Instruction Manual for
Cinema & Tension Deluxe Series Electric
MODELS: GE43***, GE169***, GE1610***, GT43***, GT169***, GT1610***
Thank you for purchasing a Severtson projection screen. Before use, please read the instructions
carefully. After installation, store the instructions for future reference.
Rev 191205
Advertisement
Table of Contents
Related Manuals for Severtson Cinema Series
Summary of Contents for Severtson Cinema Series
- Page 1 MODELS: GE43***, GE169***, GE1610***, GT43***, GT169***, GT1610*** Thank you for purchasing a Severtson projection screen. Before use, please read the instructions carefully. After installation, store the instructions for future reference. Rev 191205...
- Page 2 Instruction Manual for Cinema & Tension Deluxe Series Electric Overview Parts Included 1 ...
-
Page 3: Installation Instructions
Instruction Manual for Cinema & Tension Deluxe Series Electric Installation Instructions Take out all the parts from the packaging and verify that all the parts have been included, then follow the steps below to install the screen. Note 1.1: ... - Page 4 Instruction Manual for Cinema & Tension Deluxe Series Electric Concrete Ceiling Use an electric drill to drill four holes for each bracket and hammer the provided tapping anchors into each hole. Secure the brackets onto the ceiling by fastening the tapping screws (5x40mm) to the tapping ...
- Page 5 Instruction Manual for Cinema & Tension Deluxe Series Electric 4. Now place the screen on the baffle hooks making sure they latch onto the screen casing. Then tighten the fixing screws on the bottom of each bracket to lock the screen onto the brackets. ...
-
Page 6: Controlling The Screen
Instruction Manual for Cinema & Tension Deluxe Series Electric Controlling the Screen There are many different options included to control the projection screen. Only connect the screen to the options that will be used. R S-232 Pinouts ... - Page 7 Instruction Manual for Cinema & Tension Deluxe Series Electric 1. Trigger Connection. The trigger jack recognizes outputs of DC 5V-12V. When power is sensed the screen will automatically lower. When power is off the screen will rise back into the case. ...
-
Page 8: Appendix A: Adjusting The Screen Limits
Improperly adjusting the limits of the motor will cause damage to the screen and motor and will void all warranty. Severtson Screens is not responsible for any damage caused by adjusting limits for any reason. ... - Page 9 Instruction Manual for Cinema & Tension Deluxe Series Electric b. Press “up” on the remote control. c. If the screen does not fully ascend into the case use the accessory tool to adjust the up limit. Turn the Up limit towards the “+” symbol until the screen is at the desired position. ...
-
Page 10: Appendix B: Adjusting The Screen Tension
Instruction Manual for Cinema & Tension Deluxe Series Electric Appendix B: Adjusting the Screen Tension This section is only for applicable models ( t ab-tensioned models beginning with “GT” ) . The tension of the screen may need to be adjusted occasionally if the screen begins to appear wavy. ... -
Page 11: Appendix C: Troubleshooting The Screen
Appendix C: Troubleshooting the Screen The Cinema Series and Tension Deluxe Series screens are designed for many years of use. Problems are usually simple to resolve and caused by small issues or improper end use. If problems persist, please contact us. ... - Page 12 Instruction Manual for Cinema & Tension Deluxe Series Electric Warnings 1. Do not attempt to take apart or modify the screen. If any problems occur please contact your local dealer. 2. The screen is designed to be transported, stored, and operated in the horizontal position. Do not stand the screen up on its end vertically for any extended period of time. ...
