- Page 1 MODELS: TF43***,TF169***, TF1610***, TF235*** Thank you for purchasing a Severtson projection screen. Before use, please read the instructions carefully. After installation, store the instructions for future reference. Rev 190410...
- Page 2 Instruction Manual for 4K Thin Bezel Series Fixed Frame Overview Parts Included 1 ...
-
Page 3: Installation Instructions
Instruction Manual for 4K Thin Bezel Series Fixed Frame Installation Instructions Take out all the parts from the packaging and verify that all the parts have been included. Then follow the steps below to install the screen. 1. - Page 4 Instruction Manual for 4K Thin Bezel Series Fixed Frame [Figure 2.1] [Figure 2.2] [Figure 2.3] 3. Install the large and small corner bracket screws ( F ig. 3.1 ) and leave them slightly loose. Verify that all of the frame corners are tight and square and make an necessary adjustments.
- Page 5 Instruction Manual for 4K Thin Bezel Series Fixed Frame 4. Insert one end of the support bar into the proper track on the frame ( F ig. 4.1 ) . With one end of the support bar in place, slide the other end of the bar left or right until the angle allows for the end of the bar to slide into the track.
- Page 6 Instruction Manual for 4K Thin Bezel Series Fixed Frame [Figure 6.1] [Figure 6.2] [Figure 6.3] Note 6.3: F or acoustically-transparent screen materials, please see A ppendix A: Black Backing ...
- Page 7 Instruction Manual for 4K Thin Bezel Series Fixed Frame attached corner notches, work toward the center of the frame until the entire screen is tensioned and secured evenly to the frame at all of the plastic lugs ( F ig. 7.3 ) . ...
- Page 8 Instruction Manual for 4K Thin Bezel Series Fixed Frame [Figure 8.1] [Figure 8.2] Note 8.1: I f some of the frame bezel pieces get attached incorrectly please see A ppendix B: Bezel ...
- Page 9 Instruction Manual for 4K Thin Bezel Series Fixed Frame [Figure 9.1] [Figure 9.2] 8 ...
- Page 10 Instruction Manual for 4K Thin Bezel Series Fixed Frame Table 9.1: Horizontal Bracket Spacing Distance Frame Width (B) 16” Stud Bracket Spacing (C) 24” Stud Bracket Spacing (C) Less than 90” 48” 48” 90” to 110” 64” 72” 110” to 135” 80” ...
- Page 11 Instruction Manual for 4K Thin Bezel Series Fixed Frame [Figure 11.1] 12. Hang the screen onto the upper brackets, fitting the upper edge of the bracket into the correct track on the frame ( F ig. 12.1 ) . Then let the screen hang vertically. The back of the lower frame rail should rest against the lower brackets.
-
Page 12: Appendix A: Black-Backing Instructions
Follow these instructions to properly secure the included black backing to a Severtson Screens Fixed Frame Projection Screen. This guide applies to all 4K Thin Bezel Series Fixed Frame models. This guide is intended to be followed after the frame has been assembled and the tension rods ... - Page 13 Instruction Manual for 4K Thin Bezel Series Fixed Frame backing material until the bunched up material smooths out, then proceed with the rest of the assembly and installation. [Figure A.2] 12 ...
-
Page 14: Appendix B: Bezel Removal Instructions
Follow these instructions to properly remove the frame bezel pieces of a Severtson Screens 4K Thin Bezel Series Fixed Frame model projection screen. This may be necessary during the projection screen assembly if a bezel piece was attached incorrectly and needs to be removed ... - Page 15 Instruction Manual for 4K Thin Bezel Series Fixed Frame 2. Lift up the bezel piece and remove. Start on one side of the bezel and insert two flathead screwdrivers at an angle between the bezel removal tab and the extrusion on the frame rail.
- Page 16 Instruction Manual for 4K Thin Bezel Series Fixed Frame Warnings 1. The frame is made with lightweight aluminum. Please handle with care. 2. Make sure the fasteners used are firmly secured to the wall to avoid any damage. 3.
