2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# (636)272-9471
Model:
TD-65-24-LT
ROUGH-IN DATA
Capacity
12oz.
Model
Lids
btls.
TD-65-24-LT
2
22 cases
†
1
Depth does not include 1
/
2
note: 12 oz. bottles refers to 12 oz. longneck bottles.
T
R
RUE
EFRIGERATION
TM
MADE IN
U.S.A.
U.S.A.
.S.A.
®
SINCE 1945
4/06
TRUE FOOD SERVICE
EQUIPMENT, INC.
Deep Well Horizontal Bottle Cooler:
Low Temperature Solid Lid
Cabinet Dimensions
12oz.
Bin
cans
Dividers
L
1
32
/
4
64
2
cases
1642
"
(39 mm)
for cap catcher and 1"
APPROVALS:
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
Chart dimensions rounded up to the nearest
(inches)
(mm)
†
D
H
HP Voltage
5
5
3
1
/
26
/
33
/
/
8
8
8
3
677
848
(26 mm)
for rear bumpers.
Qty:
TD-65-24-LT
True's horizontal bottle coolers are
designed with enduring quality
and value. Our commitment to
using the highest quality materials
and oversized refrigeration assures
colder product temperatures and
years of trouble free service.
Oversized, factory balanced,
refrigeration system holds 20°F
(-6.6°C). For applications with high
ambient temperatures. Designed
for full alcoholic beverages only.
Note; some low alcohol products
freeze below 32°F (0°C).
Forced-air cooling, positively guided
airfl ow cools bottles on top fi rst.
Evaporator coil virtually runs length
of cooler for balanced temperatures
throughout the cabinet.
Exterior - all stainless steel
countertop and lids, heavy duty,
wear resistant laminated black vinyl
front and sides, matching black
aluminum back.
Interior - long lasting, heavy duty
galvanized steel.
Evaporator is epoxy coated to
eliminate the potential of
corrosion.
Entire cabinet structure is foamed-
in-place using high density, CFC
free, polyurethane insulation.
Heavy duty, 10 mil thick pure grade
PVC coated adjustable bin dividers.
Removable, bottle cap opener and
cap catcher.
Specifi cations subject to change without notice.
1
/
"
(millimeters rounded up to next whole
8
NEMA
Amps
Confi g.
115/60/1
8.2
5-15P
AVAILABLE AT:
AIA #
SIS #
number).
Cord
Crated
Length
Weight
(total ft.)
(lbs.)
(total m)
(kg)
7
285
2.13
130
