Summary of Contents for Telit Wireless Solutions Cinterion LGA DevKit Things
- Page 1 Cinterion LGA DevKit Things User Guide Rev. 0 v. 02 2023-9-25 Released Confidential Technical Documentation...
-
Page 2: Table Of Contents
Cinterion LGA DevKit Things User Guide Contents Contents............................2 Tables ............................... 4 Figures.............................. 5 Applicability Table ........................6 Introduction..........................7 2.1 Scope .............................. 7 2.2 Features and Benefits ......................... 7 2.3 Audience ............................8 2.4 Contact Information, Support ....................8 2.5 Conventions .......................... - Page 3 Cinterion LGA DevKit Things User Guide 8.1 Revision History .......................... 31 8.2 Related Documents ........................31 8.3 Safety Precaution Notes ......................31 8.4 Regulatory Compliance Information ..................32 Appendix..........................33 9.1 LGA DevKit T ..........................33 9.1.1 Placement ........................33 1VV123456 Rev.
-
Page 4: Tables
Cinterion LGA DevKit Things User Guide Tables Table 1: Applicability table ........................ 6 Table 2: Absolute maximum ratings..................... 23 Table 3: Operating and environmental conditions..............23 1VV123456 Rev. 0 Page 4 of 38 2023-9-25... -
Page 5: Figures
Cinterion LGA DevKit Things User Guide Figures Figure 1: LGA DevKit SM package content ................... 10 Figure 2: LGA DevKit socket SML with LGA DevKit variants SM and L........11 Figure 3: LGA DevKit SM top view ....................14 Figure 4: LGA DevKit SM underside view..................14 Figure 5: LGA DevKit block diagram.................... -
Page 6: Applicability Table
Cinterion LGA DevKit Things User Guide Applicability Table Table 1: Applicability table LGA DevKit SM LGA DevKit L A (LGA 68) B (LGA 112) C (LGA 140) For future use TX62-W For future use 1VV123456 Rev. 0 Page 6 of 38... -
Page 7: Introduction
Cinterion LGA DevKit Things User Guide Introduction Scope The Cinterion LGA DevKit is designed as a generic development adapter for Cinterion® ® LGA modules. With the LGA DevKit it is no longer necessary to connect the Cinterion® eval- uation modules to an adapter for test and development purposes. -
Page 8: Audience
Cinterion LGA DevKit Things User Guide Audience This document is intended for system integrators that are using the LGA adapter for their modules. Contact Information, Support For technical support and general questions, e-mail: • TS-EMEA@telit.com • TS-AMERICAS@telit.com • TS-APAC@telit.com •... -
Page 9: Terms And Conditions
Cinterion LGA DevKit Things User Guide Terms and Conditions Refer to https://www.telit.com/hardware-terms-conditions/. Disclaimer THE MATERIAL IN THIS DOCUMENT IS FOR INFORMATIONAL PURPOSES ONLY. TELIT CIN- TERION RESERVES THE RIGHT TO MAKE CHANGES TO THE PRODUCTS DESCRIBED HEREIN. THE SPECIFICATIONS IN THIS DOCUMENT ARE SUBJECT TO CHANGE AT THE DISCRETION OF TELIT CINTERION WITHOUT PRIOR NOTICE. -
Page 10: Package Content
Cinterion LGA DevKit Things User Guide Package Content The following package is available for the LGA DevKit. The LGA DevKit T is used with the LGA DevKit socket T: • Cinterion LGA DevKit T (Ordering number: L30960-N0113-A100) ® • Base PCB for the IoT platform (Things) modules •... -
Page 11: Figure 2: Lga Devkit Socket Sml With Lga Devkit Variants Sm And L
Cinterion LGA DevKit Things User Guide Cinterion ® LGA DevKit socket T (L30960-N0114-A100) LGA112 Figure 2: LGA DevKit socket SML with LGA DevKit variants SM and L 1VV123456 Rev. 0 Page 11 of 38 2023-9-25... -
Page 12: Quickstart
Cinterion LGA DevKit Things User Guide Quickstart Please complete the following steps to quickly get started with your LGA DevKit. • Mount the LGA DevKit socket onto the LGA DevKit (for details see Section 2.10). • Insert the fixing frame and then the module into the socket and close the retention lid by pressing it down and turning it clockwise. -
Page 13: 2.10 Mounting The Lga Devkit Socket
Cinterion LGA DevKit Things User Guide 2.10 Mounting the LGA DevKit Socket Before operating, the socket has to be mounted onto the LGA DevKit with 4 screws. Scanning the QR code on the DevKit's under- side and/or the quick start guide will lead you to the DevKit's web home where you find a short introduction and video on how to do this. -
Page 14: Lga Devikit Overview
Cinterion LGA DevKit Things User Guide LGA DeviKit Overview Top and Underside View Figure 3 Figure 4 show the top and bottom view of the of the LGA DevKit T variant. Error LED Configurable & interruptible signals Activity LED USB VCP & PWR... -
Page 15: Block Diagram
Cinterion LGA DevKit Things User Guide Block Diagram Native Micro USB Data Left side: Right side: Module Pins Peripherals Combinded Powering Module Signals RF Main/ DRX On board ASC0 Micro Antenna Connector Connector Connector Jumper Status LEDS Signal Jumpers ASC0... -
