ET\F CIFX 104C-CO, CIFX 104C-CO-R, CIFX 104C-CO\F, CIFX 104C-CO-R\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 56 Table 32: Versions Driver and SYCON.net for the DMA Mode PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 57: Pc Cards Cifx With Additional Mram
2DP\DN\MR\ET\F, CIFX 90E-2CO\DN\MR\ET\F) also provide the MRAM module with 128Kbyte (= 64K words). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 58: System Requirements
Table 33: Slot for the PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, Mini PCIe (2 channel), PCI-104 X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX.
Page 59: Notes On The Card Height - Pc Card Cifx Mini Pci And Mini Pcie
2 Channel format: CIFX 90E-2XX\ET\F, CIFX 90E-2XX\XX\ET\F, CIFX 90E-2XX\MR\ET\F, CIFX 90E-2XX\XX\MR\ET\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 60: Panel Cutout For Installing Aifx
D-Sub male Connector, 9 pin CIFX 90-CO\F CIFX 90E-CO\F Standard cutout D-Sub-9 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 61: Operating Temperature Range For Ul Certificate
5 V or 3.3 V Compact CIFX 80-DP Max. 1 A CIFX 80-CO PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 62 90E- RE\NHS\F\M12, CIFX 90E-RE\ET\F\M12, CIFX 90E-RE\MR\F\M12, CIFX 90E- RE\MR\ET\F\M12 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 63 6] refer to section References PCI Specifications on page 166 of this manual. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 64: Aifx-Re\M12: Max. Permissible Current Per External Led
• For the operating systems Linux, Windows CE, VxWorks, QNX and IntervalZero RTX ™ you can buy Device Driver at the company Hilscher Gesellschaft für Systemautomation mbH http://www.hilscher.com/. 2. The configuration software SYCON.net or alternatively the simple Slave configuration tool netX Configuration Tool must be installed or another application program by which the PC card cifX (Slave) can be parameterized.
Page 65 Table 39: Requirements to operate PC Cards cifX properly PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 66: Prerequisites For Certification
You should keep the cable length for the sync signals below 50 mm and take into account EMC aspects. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 67: Getting Started
In the device use only a configuration suitable for the system. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 68 Only proceed with a firmware version valid for your device. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 69: Installation And Configuration Pc Card Cifx
Make sure, that the power supply is off at the PC or at the connecting device. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 70 Note! The RJ45 socket is only for use in LAN, not for telecommuni- cation circuits. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 71 - Download the configuration to the PC card Configuration cifX (Slave) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 72 OR Slave Diagnosis Diagnosis netX Configuration Tool (only Slave) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 73 Diagnosis of a PC Card cifX Compact PCI, Mini PCI, Mini PCI Express and PCI-104 (Master and Slave) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 74: Note On Exchange Service (Replacement Case)
Vendor ID, Product Code, Serial Number, Revision Number, Output and Input Data Bytes. If the XML file Hilscher cifX RE ECS V2.2.x.xml is use/updated, the firmware with the version 2.2.x must be use/updated. The loadable firmware supports for the number of cyclic input data and for cyclic output data in total up to 400 bytes.
Page 75: Device Names In Sycon.net
Gateway/ Stand-Alone Slave CIFX CO/COS CIFX 90E-CO\MR\ET\F, CIFX 90E-2CO\ET\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 76 Table 42: Device Names in SYCON.net by Communication Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 77: Update For Firmware, Driver And Software
Note the specific details for devices with DMA Mode in section The Function „DMA Mode“ on page 55. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 78: Device Drawings
Refer also to section Ethernet Interface, page 151. Figure 4: Front Plate CIFX 80-RE PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 79: Cifx 80-Dp
Refer also to chapter, PROFIBUS Interface page 154. PROFIBUS Figure 6: Front Plate CIFX 80-RE PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 80: Cifx 80-Co
Refer also to chapter CANopen Interface, page 154. CANopen Figure 8: Front Plate CIFX 80-CO PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 81: Cifx 80-Dn
155. DeviceNet Figure 10: Front Plate CIFX 80-DN PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 82: Pc Cards Cifx Mini Pci And Mini Pci Express
Mini PCI and Mini PCIe on page 59. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 83: Cifx 90-Fb\F, Cifx 90E-Fb\F And Variants
