Summary of Contents for Akaso V50 Elite
- Page 1 USER MANUAL AKASO V50 Elite Action Camera v1.2...
-
Page 2: Table Of Contents
Controlling Your V50 Elite with Your Voice Connecting to the AKASO GO App Playing Back Your Content Deleting Videos and Photos on Your V50 Elite Transferring Your Data Transferring Your Data to a Smartphone or Tablet Adjusting the Zoom Level... -
Page 3: What's In The Box
Mount 3 Mount 4 Mount 5 Mount 6 Mount 7 Mount 8 Helmet Mounts Battery Charger Protective Backdoor USB Cable Wrist Strap Bandages Tethers Lens Cloth for Remote Quick Start Guide AKASO V50 Elite Action Camera Remote Quick Start Guide... -
Page 4: Your V50 Elite
YOUR V50 ELITE 14 3... - Page 5 Shutter/Wifi/Select Button Touch Screen Power/Mode/Exit Button Up Button Micro USB Port Down Button microSD Card Slot Tripod Hole Micro HDMI Port Battery Door Lens Note: The camera will not record sound when it is in the waterproof case.
-
Page 6: Getting Started
GETTING STARTED Welcome to your AKASO V50 Elite. To capture videos and photos, you need a microSD card (sold separately). MICROSD CARDS Use brand name memory cards that meet these requirements: • microSD, microSDHC, or microSDXC • UHS-3 rating only •... -
Page 7: Overview Of Modes
TURNING WIFI ON/OFF To turn on Wifi Turn on the camera. In Video or Photo mode, press and hold the Wifi button for three seconds to turn on Wifi. To turn off Wifi Press and hold the Wifi button for three seconds to turn off Wifi. TURNING BT(REMOTE PAIR) ON/OFF To turn on BT(Remote Pair) Turn on the camera. - Page 8 Video Mode Video Mode is the default mode when you turn on the camera. In Video Mode, press the shutter button to start recording. Press the Shutter button again to stop recording. 00:00:00 | 01:07:55 Video 4K 30fps Time Lapse Video Mode In Time Lapse Video Mode, press the Shutter button to record video at 1s / 3s / 5s / 10s / 30s / 1 min intervals.
- Page 9 Slow Motion Mode In Slow Motion Mode, press the Shutter button to record slow motion video. 00:00:00 | 01:40:51 Slow Motion 1080P 120fps Photo Mode Turn on the camera and press the Mode button once to switch to Photo Mode, then press the Shutter button to take a photo.
- Page 10 Time Lapse Photo Mode In Time Lapse Photo Mode, press the Shutter button to take a series of photos at 3s / 5s / 10s / 30s / 1 min intervals. 2 / 3220 Time Lapse Photo 20MP Setting Mode Press and hold the Up button for 3 seconds to enter Setting Mode.
-
Page 11: Customizing Your V50 Elite
CUSTOMIZING YOUR V50 ELITE Video Settings 1. Video Resolution: 4K 60FPS, 4K 30FPS, 2.7K 60FPS, 2.7K 30FPS, 1080P 120FPS, 1080P 60FPS, 1080P 30FPS, 720P 240FPS, 720P 120FPS, 720P 60FPS Default setting is 4K 30FPS. Note: When capturing video at high resolutions or high frame rates in warm ambient temperatures, the camera may become warm and use more power. - Page 12 If you record for 5 minutes and do not press the Shutter button to stop recording and save, the camera records a new 5-minute interval by recording over your previous 5 minutes of footage. When the microSD card is full, the new files will write over the old one if loop recording is on.
- Page 13 9. Wind Noise Reduction: On / Off Default setting is Off. Turn on Wind Noise Reduction to lower the noise to an acceptable level. 10. Angle: Wide/Medium/Narrow Default setting is Wide. The angle refers to how much of the scene can be captured through the camera lens.
- Page 14 2. ISO: Auto / 100 / 200 / 400 / 800 / 1600 / 3200 Default setting is Auto. ISO determines the camera’s sensitivity to light, and creates a trade-off between brightness and resulting image noise. Image noise refers to the degree of graininess in the image.