Page 16: Lga Devkit Interfaces
Cinterion LGA DevKit Things User Guide LGA DevKit Interfaces The LGA DevKit comes with two USB interfaces supporting power supply and serial com- munication. You may choose to setup communication via a module's USB port and/or a module's UART (ASC0) port via FTDI232R VCP. -
Page 17: Pin Headers
Cinterion LGA DevKit Things User Guide Figure 6: SIM interfaces and switch Pin Headers The pin headers at the top side can be used to setup connections between modules and possible on board peripherals. Thus, pin headers having signal names at their left side only, namely the pin headers CONTROL, ASC0_A, ASC0_B, DAI, ASC1, and GPIO, can be bridged by jumpers. -
Page 18: Default Configuration
Cinterion LGA DevKit Things User Guide 4.3.1 Default Configuration Figure 8 shows the factory default jumper and switch positioning. Control & ASC0 3x Jumper Figure 8: Default jumper and switch configuration Please also verify that the SIM switch at the underside is set to default "CCIO Pullup dis- abled". -
Page 19: Asc0 Switch: Module Uart Interface Selection
Cinterion LGA DevKit Things User Guide ASC0 Switch: Module UART Interface Selection The "ASC0" switch selects the module's UART communication interface either via USB VCP (FTDI232R) or via "RS232" D-Sub interface on the DSB75/DSB-Mini. Changing this from "USB" to "RS232" during operation resets the FTDI VCP bridge in order to release the signal lines, thus leading to a USB VCP disconnect on the host PC side. -
Page 20: Leds
Cinterion LGA DevKit Things User Guide LEDs The LGA DevKit LEDs have the following meaning: Meaning Blinking continuously: Module is inserted wrongly oriented, not powered, turn by 180° Blinking 2 times: No module inserted, not powered Blinking 3 times: A module not supported by footprint is inserted, not powered, change... -
Page 21: 4.11 Power Supply
Cinterion LGA DevKit Things User Guide 4.11 Power Supply The LGA DevKit can be supplied through one or two USB ports that should be in the range of 5V +-5%, and/or externally by the DSB75/DSB-Mini. The modules supply level can be ad- justed in the range between 2.8…4.8V by setting the variable resistor at the DevKit's top... -
Page 22: External Reference Supply
Cinterion LGA DevKit Things User Guide Note: When measuring with a current meter, the meter’s internal resistance may cause a high voltage drop, forcing the module to shut down. This can be avoided by measuring the voltage cross the shunt. The current option is suitable for specialist power meter supplies, whereas the voltage option is suitable for common voltage meters. -
Page 23: General Characteristics
Cinterion LGA DevKit Things User Guide General Characteristics The following table lists absolute maximum ratings for the LGA DevKit. Please note that vi- olation of these limits may cause permanent damage to the LGA DevKit. Table 2: Absolute maximum ratings... -
Page 24: Operating The Lga Devkit With A Dsb
Cinterion LGA DevKit Things User Guide Operating the LGA DevKit with a DSB LGA DevKit on DSB-Mini The LGA DevKit supports a 2x40pin connector at its underside, compatible to the DSB75/ DSB-Mini. A DSB may be a port extender for an RS232 interface, a second SIM or an analog audio interface. -
Page 25: Lga Devkit On Dsb75
Cinterion LGA DevKit Things User Guide LGA DevKit on DSB75 To operate the LGA DevKit with the DSB75 please complete the following steps: • Mount the LGA DevKit onto the DSB75. • Insert the module. • Set "PWR" and "ASC0". -
Page 26: Lga Devkit Firmware Update
Cinterion LGA DevKit Things User Guide LGA DevKit Firmware Update The Cinterion LGA DevKit features an internal processing unit that operates the LGA ® DevKit as well as the mounted modules - to for instance prevent damage when a module is inserted wrongly. -
Page 27: Setup Terminal Program
Cinterion LGA DevKit Things User Guide Setup Terminal Program The second step configures a terminal program to connect to the LGA DevKit. Open a ter- minal program (the below example uses ZOC and Tera Term). The following terminal settings are required: •... -
Page 28: Open Connection And Version Check
Cinterion LGA DevKit Things User Guide Open Connection and Version Check The third step opens a connection to the Cinterion® LGA DevKit to check the current firm- ware version. Open the channel by clicking on "Save". Now, after powering on the LGA DevKit by simply connecting a USB cable the firmware ver- sion should be issued. -
Page 29: Figure 16: Copy Update *.Hex File
Cinterion LGA DevKit Things User Guide Figure 16: Copy update *.hex file • Paste the text/firmware into your ZOC or Tera Term terminal. Figure 17: Paste update *.hex file 1VV123456 Rev. 0 Page 29 of 38 2023-9-25... - Page 30 Cinterion LGA DevKit Things User Guide • Now, you can view the update progress over the connected interface. Finally, the out- put shows that the new firmware is booting up and displays the new firmware revi- sion string: … more lines in between…...