Notes on the Card Height - PC Card cifX Mini PCI and Mini PCIe on page PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 84: Cifx 90E-2Fb\Et\F And Cifx 90E-2Fb\Mr\Et\F
Figure 19: Reverse Side CIFX 90-XX\F Figure 20: Reverse Side CIFX 90E-XX\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 85: Pc Cards Cifx Pci-104
Mini-B USB Connector (5 Pin) on page 156. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 86: Cifx 104C-Re\F, Cifx 104C-Re-R\F
AIFX-DIAG can be used beginning with the hardware revision 5 of the PC card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 87: Cifx 104C-Dp, Cifx 104C-Dp-R
For further information on the Mini-B USB Connector refer to section Mini-B USB Connector (5 Pin) on page 156. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 88: Cifx 104C-Co, Cifx 104C-Co-R
For further information on the Mini-B USB Connector refer to section Mini-B USB Connector (5 Pin) on page 156. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 89: Cifx 104C-Dn, Cifx 104C-Dn-R
For further information on the Mini-B USB Connector refer to section Mini-B USB Connector (5 Pin) on page 156. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 90: Cifx 104C-Dp\F, Cifx 104C-Co\F, Cifx 104C-Dn\F, Cifx 104C-Cc\F
Figure 32: Basic Card CIFX 104C-FB-R\F for CIFX 104C-DP-R\F, CIFX 104C-CO-R\F, CIFX 104C-DN-R\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 91: Reverse Side Cifx 104C-Xx (All Basic Cards And Variants)
Figure 33: Reverse Side CIFX 104C-XX (all Basic Cards and Variants) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 92: Detached Network Interfaces Aifx
LED Descriptions beginning from page 115. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 93: Ethernet - Aifx-Re\M12
(for channel0 and channel1) of the AIFX-RE\M12 corresponds to the description in chapter LED Descriptions beginning from page 115. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 94: Profibus - Aifx-Dp
LED Descriptions beginning from page 115. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 95: Canopen - Aifx-Co
LED Descriptions beginning from page 115. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 96: Devicenet - Aifx-Dn
LED Descriptions beginning from page 115. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 97: Cc-Link - Aifx-Cc
LED Descriptions beginning from page 115. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 98: Diagnostic - Aifx-Diag
Figure 48: Front Side, LED Display and Reverse Side Diagnostic detached Network Interface (AIFX-DIAG) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 99: Hardware Installation And Uninstalling
Warnings on page 67 and check any notes in the overview given Getting Started on page 67. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 100: Fix Front Plate Sticker At Cifx 80-Re
Table 43: LED Labeling depending of the loaded Firmware PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 101: Installing Pc Cards Cifx Compact Pci
Plug the connecting cable from the PC card cifX to the PC card Master or Slave. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 102: Uninstalling Pc Cards Cifx Compact Pci
Close the cabinet of the PC or connecting device. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 103: Installing Pc Cards Cifx Mini Pci And Mini Pci Express
25° angle without tilting it. Figure 50: Insertion angle approx. 25° (example) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 104 = CC); or CIFX 90E-RE\F\M12, CIFX 90E-RE\NHS\F\M12, CIFX 90E- RE\ET\F\M12, CIFX 90E-RE\MR\F\M12, CIFX 90E-RE\MR\ET\F\M12 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 105 Figure 54: Connecting the CANopen detached Network Interface (AIFX-CO) to the basic Card CIFX 90E (Example) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 106 For the PC cards CIFX 90-RE\F or CIFX 90E-RE\F (all variants with RJ45 connectors) note: PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 107: Uninstalling Pc Cards Cifx Mini Pci, Mini Pci Express
Mini PCI Express; cable connector Ethernet X4 or cable connector fieldbus X3. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 108 CIFX 90E, CIFX 90E\NHS, CIFX 90E\ET, CIFX 90E\MR, CIFX 90E\MR\ET PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 109: Installing Pc Cards Cifx Pci-104 (Pci-104-Modules)
Plug the PC card cifX into a free PCI-104 slot (or if so, to the underlying PCI-104 module). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 110 CIFX 104C-FB\F or CIFX 104C-FB-R\F Fieldbus with the cable. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 111 For further information refer to section Ethernet Interface on page 151. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 112: Uninstalling Pc Cards Cifx Pci-104
Ethernet X4 (or X304) or cable connector fieldbus X4 (or X304) and cable connector DIAG X3 (or X303). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 113 Close the cabinet of the PC or connecting device. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 114: Troubleshooting
