Summary of Contents for Power smart PS76154A
- Page 1 INSTRUCTION MANUAL 20V Cordless Blower Model # PS76154A Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com www.powersmartusa.com Toll free: 1-800-791-9458 M-F 9-5 EST Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Assembly instruction…………………………………………….………. 10 Operating instruction…………………………………………………..11 Maintenance……………………………………………………...………. 12 Trouble shooting…………………………………………………………. 13 Exploded view…………………………………………………………… 14 Parts list…………………………………………………………………... 15 Warranty…………………………………………………………………. 16 TECHNICAL DATA 20V Cordless Blower Model # PS76154A Power input: No-load speed: 13000~16000 RPM Max air speed: 85MPH Max wind capacity: 350CFM Battery type: 20V Lithium-ion, 1.5Ah... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your power tool works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. - Page 6 POWER TOOL USE AND CARE Do not force power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it is designed. Do not use the power tool if switch does not turn it on or off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
-
Page 7: Special Safety Rules For Cordless Blower
SPECIFIC SAFETY RULES FOR CORDLESS BLOWER Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce air flow. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts. ... -
Page 8: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 9: Knowing Your Cordless Blower
KNOWING YOUR CORDLESS BLOWER Fig.1 Blower Tube On/Off trigger switch Turbo button Handle Battery Unpacking Unpack the power tool and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. Please call 1-800-791-9458 or E-mail us at support@amerisuninc.com if any parts are damaged or missing. -
Page 10: Assembly Instruction
ASSEMBLY INSTRUCTION WARNING: Do not use this product if any parts on the packing list are already assembled to your product when you unpack it. Parts on this list are not assembled to the product by the manufacturer and require customer installation. Use of a product that may have been improperly assembled could result in serious personal injury. -
Page 11: Operating Instruction
CONNECTING AND REMOVING BATTERY IMPORTANT! The battery pack is not charged when it is purchased. Before using the power tool for the first time, place the battery pack in the battery charger and charge. Make sure to read all safety precautions, and follow the instructions in the battery charger section. -
Page 12: Maintenance
TEMPERATURE CONTROL /OVERLOAD PROTECTION When the temperature of battery is too high and the machine switches off automatically. • Switch the power tool off. • Allow the battery to cool down before continuing to work. When the power tool is blocked and switches off automatically. •... -
Page 13: Trouble Shooting
Our machines have been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper machine care and regular cleaning. In order to maintain battery capacity, we recommend the battery to be completely discharged every ... -
Page 14: Exploded View
EXPLODED VIEW... -
Page 15: Parts List
PARTS LIST Item Stock# Description PS76154A-001 Blower tube PS76154A-002 Wider tube PS76154A-003 Diversion cone PS76154A-004 Fairing PS76154A-005 Fairing PS76154A-006 Suction cover PS76154A-007 Blower tube button PS76154A-008 Small spring PS76154A-009 Motor end plate PS76154A-010 Motor PS76154A-011 Screw PS76154A-012 PS76154A-013 Shaft sleeve... -
Page 16: Warranty
TWO (2) YEARS LIMITED WARRANTY ® PowerSmart is committed to building tools that are dependable for years. Our warranties are consistent with our commitment and dedication to quality. TWO (2) YEARS LIMITED WARRANTY OF POWERSMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