- Page 15 8. Long Exposure: Off/1 Sec/2 Sec/5 Sec/8 Sec/30 Sec/1 Min Default setting is Off. Long exposures are easiest to accomplish in low-light conditions, but can be achieved in brighter light using neutral density filters or specially designed cameras. Note: Long Exposure is disabled when Burst Photo is on. 9.
- Page 16 Press any button on the camera to turn the display back on. 9. Auto Power Off: Off/1 Min./2 Min. Default setting is 2 Min. Powers off your V50 Elite after a period of inactivity to save battery life. 10. Power-on Auto Record: On/Off Default setting is Off.
- Page 17 14. Reset Wifi Setting: Yes/No Default setting is No. This option can erase the Wifi data of the V50 Elite. 15. Language: English, Português, 日本語, Deutsch, Italiano, Español, Français Default setting is English.
-
Page 18: Connecting Your V50 Elite With Remote
The System Info option lets you check the model, version and updated time of your V50 Elite. The Card Info option lets you check the capacity and free space of your microSD card. Some functions cannot be used at the same time. Please refer to the information below. -
Page 19: Controlling Your V50 Elite With Your Voice
CONTROLLING YOUR V50 ELITE WITH YOUR VOICE You can control your V50 Elite with your voice using a set of specific commands (see list below). Note: Voice Control performance may be impacted by distance, wind, and noisy conditions. Keep the product clean and clear of debris. -
Page 20: Connecting To The Akaso Go App
3. Turn on Wifi of your mobile device and connect to the Wifi SSID “AKASO_V50Elite”. 4. Enter the password: 1234567890 5. Open the AKASO GO app and tap the “Add device” icon. Add “V50Elite” and click “Live Preview”. 6. Your camera will now be connected to the AKASO GO app. -
Page 21: Playing Back Your Content
TV. With this method, playback resolution depends on the resolution of the device and its ability to play back that resolution. VIEWING VIDEOS AND PHOTOS ON YOUR V50 ELITE 1. Turn on the camera. -
Page 22: Deleting Videos And Photos On Your V50 Elite
4K 30FPS 00:00:02 / 00:05:34 DELETING VIDEOS AND PHOTOS ON YOUR V50 ELITE 1. Enter the playback mode. 2. Tap the video file icon or photo file icon 3. Tap the video or photo file you wish to delete. 4. Tap . -
Page 23: Transferring Your Data
1. If you cannot transfer videos or photos to your iPhone or iPad, please go to Settings → Privacy → Photos, find "AKASO GO" and select "Read and Write". 2. iPhone and iPad do not allow the download of 4K or 2.7K video via the app. Please transfer 4K or 2.7K video via a card reader. -
Page 24: Reformatting Your Microsd Card
REFORMATTING YOUR MICROSD CARD To keep your microSD card in good condition, reformat it on a regular basis. Reformatting erases all of your content, so be sure to transfer your photos and videos first. 1. Turn on the camera and enter Camera Settings. 2. -
Page 25: Battery Storage And Handling
BATTERY STORAGE AND HANDLING The camera contains sensitive components, including the battery. Avoid exposing your camera to very cold or very hot temperatures. Low or high temperature conditions may temporarily shorten the battery life or cause the camera to temporarily stop working properly. -
Page 26: Remote
3. Press and hold the Power button to turn on the remote. The remote indicator will flash once per second during connection. 4. The camera screen will show “Connected”. When the V50 Elite is successfully connected with the remote, the remote indicator will remain lit. -
Page 27: Mounting Your Camera
MOUNTING YOUR CAMERA You can attach your camera to helmets, handlebars and equipment, as follows:... -
Page 28: Contact Us
CONTACT US For any inquiries about AKASO products, please feel free to contact us. We will respond within 24 hours. E-mail: cs@akasotech.com Tel: (888) 466-9222 (US) Mon-Fri (except holiday) 9am-5pm (EST) Official website: www.akasotech.com The microSD, microSDHC, microSDXC and SD marks and logos are trademarks of...
