- Page 1 Instruction Manual for Pro Frame X Series MODELS: PRO-1S-***, PRO-1V-*** Thank you for purchasing a Severtson projection screen. Before use, please read the instructions carefully. After installation, store the instructions for future reference. Rev 181030...
-
Page 2: Parts Included
Instruction Manual for Pro Frame X Series Parts Included... -
Page 3: Installation Instructions
Instruction Manual for Pro Frame X Series Installation Instructions Take out all the parts from the packaging and verify that all the parts have been included, then follow the steps below to install the screen. Note 1.1: Do not unroll the screen material until Step 4. - Page 4 6. Now slide in a pin on the top and bottom frame pieces (bottom frame piece is labeled by the Severtson logo) on each end for the corner grommets. This will be a total of four more pins, one for each corner. There should be enough pins in the frame track to match the number of grommets on the screen material.
- Page 5 Instruction Manual for Pro Frame X Series 8. Before tightening the four corner bolts, slide the corner pins (previously placed in the track) into the corner as shown (Fig. 4). Once the pin is slid as far as it can go into the corner, tighten the bolt.
- Page 6 Instruction Manual for Pro Frame X Series [Figure 5]...
- Page 7 You will have to disconnect a few grommets from the pins to attach the brackets directly onto the frame. Later, the screen material will cover the brackets. Note 10.1: The bottom frame piece will be labeled with the Severtson logo. [Figure 6] 11.
- Page 8 Instruction Manual for Pro Frame X Series [Figure 7] 12. Secure the bottom wall brackets to the wall using the correct wall fasteners for your wall. The lower brackets should be placed 1/8” less than the overall height of the frame from the top wall brackets (Fig.
- Page 9 Instruction Manual for Pro Frame X Series Warnings 1. The frame is made with lightweight aluminum. Please handle with care. 2. Make sure the fasteners used are firmly secured to the wall to avoid any damage. 3. When installing the screen material onto the frame, make sure it is facing forward (viewing side toward the projector).
