https://wiki.teltonika-gps.com/view/FM63_Testing_RS-232_and_RS-485_TCP_Link_Mode
FM63 Testing RS-232 and RS-485 TCP Link
Mode
Main Page
>
EOL Products
Contents

1 Step 1. Understanding what is FM63XY RS232/RS485 TCP Link mode

2 Step 2. Setting parameters in the configurator for TCP Ascii mode test
3 Step 3. Establishing FM63XY test link with the server through Hercules
Step 1. Understanding what is FM63XY RS232/RS485 TCP
Link mode
In this mode link with an external device (for example PC) using text messages can be established.
FM63XY has to be connected to the external device through RS232 or RS485. Any string of data
coming to RS232 or RS485 will be routed to the server (if the link is currently active). Messages that
are exchanged between FMB device and server, have to be packed in Codec.12 format. Here for TCP
link establishment, we will be using Hercules. For sending messages from external devices to
servers over FM63XY Terminal will be used.
Step 2. Setting parameters in the configurator for TCP Ascii
mode test
First of all, in the FM63XY configurator you have to set parameters for RS232 or RS485 (depends on
which RS232 or RS485 port you are using) in the global parameters window.
>
FM6300
>
FM6300 Manual
> FM63 Testing RS-232 and RS-485 TCP Link Mode

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM63 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Teltonika FM63 Series

  • Page 1 FM63 Testing RS-232 and RS-485 TCP Link Mode Main Page > EOL Products > FM6300 > FM6300 Manual > FM63 Testing RS-232 and RS-485 TCP Link Mode Contents 1 Step 1. Understanding what is FM63XY RS232/RS485 TCP Link mode 2 Step 2.
  • Page 2 Here in the RS232 settings section, Baudrate can be chosen for any available. The mode has to be chosen for TCP Ascii. 2.1. Message Timestamp Message Timestamp parameter is used to determine if it is necessary to include a timestamp in the RS232 TCP packet when sending it to the server.
  • Page 3 Here you have to choose the TCP Server section from the upper menu. In the marked fields: 1. Write your server (PC) port and press Listen button; 2. In the Client connection status you will be able to see if a connection between server and FMB device has started successfully;...
  • Page 4 On terminal you should now receive a message: Step 5. Sending from external device to server over Terminal For testing data sending from external device to server, enter the text you want to send on Terminal and press send. You can check if data is received to a server in Hercules. Sample text: Hello, lets test TCP link mode. Please keep in mind, that special chars (ASCII Names) need to be marked.