Real-Time Ethernet or fieldbus system. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 115: Led Descriptions
Bus Failure Status / Error Table 46: LED Names PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 116: Overview Leds Fieldbus Systems
Status Run / Status Error Table 49: LED Names PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 117: System Led
Power supply for the device is missing. (off) Table 51: Power On LED States PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 118: Cc-Link Ie Field Basic Slave
Table 53: LED state definitions for theCC-Link IE Field Basic Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 119: Ethercat Master V3
Table 55: LED state definitions for the EtherCAT Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 120: Ethercat Master V4
(200 ms). The sequence is finished by a long off phase (1,000 ms). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 121 Table 57: LED state definitions for the EtherCAT Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 122: Ethercat Slave
Table 59: LED state definitions for the EtherCAT Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 123: Ethernet/Ip Scanner (Master)
Not powered, no IP address: The device does not have an IP address (or is (Off) powered off). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 124 Table 61: LED state definitions for the EtherNet/IP Scanner protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 125: Ethernet/Ip Adapter (Slave)
Not powered, no IP address: The device does not have an IP address (or (Off) is powered off). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 126 Table 63: LED state definitions for the EtherNet/IP Adapter protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 127: Open Modbus/Tcp
Table 65: LED state definitions for the OpenModbusTCP protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 128: Powerlink Controlled Node/Slave V2, V3
Table 67: LED state definitions for the POWERLINK Controlled Node protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 129: Profinet Io-Controller V2
Table 69: LED state definitions for the PROFINET IO-Controller protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 130: Profinet Io Controller V3
Table 70: PROFINET IO Controller, SYS, COM0 and COM1 LEDs states PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 131 Ethernet activity. Table 72: PROFINET IO Controller, LEDs states definitions PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 132: Profinet Io-Device
Table 74: LED state definitions for the PROFINET IO-Device protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 133: Sercos Master
Table 75: LED states for the Sercos Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 134 Table 76: LED state definitions for the Sercos Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 135: Sercos Slave
Table 77: LED state definitions for the Sercos Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 136 Table 78: LED state definitions for the Sercos Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 137: Varan Client (Slave)
Ethernet activity. Table 80: Definitionen der LED-Zustände für das VARAN-Client-Protokoll PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 138: Profibus Dp Master
Table 82: LED state definitions for the PROFIBUS DP Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 139: Communication Status Leds
Table 84: LED state definitions for the PROFIBUS DP Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 140: Profibus Dp Slave
Table 86: LED state definitions for the PROFIBUS DP Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 141: Communication Status Leds
Table 88: LED state definitions for the PROFIBUS DP Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 142: Profibus Mpi Device
Table 90: LED state definitions for the PROFIBUS MPI protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 143: Communication Status Leds
Table 92: LED state definitions for the PROFIBUS MPI protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 144: Canopen Master
Table 94: LED state definitions for the CANopen Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 145: Communication Status Leds
Table 96: LED state definitions for the CANopen Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 146: Canopen Slave
Table 98: LED state definitions for the CANopen Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 147: Communication Status Leds
Table 100: LED state definitions for the CANopen Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 148: Devicenet Master
Table 102: LED state definitions for the DeviceNet Master protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 149: Devicenet Slave
Table 104: LED state definitions for the DeviceNet Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 150: Cc-Link Slave
