  • Page 1 SL4640 Form No. 917001/ CP0905 SL4840 English SL5640 SL6640 Skid-Steer Loaders Operator’s Manual https://tractormanualz.com/...
  • Page 2 WRONG Gehl Company, in cooperation with the American Society of Agricultural Engineers and the Society of Automotive Engineers, has adopted this Safety Alert Symbol to pinpoint precautions which, if not properly followed, can create a safety hazard. When you see this symbol in this...

  • Page 3: Table Of Contents

    Index ........95 Loader Model Number Loader Serial Number Engine Serial Number All-Tach, Hydraloc and Hydraglide are trademarks of Gehl Company. Gehl and Powerview are registered trademarks of Gehl Company. https://tractormanualz.com/...
  • Page 4 Notes https://tractormanualz.com/...

  • Page 5: Introduction

    The Gehl dealership network stands ready to provide you with any assistance you may require, including providing genuine Gehl service parts. All service parts should be obtained from your Gehl dealer. Provide complete information about the part and include the model and serial numbers of your machine.
  • Page 6 ber. This will allow the registered owner information to be updated, so that the owner can be notified directly in case of an important product issue. 917001/CP0905 https://tractormanualz.com/...
  • Page 7 Loader Identification 1. Front Work Lights 5. Restraint Bar 2. Handholds 6. Lift Arm 3. Tilt Cylinders 7. Lift Cylinder 4. Hitch 8. Tires 1. Engine Cover 5. Roll-Over/Falling Object Protective Structure 2. Rear Work Lights (ROPS/FOPS) 3. Tail Lights 4.
  • Page 8 Control/Indicator Symbols Electrical Power Power Off Power On Engine Start Battery Charge Worklight w/Flasher Worklight Safety Alert Hazard Flasher Seatbelt Horn Read Operator’s Volume – Full Volume – Half Full Volume – Empty Manual High – Low Neutral Forward Reverse Parking Brake Engine Air Filter Engine Oil...

  • Page 9: Safety

    For further reference on the safe operation of skid-steer loaders, Gehl Company suggests that equipment owners obtain the Gehl “Skid-Steer Loader Safety” video, which is available through Gehl dealers. In addition, be sure that everyone who operates or works with this machine, whether family member or employee, is familiar with these safety precautions.
  • Page 10 To ensure safe operation, replace damaged or worn-out parts with genuine Gehl service parts. Gehl skid-steer loaders are designed and intended to be used only with Gehl attachments or approved referral attachments. Gehl cannot be responsible for operator safety if the loader is used with a non-approved attachment.
  • Page 11 During Operation Machine stability is affected by: the load being carried, the height of the load, machine speed, abrupt control movements and driving over uneven terrain. DISREGARDING ANY OF THESE FACTORS CAN CAUSE THE LOADER TO TIP, THROWING THE OPERATOR OUT OF THE SEAT OR LOADER, RESULTING IN DEATH OR SERIOUS INJURY.
  • Page 12 The skid-steer loader has decals that provide safety information and precautions around the loader. These decals must be kept legible. If missing or illegible, they must be replaced promptly. Replacements can be obtained from your Gehl dealer. New equipment must have all decals specified by the manufacturer affixed in their proper locations.
  • Page 13 ANSI-Style Safety Decals inside the ROPS/FOPS 137628 – Located on manual box, behind seat Left Instrument Panel 137647 – Located on operator’s lower left side 917001/CP0905 https://tractormanualz.com/...
  • Page 14 ANSI-Style Safety Decals on the outside of the Loader 137655 – Located on front of loader 132166 – Located on rear window emergency exit 137720 – Located on hitch (manual hitch loaders only) 184481 – Located on hitch (power hitch loaders only) 917001/CP0905 https://tractormanualz.com/...
  • Page 15 ANSI-Style Safety Decals on the outside of the Loader 137647 – Located on the left fender and left side of ROPS/FOPS 184214 – Located under the ROPS/FOPS 917001/CP0905 https://tractormanualz.com/...
  • Page 16 ANSI-Style Safety Decals in the Engine Compartment 137657 – Located on radiator 137658 – Located on radiator 917001/CP0905 https://tractormanualz.com/...
  • Page 17 ISO-Style (used Internationally) Safety Decals inside the ROPS/FOPS Safety alert: Always follow “Mandatory Safety Shutdown Procedure” in Operator’s Manual. 1 – Lower equipment to ground. 2 – Reduce throttle, stop engine. 3 – Apply parking brake; remove 137842 – Located on manual key.
  • Page 18 ISO-Style (used Internationally) Safety Decals on the outside of the Loader 137844 – Located on front of loader A – Crush hazard: Keep out from under work tool unless lift arm is supported. B – Fall hazard: No riders. Never use work tool as work platform. 132166 –...
  • Page 19 ISO-Style (used Internationally) Safety Decals on the outside of the Loader Crush hazard: Hose removal or component failure can cause lift arm to drop. Always use lift arm support device when leaving lift arm raised for service. 137848 – Located on the left fender and left side of ROPS/FOPS 184711 –...
  • Page 20 ISO-Style (used Internationally) Safety Decals in the Engine Compartment 137845 – Located on radiator A – Safety alert: Keep safety devices in place and in working order. Keep guards, screens and windows in place. B – Fire hazard: Do not smoke while fueling or servicing machine. Clean debris from engine compartment daily to avoid fire.

