True TDD-4 Specifications

2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# (636)272-9471
Model:
TDD-4
ROUGH-IN DATA
Model Doors
TDD-4 3
†
Depth does not include 1 "
* Height does not include 15
T T R R
RUE RU EFRIGERATION
TM TM
MADE IN
U.S.A. U.S.A. .S.A.
SINCE 1945
1/07
TRUE FOOD SERVICE
EQUIPMENT, INC.
Direct Draw Beer Dispenser:
Solid Door
Cabinet Dimensions
(inches)
Capacity
(mm)
1
/
2
Barrels †
L D
3 1
4 90 / 27 /
8 8
2296 689
(26 mm) for rear bumpers.
1 / " (388 mm) for draft arms.
4
APPROVALS:
R
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
Chart dimensions rounded up to the nearest
* HP Voltage
H
1
37 / 115/60/1
3
1
940 / 230-240/50/1
3
Qty:
TDD-4
True's direct draw beer
dispensers are designed with
enduring quality and value.
Our commitment to using the
highest quality materials and
oversized refrigeration assures
colder product temperatures
and years of trouble free
service.
Oversized, factory balanced,
refrigeration system holds 33°F
to 38°F (.5°C to 3.3°C).
Exterior - heavy duty, wear
resistant laminated black vinyl
front and sides. Matching black
aluminum back. All stainless
steel counter top.
Interior - 300 series stainless
steel fl oor with
reinforced lip and heavy gauge
galvanized steel walls. NSF
approved for pre-packaged
and bottled product.
3 (77 mm) diameter stainless
"
steel insulated beer columns.
Cold air is directed into beer
columns to reduce foaming and
maximize draft beer profi ts.
Entire cabinet structure and
solid doors are foamed-in-place
using high density, CFC free,
polyurethane insulation.
Specifi cations subject to change without notice.
1
/ " (millimeters rounded up to next whole
8
Cord Length
NEMA
(total ft.)
Amps Confi g.
(total m)
8.5 5-15P 7
▲
4.2 2.1
▲ Plug type varies by country.
AVAILABLE AT:
AIA #
SIS #
1
/ (13 mm)
"
2
number).
Crated
Weight
(lbs.)
(kg)
415
189
