True TDC-47 Specifications

2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl Fax# (001)636-272-7546
Parts Dept. (800)424-TRUE • Parts Dept. Fax# (636)272-9471 • www.truemfg.com
Model:
TDC-47
ROUGH-IN DATA
(Cu. Ft.)
Model Lids
(liters)
TDC-47 1 12.7
360
T R
RUE EFRIGERATION
TM
MADE IN
U.S.A. U.S.A. .S.A.
®
SINCE 1945
5/07
TRUE FOOD SERVICE
EQUIPMENT, INC.
Dipping Cabinet:
Freezer
Chart dimensions rounded up to the nearest
Cabinet Dimensions
Capacity
3 gal.
12 L
L
Cans Racks
1
12 4 47
1197
APPROVALS:
R
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
(inches)
(mm)
D H
HP
3 3 1
/ 27 / 51 / /
8 8 8 3
696 1305
Qty:
TDC-47
True's visual dipping cabinets are
uniquely designed to provide the
user maximum functional reliability
in an attractive merchandiser to
brilliantly display and serve ice cream
product.
Cold wall refrigeration system.
Maintains -10°F to +8°F (-23.3°C to
-13.3°C).
Exclusive, reverse condensing fan
motor reduces maintenance costs
and optimizes cabinet performance.
Heavy-duty, PVC coated wire can
support racks. Positions the open
ice cream containers on top level to
optimum service height. Lower level
provides for extra can storage.
Designed to hold eight (8) 9
mm) diameter, 3 gallon (12 L) ice
cream containers in display area and
four (4) on fl oor beneath support
racks.
Eight (8) removable, molded
plastic can skirts for 9
diameter, 3 gallon (12 L) cans. Firmly
holds cans in place and provides
attractive, neat appearance.
White, 6" (153 mm) wide, NSF
approved, removable magnetic
frost shields. Provides for easy clean
up and removal of ice build-up on
cabinet walls.
Two (2) white plastic night covers for
case opening.
Entire cabinet structure is foamed-
in-place using high density, CFC free,
polyurethane insulation.
Specifi cations subject to change without notice.
1
/ " (millimeters rounded up to next whole
8
NEMA
Voltage Amps Confi g.
115/60/1 6.7 5-15P
AVAILABLE AT:
AIA #
SIS #
1
/ " (242
2
1
/ " (242 mm)
2
number).
Cord Crated
Length Weight
(total ft.) (lbs.)
(total m) (kg)
9 n/a
2.74
