Training Manual
PROFINET IO Controller
CIFX, COMX and netJACK - Configuration and Testing - Step by Step
Hilscher Gesellschaft für Systemautomation mbH
www.hilscher.com
DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIFX 50-RE and is the answer not in the manual?

Questions and answers

Related Manuals for hilscher CIFX 50-RE

Summary of Contents for hilscher CIFX 50-RE

  • Page 1 Training Manual PROFINET IO Controller CIFX, COMX and netJACK - Configuration and Testing - Step by Step Hilscher Gesellschaft für Systemautomation mbH www.hilscher.com DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public...

  • Page 2: Table Of Contents

    Required Hardware and Software ................3 List of Revisions......................3 GENERAL PROCEDURE ...................4 NETWORK SETUPS....................5 Setup 1: CIFX 50-RE with NXIO 50-RE..............5 Setup 2: CIFX 50-RE Added as Second Slave............5 STEP-BY-STEP CONFIGURATION ................6 Setup 1: CIFX 50-RE with NXIO 50-RE..............6 4.1.1 Set Up Network ....................6 4.1.2...

  • Page 3: Introduction

    Hardware • 1 x PC with standard equipment: monitor, keyboard, mouse, DVD drive, PCI slot • 1 x CIFX 50-RE acting as Real-Time Ethernet master (requires master license) • 1 x NXIO 50-RE Real-Time Ethernet slave with power supply unit •...

  • Page 4: General Procedure

    Network has not been Add slave to network (e. g. NXIO 50-RE). configured yet. If a full-scale Hilscher slave device is used (e. g. CIFX 50-RE), add also a Stand-Alone Slave. Open Configuration window for master device. Note: Hardware has been Select driver for accessing the master device.

  • Page 5: Network Setups

    (flexible Real-Time Ethernet PCI card) Slave 1: NXIO 50-RE by Hilscher (simple Real-Time Ethernet test slave) Setup 2: CIFX 50-RE Added as Second Slave Setup 2 is a network consisting of a PROFINET IO Controller (master) and two IO Devices (slaves). Master:...

  • Page 6: Step-By-Step Configuration

    1. Create a new project in SYCON.net. In SYCON.net, choose File > New. 2. Insert Hilscher PROFINET IO Controller device in network. Select a CIFX RE/PNM from the Device Catalog (Master) and drag and drop it onto the upper line.
  • Page 7 To import the device description file, choose Network > Import Device Descriptions… in the SYCON.net menu. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 8 Note: Skip the following step, because it does not need to be performed for Setup 1. 4. If a full-scale Hilscher PROFINET IO device is used, place also the corresponding Stand-Alone Slave in the network. Select a CIFX RE/PNS from the Device Catalog (Gateway/Stand- Alone Slave) and drag and drop it onto the PROFINET network line.

  • Page 9: Assign Hardware And Load Firmware

    Settings > Driver > netX Driver. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 10 In the Navigation Area, choose Settings > Device Assignment and scan for available Hilscher devices. Click Scan button. Choose the CIFX 50-RE device by activating the check box PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public ©...
  • Page 11 Click Open button to load firmware into the PC card. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 12 Note: Click OK to finally confirm the assignment of the PC card and the download of the firmware. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 13: Configure Slave

    – set in the master configuration – is necessary. Note: The real station name and the IP address of full-scale Hilscher slaves can be set via Stand-Alone Slave, Hilscher master or by using the Ethernet Device Configuration tool. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public ©...
  • Page 14 Modules is preconfigured for the NXIO 50-RE and can not be changed. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 15: Configure Hilscher Stand-Alone Slave

    15/59 4.1.4 Configure Hilscher Stand-Alone Slave Note: It is not necessary to configure a Hilscher Stand-Alone Slave for this example. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public...

  • Page 16: Configure Master

    On the NXIO 50-RE, the name is set by using the rotary switch (e.g. nxio50repns-01). PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 17 Stand-Alone Slave. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 18 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 19 Under Configuration > Controller Settings, use the default settings. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 20 Step-By-Step Configuration 20/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 21 The green highlighted display indicates an active connection to the master. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 22 Step-By-Step Configuration 22/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 23: Diagnosis And Testing

    Connect. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 24 > Bus ON . This indicates a functioning communication. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 25 Diagnosis and testing with cifX Test 4. Start cifX Test auxiliary tool. In Windows, choose Start > Control Panel > cifX Test. 5. Establish connection to Hilscher device. In the menu, choose Device > Open. Select cifX > Channel0. Note: If you open the cifX level, you can see and use all functions concerning the PC card, e.
  • Page 26 Step-By-Step Configuration 26/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 27 With the output data, you can use cyclic and auto increment. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 28 Step-By-Step Configuration 28/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 29: Setup 2: Add Cifx 50-Re As Second Slave

    29/59 Setup 2: Add CIFX 50-RE as Second Slave The following steps describe – on the basis of Setup 1 – how to integrate a CIFX 50-RE as second IO Device (slave) into the setup. 4.2.1 Set Up Network 1. Add PROFINET IO Device to network.

