- Page 1 BlueDev+S42M Development Kit User Guide 1VV0301524 Rev. 0 – 2018-04-09...
-
Page 2: Notice
BlueDev+S42M Development Kit User Guide SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE NOTICE While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein. -
Page 3: Usage And Disclosure Restrictions
BlueDev+S42M Development Kit User Guide USAGE AND DISCLOSURE RESTRICTIONS License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement. -
Page 4: Applicability Table
BlueDev+S42M Development Kit User Guide APPLICABILITY TABLE PRODUCTS BLUEDEV+S42M/AI3ATH 1VV0301524 Rev. 0 Page 4 of 21 2018-04-09... -
Page 5: Table Of Contents
BlueDev+S42M Development Kit User Guide CONTENTS NOTICE ..................... 2 COPYRIGHTS ....................2 COMPUTER SOFTWARE COPYRIGHTS ............2 USAGE AND DISCLOSURE RESTRICTIONS ..........3 APPLICABILITY TABLE ................4 CONTENTS ....................5 INTRODUCTION ................6 PACKAGE CONTENT ..............8 HARDWARE ................9 FLASH ERASE ................ -
Page 6: Introduction
BlueDev+S42M Development Kit User Guide INTRODUCTION 1.1. Scope This document describes the usage of the development kit for the Bluetooth module BlueMod+S42M together with the Realtek SDK. 1.2. Audience This document is intended for Telit customers, especially system integrators, about to implement Bluetooth modules in their application. - Page 7 BlueDev+S42M Development Kit User Guide 1.4. Text Conventions Danger – This information MUST be followed or catastrophic equipment failure or bodily injury may occur. Caution or Warning – Alerts the user to important points about integrating the module, if these points are not followed, the module and end user equipment may fail or malfunction.
-
Page 8: Package Content
BlueDev+S42M Development Kit User Guide 2. PACKAGE CONTENT The package content are described in [3] BlueEva+S42M Evaluation Kit User Guide. 1VV0301524 Rev. 0 Page 8 of 21 2018-04-09... -
Page 9: Hardware
BlueDev+S42M Development Kit User Guide HARDWARE Figure 1: BlueDev+S42M The BlueDev+S42M has in addition to the connectors are described in [3] BlueEva+S42M Evaluation Kit User Guide a Flash Erase and Log UART Connector. 1VV0301524 Rev. 0 Page 9 of 21... -
Page 10: Flash Erase
BlueDev+S42M Development Kit User Guide FLASH ERASE Please write down your Bluetooth address before starting earsing since Bluetooth address will be lost during erasing. For whole flash erase please place jumper X8 on the Erase Connector. Figure 2: Erase Flash BlueDev+S42M Make a reset of Module (by power on or pressing the reset button), remove the jumper and wait approx. -
Page 11: Realtek Bluetooth Mp Tool
BlueDev+S42M Development Kit User Guide REALTEK BLUETOOTH MP TOOL Preconditions: Connect the BlueDev+S42M via USB to a PC. Check the used COM port by using the Windows device manager. Please write down your Bluetooth address before starting earsing since Bluetooth address will be lost during erasing. - Page 12 BlueDev+S42M Development Kit User Guide Press the “Open” button to open the COM port the BlueDev+S42M is connected to. Figure 4: Realteks Bluetooth MP Tool 1VV0301524 Rev. 0 Page 12 of 21 2018-04-09...
- Page 13 BlueDev+S42M Development Kit User Guide Enable the checkboxes “Patch”, “APP” and “Config” in the “Erase” area and press the “Erase” button. Erasing will take some seconds. Figure 5: Realteks Bluetooth MP Tool 1VV0301524 Rev. 0 Page 13 of 21 2018-04-09...
- Page 14 BlueDev+S42M Development Kit User Guide After the software is erased successfully, the port is highlighted in green color. Figure 6: Realteks Bluetooth MP Tool Press the “Set” button, please check your Bluetooth address and press the “Confirm” button. Close the window.
-
Page 15: Troubleshooting
BlueDev+S42M Development Kit User Guide Press the “Download” button to download the software. Downloading will take some seconds. Figure 8: Realteks Bluetooth MP Tool After the download is finished successfully, close the BeeMpTool.exe. Reset the board by pressing the RES button. -
Page 16: Realtek Log Tool
As described in Realteks [4] RTL8762A SDK User Guide EN a Debug called Analyser.exe is provided by Realtek. Figure 9: BlueDev+S42M Log UART Connection The red marked pin is the TX pin of Log UART, it is connected to RX pin of UART-to-USB adapter as shown in Figure 10. - Page 17 BlueDev+S42M Development Kit User Guide Figure 10: BlueDev+S42M Log Uart FTDI-232R-3V3 Connection 1VV0301524 Rev. 0 Page 17 of 21 2018-04-09...
-
Page 18: Telit Sensor Demo For Realtek Sdk
BlueDev+S42M Development Kit User Guide TELIT SENSOR DEMO FOR REALTEK SDK As described in [4] RTL8762A SDK User Guide EN chapter 5 SDK Directory Structure the Board sub-directory contains project files. In addition to the Realtek original SDK Telit provides a TelitSensor3ATH demo project. The corresponding source code is included in Source sub-directory. -
Page 19: Glossary And Acronyms
BlueDev+S42M Development Kit User Guide GLOSSARY AND ACRONYMS Description TTSC Telit Technical Support Centre Universal Serial Bus High Speed Data Terminal Equipment UMTS Universal Mobile Telecommunication System WCDMA Wideband Code Division Multiple Access HSDPA High Speed Downlink Packet Access HSUPA... -
Page 20: Document History
BlueDev+S42M Development Kit User Guide DOCUMENT HISTORY Revision Date Changes 2018-04-09 First issue 1VV0301524 Rev. 0 Page 20 of 21 2018-04-09...