Table 105: LED states for the CC-Link Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 151: Device Connections And Switches
For the Open Modbus/TCP firmware with V2.3.4.0 and higher both RJ45 RJ45 channels can be used. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 152: Ethernet Pin Assignment At The M12 Socket
For the Open Modbus/TCP firmware with V2.3.4.0 and higher both M12 channels can be used. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 153: Ethernet Connection Data
*Instead of hubs and switches VARAN uses splitter. [3] PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 154: Profibus Interface
1, 4, 5, 6, 8, 9 Do not connect! Table 111: CANopen Interface, X400 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 155: Devicenet Interface
Data Ground Shield Field Ground Table 113: CC-Link Interface PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 156: Mini-B Usb Connector (5 Pin)
Table 115: Rotary Switch for PCI-104 Slot Number, S1 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 157: Rotary Switch Device Address
The Slave address setting is done via the configuration software. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 158: Cable Connector
RE\ET\F\M12, CIFX 90E-RE\MR\F, CIFX 90E-RE\MR\F\M12 bzw. CIFX 90E-RE\MR\ET\F, CIFX 90E-RE\MR\ET\F\M12 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 159: Pin Assignment Cable Connector Fieldbus X3, X304, X4
Table 118: Pin Assignment for Cable Connector Fieldbus X3 and X4 for 2 Channel Devices PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 160: Pin Assignment Cable Connector Diag
Table 119: Pin Assignment for Cable connector DIAG X3 or X303 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 161: Pin Assignment Cable Connector X2, Aifx-Re\M12
Figure 70: Cable Connector Ethernet X2; 1x20 Pins, AIFX-RE\M12 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 162: Pin Assignment Cable Connector Led Signals X3, Aifx-Re\M12
5 mA. If this maximum current is not sufficient, an external driver is required previous to the LED. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 163: Cable For Detached Network Interfaces Aifx
15cm version. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 164: Sync Connector (Pin-Assignment, Hardware/Firmware)
Table 125: Meaning of the SYNC Signals for each Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 165: Pin Assignment At The Pci Bus
CIFX 104C-DP CIFX 104C-DP-R CIFX 104C-DP\F CIFX 104C-DP-R\F CIFX 104C-CO PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 166: References Pci Specifications
GROUND AD[30] AD[27] 3.3V AD[25] AD[28] (not used) AD[26] PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 167 Mini PCI Connector III [bus spec 4, page 14] (refer to section References PCI Specifications on page 166). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 168: Pin Assignment For Mini Pci Express Bus / Sync Connector (Bootstart)
PC card cifX. The names in the bus specification are defined from the perspective of the host. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 169 RE\F\M12, CIFX 90E-RE\NHS\F\M12, CIFX 90E-RE\ET\F\M12, CIFX 90E- RE\MR\F\M12, CIFX 90E-RE\MR\ET\F\M12 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 170: Pin Assignment For Mini Pci Express Bus, X1/X2 For 2 Channel Devices
Mini PCI Express. The Pins 44 and 46 are ‘not used’. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 171 LED status (Pin 42 „WWAN#“, Pin 44 „WLAN#“, Pin 46 „WPAN#“). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 172: Technical Data
0 can be used, channel 1 is deactivated. Beginning with the EtherCAT Master firmware version 3 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 173 Configuration Tool Table 131: Technical Data CIFX 80-RE PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 174: Cifx 80-Dp
Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104, page 58. RoHS CE Sign CE Sign PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 175: Cifx 80-Co
LED Display System Status LED CANopen Status (duo LED) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 176 Configuration Tool Table 133: Technical Data CIFX 80-CO PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 177: Cifx 80-Dn
EN 55011:2009 + A1:2010, CISPR 11:2009, Class A (Radio disturbance characteristics - Limits and methods of PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 178: Cifx 90-Re\F, Cifx 90-Re\F\M12
EtherNet/IP Adapter (Slave), Open Modbus/TCP POWERLINK Controlled Node/Slave PROFINET IO-Controller (Master), PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 179 EN 61000-4-4:2004 + A1:2010 (Burst Electrical fast transients/burst test) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 180: Cifx 90-Dp\F
For LEDs at AIFX-DP, refer to section AIFX-DP page 229. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 181: Cifx 90-Co\F
