Extel XB250 Manual

XB250
EN
ELECTRIC GATE
V1
OPENER KIT
For 2-panel swing gates
Ref. 761005
Thank you for purchasing an EXTEL automatic gate opener.
This document is a quick start guide detailing the main installation steps as well as the equipment required. To perform the installation, please
download the installation manual at the following address:
Warning: The safety instructions and installation instructions can be found in the installation manual. Follow all these instructions, as an as
incorrect installation can cause serious injuries.
1. DESCRIPTION
1 2 3
x 2 x 2 x 1
11 11 11 11
x 1 x 6 x 6
1
Motor lock screws
2
Post mounting bracket
3
Main motor with electronic card
4
Secondary motor
Screws for attaching the rear arm to the
5
motor
6
Rear arm
7
Pin
8
Pin axis
2. EQUIPMENT REQUIRED (NOT SUPPLIED)
The tools and screws required for the installation must be in good condition and compliant with applicable safety standards.
Please use screws compatible with the bracket to which the motors will be attached (e.g. anchor studs, threaded rod with chemical seal, etc.)
Flashing light
3m cable
2 x 0.5mm
www.avidsen.com
4 5
x 1 x 2
12 12 12
x 4 x 1 x 2
9
Front arm
10
Gate mounting bracket
11
Photocells and screws
12
Flashing light and screws
13
Remote controls
14
Override key
15
Installation template
16
Accessories for the solar kit
17
Backup fuses
1 fl at head screwdriver
1 drill 1 Phillips screwdriver
Motor Photocells
8m cable 10m cable
2 x 1.5mm 4 x 6/10
2 2
6 7
x 2 x 4
8
x 4
13
x 2 x 2
1 pencil 1 x 13mm spanner
1 spirit level
1 measuring tape
Attaching the
Attaching the motors
onto the posts
brackets
on the gate:
Choose a screw/nut
system compatible
with the thickness of
the gate. There are 4
attachment points
9
x 2
14 15
x 1 x 1
16 17
x 1 x 1
10
x 2
