True TDD-1 Specifications

St. Charles Industrial Center • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# (636)272-9471
Model:
TDD-1
ROUGH-IN DATA
Model Doors
TDD-1 1
*
Height does not include 14
T R
RUE EFRIGERATION
TM
MADE IN
U.S.A.
®
SINCE 1945
12/05
TRUE FOOD SERVICE
EQUIPMENT, INC.
Direct Draw Beer Dispenser:
Solid Door
Cabinet Dimensions
(inches)
Capacity
(mm)
1
/
2
Barrels
L D
1 1
1 23 / 31 /
2
597 794
1
/ " (362 mm) for draft arm.
4
APPROVALS:
R
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
Chart dimensions rounded up to the nearest
* HP Voltage
H
3 1
39 / / 115/60/1
4 4 6
1
1010 / 230-240/50/1
4
Qty:
TDD-1
True's direct draw beer
dispensers are designed with
enduring quality and value. Our
commitment to using the highest
quality materials and oversized
refrigeration assures colder
product temperatures and years
of trouble free service.
Oversized, factory balanced,
refrigeration system holds 33°F to
38°F (.5°C to 3.3°C).
Exterior - heavy duty, wear
resistant laminated black vinyl
front and sides. Matching black
aluminum back. All stainless steel
counter top.
Interior - 300 series stainless steel
fl oor with 1 / " (13 mm) reinforced
2
lip and heavy gauge galvanized
steel walls. NSF approved for pre-
packaged and bottled product.
3" (77 mm) diameter stainless
steel insulated beer column. Cold
air is directed into beer column
to reduce foaming and maximize
draft beer profi ts.
Anodized aluminum glass rail
provides convenient storage for
glasses on top.
Entire cabinet structure and
solid door are foamed-in-place
using high density, CFC free,
polyurethane insulation.
Specifi cations subject to change without notice.
1
/ " (millimeters rounded up to next whole
8
Cord
Length
NEMA
(total ft.)
Amps Confi g.
(total m)
3.9 5-15P 7
▲
2.5 2.1
▲ Plug type varies by country.
AVAILABLE AT:
AIA #
SIS #
number).
Crated
Weight
(lbs.)
(kg)
180
82
