REMOVING THE FREEZER DRAWER
The freezer drawer can be removed, if needed,
to fit through tight areas.
Read these instructions completely and carefully.
REMOVE THE BASKET
1
A Open the freezer drawer until it stops.
B The freezer basket rests on a frame inside the
freezer drawer. Lift the basket up at the back.
Lift the front up and lift the entire basket up
C
and out of the drawer.
REMOVE THE DRAWER FRONT
2
FROM THE SLIDES
Remove the screw on each side of the railing.
A
Installation Instructions
A
Screw
REMOVE THE DRAWER FRONT FROM
2
THE SLIDES
(cont.)
B Lift up on both sides of the freezer drawer
handle to separate the drawer railings from
the rail assemblies.
C Set the drawer front on a non-scratching
surface.
D Push the rail assemblies back into locking
position.
Drawer
Rail Assembly
Assembly
REMOVE THE BASE GRILLE
3
(if needed)
If, after removing the freezer drawer and
refrigerator door, the refrigerator will still not
fit through a doorway, the base grille can be
removed.
Remove the base grille by removing the
A
screws.