Communication interface with Mini PCI-Socket and CANopen interface Communication Type netX 100 processor Controller PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 182 EN 61000-4-8:2010 (power frequency magnetic field test) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 183: Cifx 90-Dn\F
-20 °C ... +70 °C (acc. to UL: 0 °C ... +70 °C) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 184: Cifx 90-Cc\F
Overview, page 165 and Pin Assignment for Mini PCI Bus, X1, page 166. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 185 SYCON.net or netX Configuration Tool Table 139: Technical Data CIFX 90-CC\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 186: Cifx 90E-Re\F And Variants
(determined by the loaded EtherNet/IP Scanner (Master), firmware) EtherNet/IP Adapter (Slave), PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 187 CIFX 90E-RE\F\M12 CIFX 90E-RE\MR\ET\F, CIFX 90E-RE\MR\F\M12 CIFX 90E-RE\NHS\F\M12, CIFX 90E-RE\ET\F\M12, PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 188: Cifx 90E-Dp\F And Variants
CIFX 90E-DP\MR\ET\F 1291.416 X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 189 μs. Current consumption at 3.3 V 600 mA (maximum) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 190 Configuration Software Slave netX Configuration Tool X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 191: Cifx 90E-Co\F And Variants
Cable Connector Fieldbus X3 (JST 10FMN-BMT-A-TF(LF)(SN), Pitch 1,0 mm) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 192 EN 61000-4-8:2010 (power frequency magnetic field test) EN 61000-6-2:2005 + B1:2011 (for industrial X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 193: Cifx 90E-Dn\F And Variants
DeviceNet interface Transmission Rate 125 kBit/s, 250 kBit/s, 500 kBit/s PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 194 EN 61000-4-3:2006 + A1:2008 + A2:2010 (Radiated, radio-frequency, electromagnetic field test) X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 195: Cifx 90E-Cc\Nhs\F,Cifx 90E-Cc\Et\F, Cifx 90E-Cc\Mr\Et\F
Width for the data access to the 32-Bit Dual-Port Memory (DPM) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 196 EN 61000-4-6:2009 (to conducted disturbances, induced by radio- frequency fields) X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 197 Table 144: Technical Data CIFX 90E-CC\NHS\F, CIFX 90E-CC\ET\F, CIFX 90E- CC\MR\ET\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 198: Cifx 90E-2Dp\Et\F, Cifx 90E-2Dp\Mr\Et\F
Via Mini PCI Express Bus Environmental CIFX 90E-2DP\ET\F, CIFX 90E-2DP\MR\ET\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 199: Cifx 90E-2Dp\Co\Et\F, Cifx 90E-2Dp\Co\Mr\Et\F
PCI Express CIFX 90E-2DP\CO\ET\FF and CIFX 90E- 2DP\CO\MR\ET\F do not comply with the standard specifications. X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 200 0V to 3.3V must last longer than 180 μs. Current consumption at 3.3 V 800 mA (maximum) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 201: Cifx 90E-2Dp\Dn\Et\F, Cifx 90E-2Dp\Dn\Mr\Et\F
‚ET’) composed of: - Basic card CIFX 90E-2FB\ET or CIFX 90E-2FB\MR\ET X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 202 For the LEDs at AIFX-DP at channel X1, refer to section AIFX-DP page 229. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 203: Cifx 90E-2Co\Et\F, Cifx 90E-2Co\Mr\Et\F
CIFX 90E-2CO\MR\ET\F 1293.506 X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 204 Humidity 10 … 95% relative humidity, no condensation permitted PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 205: Cifx 90E-2Co\Dn\Et\F, Cifx 90E-2Co\Dn\Mr\Et\F
Integrated Memory 8 MB SDRAM X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 206 Conditions Operating temperature range* -20 °C ... +70 °C PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 207: Cifx 90E-2Dn\Et\F, Cifx 90E-2Dn\Mr\Et\F
100 processor Controller X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 208 Compact PCI, Mini PCI, Mini PCIe, PCI-104, page 58. RoHS X1, X2 corresponds to the Hilscher convention for „interface“ on the top or the bottom side of the PC Card cifX. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public ©...
Page 209 Configuration Tool Table 150: Technical Data CIFX 90E-2DN\ET\F, CIFX 90E-2DN\MR\ET\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 210: Cifx 104C-Re, Cifx 104C-Re-R
Mini B USB Plug (5 pin), refer to section Mini-B USB Connector (5 Pin), page 156. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 211 UL 508 Configuration Configuration Software SYCON.net Master and Slave PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 212: Cifx 104C-Re\F, Cifx 104C-Re-R\F And Variants
Half duplex/Full duplex depending on loaded firmware, supported (at 100 MBit/s) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 213 (Radio disturbance characteristics - Limits and methods of measurement) Immunity EN 61000-4-2:2009 (Electrostatic discharge test) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 214: Cifx 104C-Dp, Cifx 104C-Dp-R
