Summary of Contents for OETIKER SMART
- Page 1 Instruction manual SMART (Sensor Monitored Assembly Repair Tool) Part no. 08906644 OETIKER Schweiz AG Model no. MY23 Spätzstrasse 11 Issue: 2311_V00_b CH-8810 Horgen Schweiz...
-
Page 2: Structure And Description
SMART Structure and deScription Structure and description The SMART pincer consists of: Switch button Handles protective cap Handle grip Battery Shrink hose (only SaFt LS14500 3.6V) pincer jaws Battery container cover clamping zone carrier Force indicator (Led) Qr-code «register / manuals»... -
Page 3: Intended Use
Failure to follow this recommended behavior could cause disruptions and/or loss of production. • the SMart pincer conforms to the ‘state of the art’ and is safe. it can give rise to residual dangers if it is used and operated by untrained personnel. - Page 4 Working WitH tHe SMart pincer Working with the SMART pincer 3.1 Register the tool it is highly recommended to register the tool to get connected with oetiker by scanning the Qr-code (13) on the handle. 3.2 Power ON the closing force is regulated by pressing the button to switch different closing forces.
-
Page 5: Closing Operation
Hazards due to operation by unauthorized or unqualified personnel. 1. grab the ear of an oetiker ear clamp into the clamping zone (5) between the pincer jaws (4). 2. Squeeze the handles of the pincer together to close the ear. once the target force is achieved, the Led (6) and vibrator will be triggered. -
Page 6: Low Power Indication
SMART Working WitH tHe SMart pincer 3.5 Turning off pincer press the switch button (8) for 2 seconds and all Leds lightened up and then ex- tinguished from top to bottom. pincer will be turned off automatically if no operations for 5 minutes. -
Page 7: Changing The Battery
SMART Working WitH tHe SMart pincer 3.7 Changing the battery CAUTION When closing the pincer jaws (4), fingers can be crushed! Never insert a finger into the clamping zone (5) of the manual pincer! 1. Slide out the protective cap from battery housing (9). -
Page 8: Troubleshooting And Error Messages
(including warranties of merchantability, fitness for a particular purpose or non-in- fringement of intellectual property rights). neither oetiker nor any of its officers, employees or agents will accept any re- sponsibility or liability with respect to the adequacy, accuracy, completeness or...
