- Page 1 INSTRUCTION MANUAL 20V Cordless Blower Model # PS76101B Have product questions or need technical support? Please scan the QR code to enter our official website and contact us! Website: www.powersmartusa.com Toll free: 1-800-791-9458 M-F 9-5 EST Website Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Assembly ………….……………………………………………………… 13 Operating instruction…………………………………………………..Maintenance.……………………………………………………………… 16 Environmentally safe battery disposal……………………………………. 17 Exploded view & parts list……………………………………………… Warranty statement……………………………………………………… TECHNICAL DATA 20V Cordless blower Model # PS76101B Power input: Blower speed: 150MPH No load speed: 9000/15000 RPM Battery type: 20V Lithium-ion，2.0Ah... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your blower works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. - Page 6 CAUTION: In all cases, make certain the outlet in question is properly grounded. If you are not sure if it is, have a licensed electrician check the outlet. WARNING: Do not expose to rain or use in damp locations. Guidelines for using extension cords Make sure your extension cord is in good condition.
- Page 7 Wear safety glasses with side shields or goggles that are marked to comply with ANSI Z87.1 standard when operating this product. Use face or dust mask if environment is dusty. Do not operate the equipment while barefoot or when wearing sandals or similar lightweight ...
- Page 8 BATTERY TOOL USE AND CARE WARNING: USE ONLY POWERSMART APPROVED REPLACEMENT BATTERIES, OTHER BATTERIES MAY CAUSE INJURY OR DAMAGE TO THE BLOWER. Use with POWERSMART 20V battery. Battery safety rules Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in ...
-
Page 9: Specific Safety Rules For Blower
Proper care for battery Off-season storage To obtain the longest possible battery life, we suggest the following: Remove the battery pack from the charger once it is fully charged and ready for use. For battery pack storage longer than 30 days: Store the battery pack where the temperature is below 80°F and away from moisture. - Page 10 Remove all hard objects from work area. Do not blow debris in the direction of people, animals or property. Use only accessories provided. Keep guards in place and in working order. Maintain labels and nameplates on the appliance. These carry important safety information. ...
-
Page 11: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 12: Knowing Your Blower
KNOWING YOUR BLOWER Blower small tube Blower big tube Blower removal button Variable speed trigger switch On/Off trigger switch Battery pack Unpacking Unpack the blower and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. -
Page 13: Assembly
ASSEMBLY WARNING: Do not use this product if any parts on the packing list are already assembled to your product when you unpack it. Parts on this list are not assembled to the product by the manufacturer and require customer installation. Use of a product that may have been improperly assembled could result in serious personal injury. - Page 14 CONNECTING AND REMOVING BATTERY IMPORTANT! The battery pack is not charged when it is purchased. Before using the power tool for the first time, place the battery pack in the battery charger and charge. Make sure to read all safety precautions, and follow the instructions in the battery charger section.
-
Page 15: Operating Instruction
OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this blower. Failure to do so may cause serious injury or death. Do not allow anyone to operate this blower who has not read this manual. A blower can be dangerous if assembled or used improperly. -
Page 16: Maintenance
MAINTENANCE WARNING: To avoid serious personal injury, always remove the battery pack from the product before inspecting, cleaning or performing any maintenance. WARNING: Always wear eye protection with side shields marked to comply with ANSI Z87.1. If operation is dusty, also wear a dust mask. WARNING: When servicing, use only identical replacement parts. -
Page 17: Environmentally Safe Battery Disposal
BATTERY PACK Store the battery pack fully charged. Once the charging light turns green, remove the battery from the charger and disconnect the charger from the outlet. Do not store the battery pack on the tool. After charging, the battery pack may be stored in the charger, as long as the charger is not plugged in. ... -
Page 18: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 19 Item stock# Description PS76101B-001 Blower small tube PS76101B-002 Blower big tube PS76101B-003 Connector tube PS76101B-004 Pressing plate PS76101B-005 Screw ST4x14 PS76101B-006 Right housing PS76101B-007 Insert base PS76101B-008 Battery pack PS76101B-009 Motor PS76101B-010 Powder metallurgy PS76101B-011 PS76101B-012 Left housing PS76101B-013 Switch button...
- Page 20 (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use. SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Two (2) Years Limited...