1000 VDC (tested for 1 minute) Connector DSub female Connector, 9 pin PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 215 Configuration Tool Table 153: Technical Data CIFX 104C-DP, CIFX 104C-DP-R PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 216: Cifx 104C-Dp\F, Cifx 104C-Dp-R\F
(acc. to UL: 0 °C ... +55 °C) Conditions *Air flow during measurment 0,5 m/s PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 217: Cifx 104C-Co, Cifx 104C-Co-R
DPM or DMA (Direct Memory Access) Width for the data access to the 32-Bit PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 218 EN 61000-4-6:2009 (to conducted disturbances, induced by radio- frequency fields) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 219 Configuration Tool Table 155: Technical Data CIFX 104C-CO, CIFX 104C-CO-R PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 220: Cifx 104C-Co\F, Cifx 104C-Co-R\F
(acc. to UL: 0 °C ... +55 °C) Conditions *Air flow during measurment 0,5 m/s PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 221: Cifx 104C-Dn, Cifx 104C-Dn-R
33 MHz Data Access DPM or DMA (Direct Memory Access) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 222 EN 61000-4-6:2009 (to conducted disturbances, induced by radio- frequency fields) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 223: Cifx 104C-Dn\F, Cifx 104C-Dn-R\F
Cable Connector DIAG X303 (X3) (JST 12FMN-SMT-A-TF(LF)(SN), Pitch 1,0 mm) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 224 Configuration Tool Table 158: Technical Data CIFX104C-DN\F, CIFX 104C-DN-R\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 225: Cifx 104C-Cc\F
Humidity 10 … 95% relative humidity, no condensation permitted PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 226 SYCON.net or netX Configuration Tool Table 159: Technical Data CIFX104C-CC\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 227: Aifx-Re
UL 508 Table 160: Technical Data AIFX-RE PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 228: Aifx-Re\M12
Tested together with the corresponding basic cards cifX. Table 161: Technical Data AIFX-RE\M12 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 229: Aifx-Dp
UL 508 Table 162: Technical Data AIFX-DP PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 230: Aifx-Co
UL 508 Table 163: Technical Data AIFX-CO PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 231: Aifx-Dn
UL 508 Table 164: Technical Data AIFX-DN PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 232: Aifx-Cc
UL-File-Nr. E221530 to UL 508 Table 165: Technical Data AIFX-CC PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 233: Aifx-Diag
UL 508 Table 166: Technical Data AIFX-DIAG PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 234: Pci Ids Pc Cards Cifx On The Pci Bus
Table 167: PCI IDs PC Cards cifX on the PCI Bus 10.3 Supported PCI Bus Commands From the following table you can see which PCI bus commands are supported by the Hilscher PC Cards cifX Compact PCI, Mini PCI, Mini PCI Express and PCI-104. C/BE3#...
Page 235: Technical Data Of The Communication Protocols
Table 169: Technical data CC-Link IE Field Basic Slave protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 236: Ethercat Master (V3)
Reference to firmware/stack version V3.0 Table 170: Technical Data EtherCAT Master Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 237: Ethercat Master (V4)
Reference to firmware / stack version V4.4 Table 171: Technical Data EtherCAT Master Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 238: Ethercat Slave
512 bytes, where each length has to be rounded up to the next multiple of 4 for this calculation. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 239: Ethernet/Ip Scanner (Master)
Reference to firmware/stack version V2.10 Table 173: Technical Data EtherNet/IP Scanner Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 240: Ethernet/Ip Adapter (Slave)
Reference to firmware/stack version V2.13 Table 174: Technical Data EtherNet/IP Adapter Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 241: Open Modbus/Tcp
Reference to firmware/stack version V2.6 Table 175: Technical Data Open Modbus/TCP Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 242: Powerlink Controlled Node/Slave (V2)
V3.4 Table 177: Technical Data POWERLINK Controlled Node Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 243: Profinet Io-Controller (V2)
The size of the bus configuration file is limited by the size of the RAM Disk (1 MByte) WriteMultiple-Record service is not supported PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 244: Profinet Io-Controller (V3)
Implemented according to V2.3 ED2 MU3 Legacy Startup supported according to PROFINET specification V2.2 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 245: Profinet Io-Device (V3.4)
Multicast communication not supported Only one device instance is supported PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 246: Profinet Io-Device (V3.13)
