UPX & DIGITAL VIDEO PROCESSORS
The DVPHD-PRO is an advanced multi-window digital video
processor and touchpanel interface. Ideal for videoconference
rooms, lecture halls and training labs, command centers,
operating rooms, ground and air traffic control, security and
surveillance, public information, houses of worship, home
theater, sports bars, and all kinds of entertainment venues,
the DVPHD-PRO combines a unique set of features to deliver
a dramatic and versatile presentation solution. Out-of-the-box
functionality means the DVPHD-PRO can be used standalone
or as part of a complete Crestron control system.
Multi-Window Video Processor—The DVPHD-PRO
displays up to 8 simultaneous video windows on a single
high-resolution monitor, projector, or flat panel display. Its
4 multi-format video inputs and 4 high-res DVI-I inputs each
route to a dedicated video window1 onscreen. These video
windows can be displayed together in any combination over
a fully-customizable graphic background. Each window is
fully-scalable and independently controllable, allowing for
display at any position, size, or aspect ratio.
Multi-Format Support—The 4 DVI-I inputs support high-
resolution digital DVI and HDMI sources with HDCP, as well
as analog RGB and component sources, with resolutions
up to 1920 x 1200 pixels. The 4 video inputs accept HDTV/
component sources up to 1080p, as well as NTSC/PAL
composite and S-Video signals. Auto-detection on every input
configures the DVPHD-PRO automatically to match the input
signals. DVI-I and QuickMedia outputs provide a choice of
digital or analog signals to feed a non-interlaced RGB, DVI,
or HDMI display.
2
Pure Digital HD Video—A 100% digital backplane means
the DVPHD-PRO's internal signal is never degraded by noise,
and its DVI digital inputs and output ensure a pure digital
signal throughout. DVI affords simplified connectivity through
a single-cable interface that combines uncompressed digital
high-definition video with intelligent format and command
data. The DVI-I format employed on the DVPHD-PRO
supports the choice of digital or analog signals through a
single connector. EDID information on the digital output
affords easy and reliable setup when connected to an
EDID-compliant display.
100% HDCP Compliance—Advanced HDCP implementation
ensures compliance with a complete range of digital video
players, cable and satellite receivers, multimedia computers,
displays, and projectors. The DVPHD-PRO can manage 4
separate HDCP input connections from DVI or HDMI sources,
and generate a new HDCP-encrypted output combining
any of the inputs. The authentication key from the connected
display device is passed back to each source to enable
full high-definition display of copy-protected content.
www.crestron.com
|
800.237.2041
© 2007 Specifications subject to change without notice
Digital Video Processors
8X1 High-Definition Digital Video Processor
|
201.767.3400
Advanced Image Processing—Whether displaying a
single full-screen image, or several windows with graphics,
the DVPHD-PRO scales the output signal perfectly to match
the native resolution of your high-definition display, supporting
any aspect ratio with output resolutions up to 1920 x 1200
pixels. Featuring Gennum's Visual Excellence Processing™
with TruMotionHD™ fully adaptive deinterlacing, the DVPHD-
PRO achieves exceptional image sharpness and resolution
from SDTV, HDTV, and computer sources. RealityExpansion™
10-bit image processing employing FidelityEngine™ image
enhancement delivers astounding realism and detail.
FineEdge™ dynamic directional interpolation eliminates the
jaggy artifacts typical of traditional deinterlacing algorithms.
Isys
®
Graphics—The DVPHD-PRO includes Crestron's
24-bit Isys graphics engine, allowing for the creation of
stunning graphics, high-res images, dynamic text, multi-
mode objects, and full-motion animations. Advanced
antialiasing delivers crisp, sharp objects and text, while
enhanced 3D effects add alluring depth and style. The
position and appearance of the video windows within the
graphical environment can be fully customized with the
ability to apply digital transition effects for a dynamic look
and feel.
Touchpanel Interface—With both USB and RS-232
connections, the DVPHD-PRO can be used to transform
a third-party touchscreen monitor, pen display, whiteboard,
or touch-enabled plasma display into a full-featured, large-
scale Crestron touchpanel. This opens a host of possibilities
for special control and presentation applications such
as interactive kiosks, museum and tradeshow exhibits,
training rooms, and command centers. As an alternative to
touchscreen, its graphical interface can also be navigated
DVPHD-PRO
> continued
