- Page 1 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Titan Dynamics - Hawk https://www.titandynamics.org/3dhangar/p/titan-hawk Build & User Manual Revision 1.2 Page 1 of 25...
-
Page 2: Table Of Contents
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Contents Section 1: Model Information ........................ 3 Section 2: Model Specifications & Performance ................4 2.1: Physical Characteristics ....................... 4 2.2: Aircraft Performance: ........................5 2.2.1: Drag, Efficiency, Power, and Angle of Attack at Varying All-up-weights: ..... 6 2.2.2: Turn rate, range, endurance, and max climb rate for a variety of different... -
Page 3: Section 1: Model Information
The Titan Hawk is a 1m wingspan twin-boom focused on maximizing efficiency. Boasting a range of 153km with flight time of 2h40m (on its maiden), the Hawk punches well above its weight. The feel on the sticks is akin to a much larger aircraft with excellent wind resistance and handling like it’s on rails. -
Page 4: Section 2: Model Specifications & Performance
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Section 2: Model Specifications & Performance 2.1: Physical Characteristics General Stats: • Wingspan: 1021mm • Wing area: 1690cm • Maximum take-off Weight: 1.75kg • Efficiency: 0.88 Wh/km @ 1.5kg AUW •... -
Page 5: Aircraft Performance
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server 2.2: Aircraft Performance: Below are some plots showing aircraft performance at different all-up weights. The values predicted are not perfect, and values like efficiency can vary greatly based on the choice of motor and propeller, among many other factors. -
Page 6: 1: Drag, Efficiency, Power, And Angle Of Attack At Varying All-Up-Weights
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server 2.2.1: Drag, Efficiency, Power, and Angle of Attack at Varying All-up-weights: Page 6 of 25... - Page 7 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 7 of 25...
- Page 8 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 8 of 25...
- Page 9 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 9 of 25...
-
Page 10: 2: Turn Rate, Range, Endurance, And Max Climb Rate For A Variety Of Different Battery Configurations
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server 2.2.2: Turn rate, range, endurance, and max climb rate for a variety of different battery configurations: Page 10 of 25... - Page 11 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 11 of 25...
- Page 12 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 12 of 25...
-
Page 13: Section 3: Required Build Materials
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Section 3: Required Build Materials Spars needed: • (1) 8x500mm tube (main wing spar) • (1) 4x270mm rod (rear wing spar) • (2) 3x240mm rod (aileron hinge) •... -
Page 14: Section 4: 3D Printing
Section 4: 3D printing 4.1: Things to know before you start printing. 1. Titan Dynamics strongly recommends using Polymaker Polylite prefoamed LWPLA for the best results. This filament is much easier to tune your printer for and has less stringing than active foaming filaments. If you aren’t able to purchase... -
Page 15: Part Orientation
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server subdivision or cubic. A part printed at 3% gyroid is comparable weight to the same part printed at 7% cubic subdivision. Polycarbonate, PETG or other high-temp filament should be used for the motor mounts and wing bay covers. - Page 16 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 16 of 25...
-
Page 17: Tuning "Hole Horizontal Expansion
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server 4.3: Tuning “hole horizontal expansion” It is very important to check the fitment of the carbon rods in their holes on the first parts you print. Because everyone may be using different printers, materials and slicer settings, it is not possible to provide the models with a slicing profile and hole size that will work for everyone. - Page 18 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Once completed, be careful when removing these tabs from the print as they are quite strong and can damage the bottom of your part if not removed carefully. Re-open any holes the tab may have filled on the bottom of the print.
-
Page 19: Section 5: Assembly Of 3D Printed Parts
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Section 5: Assembly of 3D Printed Parts Below are a few exploded views of the Hawk to help with assembly. Page 19 of 25... - Page 20 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 20 of 25...
- Page 21 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server The spar layout for Hawk is as depicted below. Page 21 of 25...
- Page 22 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server • Medium CA glue should be used to assemble all fuselage parts. • When first putting the glued parts together be sure to wipe any excess glue off before it sets.
-
Page 23: Section 6: Final Setup & Tuning Tips
Join our Discord server Section 6: Final Setup & Tuning Tips • Titan Dynamics strongly recommends the use of Arduplane for all our models. If you encounter an issue in flight, the data logs Ardupilot creates are invaluable for finding the root cause of any issue and increasing future chances of success. -
Page 24: Section 7: Additional Images
Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Section 7: Additional Images Page 24 of 25... - Page 25 Titan Dynamics Titan Dynamics Webpage Visit our Facebook page Join our Discord server Page 25 of 25...
