Qu-Bit Electronix Mojave Quick Start Manual page 13

Dune Output
19
A configurable CV/Gate output that is algorithmi-
cally generated by Mojave. Swap between output
options via the Narwhal web app. See the manual
for a full list of available outputs!
CV Output (Default): Variable modulation source
generated by the environmental conditions at play
in Mojave. Range: 0V to +5V.
Microphone
20
Become the wind itself with Mojave's onboard
microphone! The mic normals to the left input
by default.
Control the input level by holding the Clock Mode
button and turning the Mix knob.
Reset the input level settings by holding the Clock
Mode and pressing the Freeze button.
Avoiding Feedback: Minimize completely dry mix
and original Speed settings.
Mic Mode
Sets the mic relationship with the audio input.
Hold the Clock Mode button and press the
Lock button to cycle modes:
Mode
Normalled
Off
Summed
Color Description
Blue Mic is normalled to the left input
Green Mic is turned off
Gold Mic is summed with the audio inputs
12
