Walthers Cornerstone 933-4600 Manual

HO Structure Kit
BLAST FURNACE
933-4600
Thanks for purchasing this Cornerstone® kit! Please take a few minutes to read the instructions and study the drawings before
starting each step. While this is a large kit, each step can be completed in stages: work slowly and highlight or check off each
completed assembly sequence. All parts are made of styrene, so use only compatible glue and paint to assemble and finish your
model. You may find it easier to build and paint some parts as subassemblies before moving on to the next step. PLEASE
NOTE: Most individual part numbers are molded on sprues, however some sprues have been trimmed; please refer to illustra-
tions to properly identify parts.
While no other structure is so closely associated with a steel works, blast furnaces actually produce "pig iron." Named for an
early casting method resembling a mother pig nursing little ones molten iron flowed into a large main trench called the "sow,"
then into several smaller trenches, where it cooled to form "pigs." Once charged and "blown in," the furnaces run non-stop at
temperatures up to 3500°F (1926.7°C). Each ton of pig iron produced requires about three tons (2.7t) of raw materials: nearly
two tons (1.8t) of ore, about 1500 pounds (0.6804t) of coke and the rest in fluxing stone (usually limestone or dolomite), plus a
few hundred pounds of iron and steel scrap. Finally, four (3.6t) to four-and-one-half tons (4.0t) of air will be consumed. For every
ton of iron, 700 pounds (317k) of slag (a lava-like material reclaimed for sale to the construction industry) and six tons (5.4t) of
gases are produced. And since part of the charge is always melting, voids are created that have to be refilled constantly.
Meeting this voracious appetite is the job of the ore yard, where huge quantities of raw materials arrive by boat (ore carriers,
despite their size, are known as "boats" on the Great Lakes) and rail. Materials are transported from here to the furnaces in older
open hopper cars and ore jennies on an elevated stretch of two or three parallel tracks known as the "highline." Running behind
the furnace, the tracks span storage bins where coke, scale, scrap, dolomite, ore and limestone are kept ready.
Raw materials for the charge (or burden) enter the furnace through the top via conveyors at newer facilities, or in a pair of
wheeled carts called skip cars fed by a bridge crane, that constantly ride up and down on steeply pitched rails. As one skip
loads, the other is emptied at the top.
The "blast" in a blast furnace comes from the blowing engine house; here giant air compressors pressurize the cold blast main,
a huge pipe feeding air into three or more heated and refractory-lined stoves to raise the temperature to 1800°F (982.2°C). This
superheated air is fed under pressure into the furnaces via a bigger pipe known as the hot blast main. So there's a constant
supply of air available, the process rotates through each stove with one on blast, one heating and one on standby.
Once combustion begins, the hot air blast forces the coke in the charge to burn faster producing more heat, and large amounts
of carbon monoxide and other reducing gases that are also burned. For each ton of iron, there may be 100 to 300 pounds (100-
136k) of flue dust suspended in this gas, which is rich in iron and coke particles and reclaimed for use. This begins at the top of
the furnace, where four offtakes resembling huge upside down slingshots converge into a single downcomer. This feeds gas
into a dust catcher, capturing large dry particles like a vacuum cleaner in a holding bin. The gas then passes through sprays of
water inside a gas washer and a precipitator to capture progressively smaller particles, with the resulting slurry pumped to a
settling operation, where solids settle to the bottom. From here, the dust and slurry are sent to a sintering plant (dust in old
covered hoppers, slurry via pipelines) where it's pressed into large pellets that are sent back to the furnaces.
The heart of the furnace is the hearth at the bottom, where molten iron and slag collect. Two or three hours before the iron is
tapped, slag is drawn off. More will be removed about an hour before the cast, and the balance is tapped with the iron. When
the iron is ready, a clay plug in the bottom of the hearth is drilled open. Molten iron then flows into a refractory-lined iron runner
on the floor of the cast house, essentially a large covered platform with open sides and ends to dissipate heat, and into smaller
runners loading hot metal cars for the trip to the converters, where the impurities will be burned out to create molten steel, or
slag cars which dump their loads in an open pit some distance away.
The centerpiece of your steel works, you can easily model a complete operation with the Blowing Engine House with Piping
Extensions (#933-4602), along with the WalthersProto® Hot Metal Bottle Car 2-Packs (#920-107900 Gray or #920-107901
Rust) and Slag Car 2-Packs (#920-1079010 Gray or #920-107911 Rust) and Bridge Crane (#933-2906). For more models,
photos and information on Walthers Steel Series, visit your participating hobby shop, see the latest Walthers Model Railroad
Reference Book or visit us online at walthers/products/steel-series.
PLEASE NOTE: As individual part numbers are molded on a sprue that has been trimmed , please
refer to the illustrations to properly identify parts.
© 2020 Wm. K. Walthers, Inc., Milwaukee, WI 53218 waltherscornerstone.com I-933-4602 Printed In China
