mitty dairy MAD DOG TMDK-1PS GM Assembly Instructions

Milking machine

Your machine is now ready for use. Please

proceed with the manual "HOW TO START

MILKING FOR THE FIRST TIME."

The gasoline engine uses

motor oil SF 10W-30.

The vacuum pump is dry and works with graphite pallets, or

vanes, that you will have to replace every 8 or 10 months

with normal usage of the machine (1-2 times per day). It is

important to clean your machine before using it. You can go

to our YouTube Channel, Mitty Supply, and watch the vid-

eo on how to clean and disinfect your machine prior to use.

Please follow the instructions in the MAD DOG User Manual

(pages 22-24) to operate the gas motor on your machine.

**THIS MACHINE DOES NOT HAVE A BELT OR A

BELT TENSION BOLT.**

Assembly Instructions

For Your Milking

Machine

Model:

MAD DOG

TMDK-1PS GM

315 E. Banks St Glennville, GA 30427

Tel: (912) 339-0173
