CONSTRUCTION
Heavy-duty cast iron bowl with a glossy white enamel
designed for the toughest of applications, and at the same time is
gentle to all users with its soft rounded corners. Unit also ships with
vandal-resistant bottom plates to provide added peace of mind.
BUBBLER HEADS
Polished chrome-plated brass bubbler heads with integral 11/16" dia.
basin shank and stainless anti-rotation roll pin for vandal resistance
strength. Shielded, angled stream opening provides a steady, sanitary
source of drinking water at .45 gpm.
FOUNTAIN VALVES
Fountain incorporates touchless sensor operated stainless steel
solenoid valves controlled by a transformer for hands-free operation.
A pressure regulator is used to adjust the bubbler flow according to
incoming water pressures.
VANDAL RESISTANT
The bubbler heads, drain strainer and bottom plate are locked in
place, discouraging unwanted vandal tampering.
INTEGRATED TRAP
All cast brass 1-1/4" NPT adjustable traps completely concealed
inside bottom plates for easy installation and lack of unwanted access.
Bottle Filler: Model 1920WHO, touchless bottle
stand-alone station, or mounted above Haws 1430 series
touchless drinking fountain models.
Remote Drinking Fountain Water chiller: Model HCR8, 8 gph (30.3
L) remote water chiller provides instantaneous cooling to meet a
continuous demand for chilled water.
For more information, visit www.hawsco.com
DISCLAIMER: Continued product improvements make speci cations subject to change without notice. Check www.hawsco.com for the latest product information and updates.
FEATURES & BENEFITS
nish is
OPTIONS
ller can be a
or call (888) 640-4297.
1455 Kleppe Lane :: Sparks, NV 89431 :: p. 775.359.4712 :: f. 775.359.7424 :: e. info@hawsco.com :: www.hawsco.com :: 31 May, 2023
model
Vandal-Resistant Enameled Iron Motion-Activated Fountain
Model 1430HO vandal-resistant wall mounted motion activated drinking
fountain shall include a white enameled- iron basin mounted with twin
galvanized cast-iron wall brackets, touchless sensor operated stainless
steel solenoid valves with 30-second obstruction time-out controlled by
a transformer, 100% lead-free waterways, dual polished chrome plated
brass vandal-resistant bubbler heads, polished chrome plated brass
vandal-resistant waste strainer, vandal-resistant bottom plate, and
chrome- plated 1-1/2" NPT trap.
FOR INDOOR USE ONLY
Perfect for either public or private settings, our gleaming white
enameled-iron series is one of the sturdiest wall mounted fountains
Haws produces. This unit is the perfect t for high traf c areas where
there is a greater need for multiple drinking stations. Elegant gloss nish
and color consistency throughout the enameled-iron maintain the
fountains overall appeal so it always remains looking as new as it did
when it was installed. Speci cally, this type of wall mounted drinking
fountain may be placed in settings such as: parks, schools, and other
indoor/outdoor environments where the temperature remains above
freezing. Haws manufactures drinking fountains, faucets and electric
water coolers to be lead-free by all known de nitions including
NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition
65, and the Federal Safe Drinking Water Act. Product is compliant to
California Health and Safety Code 116875 (AB 1953-2006), and
NSF/ANSI/CAN 61: Q ≤ 1.
1430HO
SPECIFICATIONS
APPLICATIONS