V2.2 (legacy startup) and V2.3 Limitations RT over UDP not supported. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 247: Sercos Master
Reference to firmware/stack version V2.1 Table 182: Technical Data Sercos Master Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 248: Sercos Slave
Reference to firmware/stack version V3.5 Table 183: Technical Data Sercos Slave Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 249: Varan Client (Slave)
Reference to firmware/stack version V1.1 Table 184: Technical Data VARAN Client Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 250: Profibus Dp Master
V2.8 Table 185: Technical Data PROFIBUS DP Master Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 251: Profibus Dp Slave
V2.10 Table 186: Technical Data PROFIBUS DP Slave Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 252: Profibus Mpi
Reference to firmware/stack version Table 187: Technical Data PROFIBUS-MPI Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 253: Canopen Master
Reference to version V2.14 Table 188: Technical Data CANopen Master Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 254: Canopen Slave
Reference to firmware/stack version V3.7 Table 189: Technical Data CANopen Slave Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 255: Devicenet Master
Reference to firmware/stack version V2.4 Table 190: Technical Data DeviceNet Master Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 256: Devicenet Slave
Reference to firmware/stack version V2.5 Table 191: Technical Data DeviceNet Slave Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 257: Cc Link Slave
Reference to firmware/stack version V2.12 Table 192: Technical Data CC-Link-Slave-Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 258: Annex
Security code: X Figure 73: Example Barcode Label (EAN 39) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 259: Tolerances Of The Shown Card Dimensions
Cards cifX on page 172 (and also the identical values in the data sheet cifX and on the ‘Hilscher Site’) are rounded and unified for the respective types of card. The depth of the PC cards Compact PCI (CIFX 80) has been equated to the rounded width of the front panel.
Page 260: Dimensioning Pc Cards Cifx Compact Pci
14.0 Figure 75: Dimensions Front Panel for CIFX 80-RE PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 261: Cifx 80-Dp
PROFIBUS 10.5 Figure 77: Front Panel for CIFX 80-DP PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 262: Cifx 80-Co
10.5 Figure 79: Dimensions Front Panel for CIFX 80-CO PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 263: Cifx 80-Dn
DeviceNet 4.00 Figure 81: Dimensions Front Panel CIFX 80-DN PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 264: Dimensioning Pc Cards Cifx Mini Pci And Mini Pci Express
Reverse Side CIFX 90-XX\F, CIFX 90E-XX\F and Variants on page 84. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 265: Dimensioning Pc Cards Cifx Pci-104
14.51 60.30 81.28 90.17 Figure 84: Dimensions CIFX 104C-RE PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 266: Cifx 104C-Re\F
14.51 60.30 81.28 90.17 Figure 85: Dimensions CIFX 104C-RE\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 267: Cifx 104C-Dp
14.51 60.30 81.28 90.17 Figure 86: Dimensions CIFX 104C-DP PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 268: Cifx 104C-Co
14.51 60.30 81.28 90.17 Figure 87: Dimensions CIFX 104C-CO PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 269: Cifx 104C-Dn
14.51 60.30 81.28 90.17 Figure 88: Dimensions CIFX 104C-DN PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 270: Cifx 104C-Fb\F
14.51 60.30 81.28 90.17 Figure 89: Dimensions CIFX 104C-FB\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 271: Reverse Side Cifx 104C-Xx (All Basic Cards And Variants)
Figure 90: Reverse Side CIFX 104C-XX (all Basic Cards and Variants) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 272: Dimensioning Detached Network Interfaces Aifx
30.7 Figure 91: Dimensioning Ethernet detached Network Interface (AIFX-RE) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 273: Ethernet M12 - Aifx-Re\M12
Figure 93: Drawing Panel Cutout Detached Network Interface Ethernet (AIFX-RE\M12) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 274: Profibus - Aifx-Dp
23.4 Figure 94: Dimensioning PROFIBUS detached Network Interface (AIFX-DP) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 275: Canopen - Aifx-Co
26.7 Figure 96: Dimensioning DeviceNet detached Network Interface (AIFX-DN) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 276: Cc-Link - Aifx-Cc
23.2 Figure 98: Dimensioning Diagnostic detached Network Interface (AIFX-DIAG) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 277: Notes On Earlier Hardeware Revisions