  • Page 30: Configure Slave

    – set in the master configuration – is necessary. Note: The real station name and the IP address of full-scale Hilscher slaves can be set via Stand-Alone Slave, Hilscher master or by using the Ethernet Device Configuration tool. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public ©...
  • Page 31 I/O data, e. g. 2 bytes input and 2 bytes output. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 32: Configure Hilscher Stand-Alone Slave

    Step-By-Step Configuration 32/59 4.2.4 Configure Hilscher Stand-Alone Slave 1. Open Configuration window for CIFX RE/PNS slave. Right-click on the slave device to open the context menu and choose Configuration… PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public ©...
  • Page 33 Settings > Driver > netX Driver. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 34 In the Navigation Area, choose Settings > Device Assignment and scan for available Hilscher devices. Click Scan button. Choose the CIFX 50-RE by activating the check box PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public ©...
  • Page 35 Click Open button to load firmware into the hardware. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 36 Make sure that these match the slave I/O data of the network configuration. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 37 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 38 Right-click on the Stand-Alone Slave device to open the context menu, then choose Download. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 39 Step-By-Step Configuration 39/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 40: Configure Master

    4.2.5 Configure Master Note: The basic configuration of the CIFX RE/PNM and the NXIO 50-RE has already been carried out during configuration of Setup 1: CIFX 50-RE with NXIO 50-RE. 1. Open Configuration window for CIFX RE/PNM master. Right-click on the master device to open the context menu, then choose Configuration…...
  • Page 41 Stand-Alone Slave. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 42 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 43 Under Configuration > Controller Settings, use the default settings. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 44 Step-By-Step Configuration 44/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 45 The green highlighted display indicates an active connection to the master. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 46 Step-By-Step Configuration 46/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 47: Diagnosis And Testing

    Connect. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 48 The input data area displays the received input data. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 49 4. Start cifX Test auxiliary tool. In Windows, choose Start > Control Panel > cifX Test. 5. Open the Hilscher device to which you want to establish a connection. In the menu, choose Device > Open. Select cifX > Channel0.
  • Page 50 Step-By-Step Configuration 50/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 51 With the output data, you can try cyclic and auto increment. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 52 Step-By-Step Configuration 52/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 53: Tips And Tricks

    Disconnect. Note: Licenses can easily be reordered by simply exporting the filled-in form and handing it over to Hilscher, as if in an ordinary ordering process. Use the Export License Request… button for this. A license is delivered as a license file with the ending .nxl. It can be transferred to the device from the same dialog sheet by clicking the Download License button.

  • Page 54: Automated Scanning Of The Network Structure

    Hilscher master and the download of the corresponding firmware. Furthermore, the Hilscher master must contain a basic configuration. Note: If a non-Hilscher slave device is used, first import in SYCON.net all necessary device description files. Note: After having automatically created a configuration, the configuration still has to be downloaded to the Hilscher master.
  • Page 55 Tips and Tricks 55/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 56: Setting Station Name And Ip Address Of Profinet Devices

    Tips and Tricks 56/59 Setting Station Name and IP Address of PROFINET Devices By using Hilscher PROFINET Controller in SYCON.net 1. Open Configuration window for CIFX RE/PNM master. Right-click on the master device to open the context menu, then choose Configuration…...
  • Page 57 Tips and Tricks 57/59 PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...
  • Page 58 LEDs blink. PROFINET IO Controller | CIFX, COMX and netJACK - Configuration and Testing - Step by Step DOC121001TM02EN | Revision 2 | English | 2012-12 | Released | Public © Hilscher, 2012...

  • Page 59: Contacts

    +49 (0) 6190 9907-50 E-Mail: info@hilscher.com Support Phone: +49 (0) 6190 9907-99 E-Mail: de.support@hilscher.com Subsidiaries China Japan Hilscher Systemautomation (Shanghai) Co. Ltd. Hilscher Japan KK 200010 Shanghai Tokyo, 160-0022 Phone: +86 (0) 21-6355-5161 Phone: +81 (0) 3-5362-0521 E-Mail: info@hilscher.cn E-Mail: info@hilscher.jp...
