SPROUT HARMONIC 3.0 - Bluetooth Headphones Manual

WHAT'S IN THE BOX?

For optimum performance and safety, please read instructions carefully before usage.

Please keep this manual for future reference.

1x Harmonic 3.0 Bluetooth Headphones
1x USB-A to USB-C charging cable
1x Plane adaptor
1x Carry case
1x Aux-in audio cable
1x Product manual

PRODUCT OVERVIEW

1. Active Noise Cancellation switch
2. USB-C charging input
3. LED indicator
4. Volume control
5. DuoLink^TM button
6. Power/play/pause button
7. Microphone for calls
8. Aux input port

QUICK START GUIDE

LED INDICATOR

CHARGING YOUR HARMONIC 3.0 BLUETOOTH HEADPHONES

1. Insert the USB-C end of the charging cable into the charging input
2. Insert the USB-A end of the cable into a power source* to charge. The LED indicator will be red while charging is in progress. The LED indicator will be blue when charging is complete. A full charge will take approximately 1.5 hours

iOS enabled devices will display the Harmonic 3.0 battery power status on the top right hand side of their screen.

*Power options include USB connection to a power source such as a Sprout AC power adapter, a Sprout car charger or computer/notebook USB connection.

TURNING HARMONIC 3.0 ON/OFF

Press and hold the power/play/pause button for 3 seconds to power on/off.

CONNECTING VIA BLUETOOTH

1. Enter into pairing mode:
   • From power off status, press and hold the power/play/pause button for 5 seconds to enter pairing mode
   • From power on status, press and hold the power/play/pause button for 2 seconds to enter pairing mode
     Once in pairing mode, Harmonic 3.0's LED indicator will flash blue/red until a device is connected
2. Turn on Bluetooth on your mobile phone/music device*
3. 'Harmonic 3.0' will appear on your mobile phone/music device. Select 'Harmonic 3.0' to pair
4. The LED indicator light will flash blue every 5 seconds when you are connected
5. Enjoy your music

*If you are not familiar with Bluetooth pairing for your mobile phone or music device, refer to the user guide for your mobile phone/music device for instructions to pair a new device using Bluetooth.

CONNECTING VIA 3.5MM AUX CABLE

Connect your Harmonic 3.0 to a smartphone, tablet or other audio device using your aux-in audio cable. Once connected, all additional controls (volume, skip track, etc.) will be disabled on your headphones. Your audio device must be used to perform these functions.

Please note: Using 3.5mm aux input will override a Bluetooth source input.

OPERATING CONTROLS

VOLUME ADJUSTMENT

Short press on Vol+ or Vol- buttons.

PLAY/PAUSE

Short press the power/play/pause button button to pause audio. Press again to resume audio.

ANSWER/END CALL

Short press the power/play/pause button to answer an incoming call or end a phone call.

REJECT CALL

Press the power/play/pause button for 2 seconds to reject a call.

TRANSFER CALL

After accepting a phone call, press the power/play/ pause button for 2 seconds, and your call will transfer to your smartphone. Press the power/play/pause button for 2 seconds again, and your call will be transferred to your Harmonic 3.0 Headphones.

RESTORE FACTORY SETTINGS

Connect your Harmonic 3.0 to a computer via the USB-A to USB-C cable, press Vol + button and Vol - together for 5 seconds. Once complete, your LED indicator light will flash blue 6 times.

ACTIVE NOISE CANCELLATION FUNCTION (ANC)

ANC function can be enabled to reduce outside noise and provide enhanced sound quality. To activate ANC, switch the ANC button to "ON". Your LED indicator light will turn green once ANC is engaged.

CONNECTING MULTIPLE HARMONIC 3.0 VIA DUOLINK™

Using the DuoLink feature you can connect multiple Harmonic 3.0 Headphones. One set will be your 'primary' headphones and another will be your 'replica'.

TO CONNECT

• Short press the DuoLink button on your primary device once. The primary will announce "DuoLink enabled"
• Short press the DuoLink button on your replica device once. The replica will announce "DuoLink enabled"
• Press the DuoLink button once more on the replica to connect both devices
• Once connected, the replica will announce that it is using "DuoLink Audio". The primary device will show a solid blue light while the replica will show a flashing red and blue light

TO DISCONNECT OR RESET

• Press DuoLink button again to disable DuoLink*
• Press and hold the DuoLink button for five seconds to reset the DuoLink function**

*If DuoLink is disabled, Harmonic 3.0 will disconnect from the replicas, but will still remember them.

**Resetting DuoLink will make your Harmonic 3.0 'forget' all replica devices.

SPECIFICATIONS

• 4x ANC microphones, 1x call microphone
• Bluetooth V5.1
• Bluetooth range: 10m
• Qualcomm QCC3021 chipset
• Rechargeable 800mAh battery
• Up to 35 hours at 50% volume without ANC
• USB-C charging input
• Aux input port
• Noise reduction coefficient: 35dB +/-3 dB
• PU leather ear pads with memory foam
• Operating temperature: 0-40°C

IMPORTANT SAFETY INFO

Read all instructions and warnings prior to using this product. Improper use of this product may result in product damage, excess heat, toxic fumes, fire or explosion.

• Do not use your Harmonic 3.0 near an open fire, heat source or excessive heat
• Do not use your Harmonic 3.0 near water
• Using your Harmonic 3.0 is not recommended while charging
• Protect your charging cable from being pinched particularly at the connectors
• Unplug your charging cable during lightning storms or when unused for long periods of time
• Avoid listening at excessive volume levels or for prolonged periods
• Do not disassemble this device or attempt to modify it in any manner

All Sprout products go through thorough quality assurance inspections. If you find that your device is excessively hot, is emitting odour, is deformed, abraded, cut or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact Sprout.

Sprout Accessories Pty Ltd
W: Sproutinc.com.au | E: enquiries@sproutinc.com.au
