Telit Wireless Solutions WE310G4-I/P Quick Start Manual

WE310G4-I/P
Quick Start Guide
1VV0301775 Rev. 0 – 2022 -03 -31

Program the WE310G4 Module

1. Connect the micro-USB UART1 port to your system.
2. Change the toggle switch position to Program.
3. Download and unzip the Telit_Wifi_Image_Tool. For download information, see
4. Open the Telit_Wifi_Image_Tool folder.
5. Open the Telit_Wifi_Image_Tool application.
6. Click Browse.
7. Navigate to the Telit_Wifi_Image_Tool and select s2w.bin file.
8. To initiate the flash, click Program.
9. After the flash process is complete, click OK.
10. Close the Telit_Wifi_Image_Tool.
The WE310G4 EVB is ready to configure.

Configure the WE310G4 Module

1. Connect the micro-USB cable to the UART0 port.
2. Change the toggle switch position to Run.
3. Open Tera Term > Setup > Serial Port.
4. Set the BAUD rate.
The WE310G4 EVB is ready to use.
Wireless Mode- Station Mode
1. To set the module in Station Mode:
AT+WNI=0
2. To connect the network to L3: AT+WNCN=1,"Telit_WiFi","Password123",11
Wireless Mode- AP Mode
1. To set the module in AP Mode:
AT+WNI=1
2. To configure the IP:
AT+WNIPC=0,1,192.168.5.1,255.255.255.0,192.168.5.1
3. To configure the node in AP Mode:AT+WNAPIPC=0,192.168.5.3,192.168.5.20,86400000
Bluetooth Mode- Station Mode
1. To scan the available Bluetooth devices:
2. For DUT peripheral connection:
Device 1
AT&W0
AT+YSR
AT+BI=1
AT+BICAP=0
AT+BADVINTMIN=60
AT+BADVINTMAX=60
AT+BADVE=1
AT+BATTRIB="pserv","uuid=1234"
AT+BATTRIB="char","prop=0x0c","uuid=5678"
AT+BATTRIB="charval","perm=0011","len=1","val=0
x30"
AT+BATTRIB="complete"
AT+BOAD
AT+BI=1
AT+BCONINTMAX=1000
AT+BCONINTMIN=1000
AT+BCONNECT="00217E368'22","t2"
Resource
AT+BI=1
Links.