-
Page 31: Document History
Cinterion LGA DevKit Things User Guide Document History Revision History Preceding document: "Cinterion LGA DevKit User Guide" v01 ® New document: "Cinterion LGA DevKit User Guide" v02 ® Chapter What is new New chapter LGA DevKit Firmware Update. New document: "Cinterion LGA DevKit User Guide"... -
Page 32: Regulatory Compliance Information
Cinterion LGA DevKit Things User Guide Regulatory Compliance Information The Cinterion LGA DevKit is intended for evaluation and development purposes only, and ® should therefore only be used in a (laboratory) test environment. The device is not CE ap- proved, and has not been authorized as required by the rules of the FCC. All persons han-... -
Page 33: Appendix
Cinterion LGA DevKit Things User Guide Appendix LGA DevKit T 9.1.1 Placement CON11 CON14 CON9 CON13 CON12 CON7 CON10 LED2 CON18 LED6 CON17 BTN1 BTN2 LED9 LED4 LED5 LED3 LED1 Top view Underside view Figure 18: op and underside placements (LGA DevKit SM) 1VV123456 Rev. - Page 34 Cinterion LGA DevKit Things User Guide MULTI_ADAPTER_TX62_TX82_STEP1_np MULTI_ADAPTER_TX62_TX82_STEP1_PATCHFIELD_np TX62 TX62 VUSB_MODULE 200R VUSB RF_OUT VUSB VUSB/3.?? ANT_MAIN/2.?? VUSB_MODULE BOARD.D+/3.?? USB_DP GNSS_ANT ANT_GPS/2.?? T22A USB_DN AUX_ANT BOARD.D-/3.?? ANT_DRX/2.?? NX3008NBKS PULL_VUSB/2.?? ON_MODULE/4.?? V180 VEXT_MODULE/2.?? ON_MODULE/4.?? V180 VEXT_MODULE/2.?? EMERG_RST EMERG_RST EMG_RST/4.?? EMG_RST/4.?? VCORE VCORE/4.??
- Page 35 Cinterion LGA DevKit Things User Guide MICROCONTROLLER SMA + U.FL CONNECTORS 18pF 18pF IC9A ANT_MAIN/1.?? TP10 /RST_PCIN14_C6 SCK_PCIN5_B5 100k RESET@UC MISO_PCIN4_B4 MOSI_PCIN3_B3 +3V3/4.?? CON2 SS_OC1B_PCIN2_B2 ON_BUTTON 73251-1150 OC1A_PCIN1_B1 ON/4.?? RESET@UC 18pF 18pF ICP1_CLKO_PCIN0_B0 R100 ANT_GPS/1.?? XTAL1_TOSC1_PCIN6_B6 +3V3/4.?? CON6 CON3 XTAL2_TOSC2_PCIN7_B7...
- Page 36 Cinterion LGA DevKit Things User Guide TC1014-3.0VCT713 LDO BATT+ GPS PWR LDO +3V BATT+: 2.8V - 4.86V TP68 EXTERN_REFERENCE/2.?? V480 VOUT BATT+/4.?? ANT_GPS_PWR/2.?? T14A BATT+/4.?? ISL80103 TP81 IC10 TP64 TP65 LDO_OUT/4.?? EN_BATT+/2.?? EN/UVLO NX3008PBKS DVDT ERROR_LED_OD V480/2.?? X100.BATT+ T14B IC20...
- Page 37 Cinterion LGA DevKit Things User Guide LEVEL SHIFTER ASC0.1 PINHEADER 80 PIN INTERFACE Control CON7 IC14 EEPROM VREF/3.?? VCC-A VCC-B VEXT_BUFF/3.?? ON/2.?? ON_MODULE/1.?? RXD0_X100/3.?? RXD0@LS EMERG_RST_X100/2.?? EMG_RST/1.?? CTS0_X100/3.?? CTS0@LS VEXT_JUMPER/3.?? VEXT_MODULE/2.?? CCIN_X100/2.?? CCIN/1.?? DAC_OUT_X100 DAC_OUT ADC1_IN ADC1_IN_X100 PW R_IND ADC2_IN...
- Page 38 © Telit 2023 All rights reserved. Technical Documentation...