“Summary of 10BT problem on EthernetPHY”, RenesasElectronics Europe, April 27, 2010 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 278: Pin Assignment For Mini Pci Express Bus / Sync Connector (Bootstart)
Express refer to section References PCI Specifications on page 166 of this manual. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 279 LED status (Pin 42 „WWAN#“, Pin 44 „WLAN#“, Pin 46 „WPAN#“). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 280: Disposal Of Waste Electronic Equipment
References Protocol API Manuals • CANopen Master Protocol API Manual, Revision 16, Hilscher GmbH 2016 • CANopen Slave Protocol API Manual (V3), Revision 7, Hilscher GmbH 2016 • DeviceNet Master Protocol API Manual, Revision 11, Hilscher GmbH 2016 • DeviceNet Slave Protocol API Manual, Revision 15, Hilscher GmbH 2016 •...
Page 281: Ethercat Summary Over Vendor Id, Conformance Test, Membership And Network Logo
(e.g. PCI Interface card products) only as part of a machine or machine line or as spare part for such a machine. In case of questions, contact Hilscher and/or your nearest ETG representative. The ETG Vendor-ID policies apply.
Page 282: Membership And Network Logo
Vendor ID Policy accepted by ETG Board of Directors, November 5, 2008 PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 283: List Of Figures
Figure 46: Front Side and LED Display CC-Link detached Network Interface (AIFX-CC) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 284 Figure 90: Reverse Side CIFX 104C-XX (all Basic Cards and Variants) Figure 91: Dimensioning Ethernet detached Network Interface (AIFX-RE) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 285: List Of Tables
Table 39: Requirements to operate PC Cards cifX properly PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 286 Table 87: LED states for the PROFIBUS DP Slave protocol – 2 Communication Status LEDs (AIFX-DP connected or prior Hardware Revision) PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 287 Table 135: Technical Data CIFX 90-RE\F, CIFX 90-RE\F\M12 Table 136: Technical Data CIFX 90-DP\F PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 288 Table 184: Technical Data VARAN Client Protocol Table 185: Technical Data PROFIBUS DP Master Protocol PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 289 Table 194: Assignment of the Pin 24 for HW-Rev. 6,7,8 + B or 1 to 5 and A Table 195: References Protocol API Manuals PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 290: Glossary
Station in the CC-Link IE Field Basic network communicating with a master station PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 291 Modbus (read with FC 2). PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 292 Fieldbus Data Link defines the PROFIBUS communication on layer 2, identical for DP and FMS PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 293 A hub can be used for setting up a star topology. Industrial Ethernet See Real-Time Ethernet PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 294 Type of device that initiates and controls the communication on the bus PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 295 PROFIBUS and based on RS-485. It usually works with a transmission rate of 187.5 kBaud. netX networX on chip, Hilscher network communication controllers netX Configuration Tool The netX Configuration Tool allows users to operate cifX or netX based devices in different networks.
Page 296 Annex 296/299 PC Card cifX Communication Interfaces of the cifX product family of Hilscher on the basis of the communication controller netX 100: for the Real-Time Ethernet systems and for the fieldbus systems CC-Link IE Field-Basic PROFIBUS DP PROFIBUS MPI...
Page 297 For the connected communication partners a switch behaves transparently. PC Cards cifX Compact PCI, Mini PCI, Mini PCIe, PCI-104 | Installation, Operation and Hardware Description DOC120205UM53EN | Revision 53 | English | 2019-03 | Released | Public © Hilscher, 2008-2019...
Page 298 X1, X2 correspond for PC cards cifX Mini PCI Express to the Hilscher convention for „interface“ on the top or the bottom side X3, X4 (names on the circuit board) ...
Page 299: Contacts
+49 (0) 6190 9907-50 E-Mail: info@hilscher.com Support Phone: +49 (0) 6190 9907-99 E-Mail: de.support@hilscher.com Subsidiaries China Japan Hilscher Systemautomation (Shanghai) Co. Ltd. Hilscher Japan KK 200010 Shanghai Tokyo, 160-0022 Phone: +86 (0) 21-6355-5161 Phone: +81 (0) 3-5362-0521 E-Mail: info@hilscher.cn E-Mail: info@hilscher.jp...

This manual is also suitable for:

Cifx 80 Cifx 90 Cifx 90e Cifx 104c

hilscher CIFX Series User Manual

1 Introduction

2 Safety

3 Descriptions and Requirements

4 Getting Started

5 Device Drawings

6 Hardware Installation and Uninstalling

7 Troubleshooting

8 Led Descriptions

9 Device Connections and Switches

10 Technical Data

11 Annex

Quick Links

Need help?

Questions and answers

Related Manuals for hilscher CIFX Series

Summary of Contents for hilscher CIFX Series