  • Page 21: Controls And Safety Equipment

    Know how to stop loader operation before starting it. This Gehl loader is designed and intended to be used only with a Gehl attachment or a Gehl-approved referral attachment or accessory. Gehl cannot be responsible for operator safety if the loader is used with a non-approved attachment.
  • Page 22 Operator’s Seat The seat is mounted on rails for rearward or forward repositioning. A spring-loaded latch handle activates the seat position adjustment mechanism. Suspension seat (optional on all models): A weight adjustment knob is provided for individual operator adjustment. Figure 1 Operator’s Seat 1.
  • Page 23 Disables the lift arm, auxiliary hydraulics, attachment tilt and wheel drives whenever the operator leaves the seat, turns the keyswitch to Off or raises the restraint bar. Testing the Safety Interlock System Before exiting the machine, check the safety interlock system for proper operation: Restraint Bar With the engine running, raise the restraint bar.
  • Page 24 “lower”. If the sole- noid valve does not hold the lift arm raised, lower the lift arm completely and contact your Gehl dealer immediately to determine why the cause. Engagement To engage the lift arm support device: 1.
  • Page 25 Figure 4 Lift Arm Support someone store the support device for you. Device Storage Location Then, contact your Gehl dealer to deter- mine the reason why the lift arm lowers while the keyswitch is in the OFF position. 5. To store the support device, raise it up until it contacts the lift arm. Press in and hold the lock pin button to release its locking mechanism.
  • Page 26 Heater (optional) Loaders with the optional heater have a dial on the left instrument panel to con- trol the fan speed. Heater and Air Conditioner (optional) Loaders with the combination heater/ air conditioner have two controls on the left instrument panel: fan speed, air condi- tioner on/off, and temperature.
  • Page 27 T-Bar, Dual Hand and T-bar/Joystick Controls Only: A right-foot operated throttle pedal is provided to control the engine speed (Figure 7). The pedal linkage is spring-loaded to return to the pre-set hand throttle setting. Figure 7 Foot Throttle (T-Bar, Dual-Hand & T-bar/Joystick control units) 917001/CP0905 https://tractormanualz.com/...
  • Page 28 Two-Speed Transmission (optional) Loaders with the optional two-speed transmission have a button on the left con- trol handle for shifting between High (H) and Low (L). Shifting to High allows the machine to exceed 8 mph (13 km/h), up to a maximum speed of 12.4 mph (20 km/h).
  • Page 29 Power-A-Tach™ Hitch With the optional hitch mechanism, a switch on the left control panel activates the latch pins. Metal “flags” on the pins indicate their position: the pin flags rotate to a horizontal position when engaging the pins and a vertical position when disengaging the pins.
  • Page 30 Instrument Panels The instrument panels contain the switches and indicator lights. Symbols on the indicator lights are visible only when the indicator light are on. Left Panel 1. Two-Speed Transmission (optional) – Lights when high speed is engaged. 2. Parking Brake – Lights when the parking brake is applied.
  • Page 31 Right Panel 1. Hourmeter – Displays the total operating hours of the loader. 2. Fuel Level Gauge – Displays the amount of fuel in the tank. 3. Engine Oil Temperature Gauge – Displays the temperature of the engine oil. 4. Engine Oil Temperature – Lights if the engine oil is too hot this warns the operator to stop the engine and determine and correct the cause for the high temperature.
  • Page 32 Note: The engine cannot be started unless the operator is sitting in the seat and the restraint bar is lowered. 8. Circuit Breakers – Four circuit breakers on the instrument panel protect the loader electrical circuits. Important: Do not attempt to defeat the circuit protection by jumping across or by installing a higher amperage circuit breaker.
  • Page 33 T-Bar Controls Your loader may be equipped with the Gehl T-Bar control option. The left T-Bar controls the drive and the right T-Bar con- trols the lift/tilt. Drive Controls Forward, reverse, speed and turning maneuvers are accomplished by move- Figure 12 T-Bar Controls ment of the left T-Bar.
  • Page 34 T-Bar/Joystick Controls Your loader may be equipped with the Gehl T-Bar/Joystick control option. The left T-Bar controls the drive and the right joystick controls the lift/tilt. Drive Controls Forward, reverse, speed and turning maneuvers are accomplished by move- Figure 13 T-Bar/Joystick ment of the left T-Bar.
  • Page 35 Lift/Tilt Control Moving the lift arm and tilting the attachment are accomplished by movement of the right joystick. To raise the lift arm, pull the control straight rearward; to lower the lift arm, push the control straight forward. To tilt the attachment for- ward and down, move the control to the right;...
  • Page 36 Hand/Foot Controls Your loader may be equipped with the hand/foot control option. The handles control the drive and the foot pedals con- trol the lift/tilt. Drive Controls Forward, reverse, speed and turning maneuvers are accomplished by move- ment of the control handles. To go for- Figure 14 Hand/Foot Controls ward, push both handles forward;...
  • Page 37 Lift/Tilt Controls Moving the lift arm and tilting the attachment are accomplished by movement of the foot pedals. The left pedal raises and lowers the lift arm; the right pedal tilts the attachment. To raise the lift arm, push down on the back of the left pedal with your left heal;...
  • Page 38 Dual-Hand Controls Your loader may be equipped with the dual-hand control option. The left handle controls the left side drive and the lift. The right handle controls the right side drive and the tilt. Drive Controls Forward, reverse, speed and turning Figure 15 Dual-Hand Controls maneuvers are accomplished by pushing 1.
  • Page 39 Auxiliary Hydraulic Controls Auxiliary hydraulics are used with attachments that have a mechanism requiring its own hydraulic power. Important: Always be sure the auxiliary hydraulic control is in neutral before starting the loader or disconnecting the auxiliary hydraulic couplers. Standard-Flow Auxiliary Hydraulic Control Loaders are shipped from the factory with a standard-flow auxiliary hydraulic system with flat-face couplers.
  • Page 40 High-Flow Auxiliary Hydraulic Control (optional) In addition to a standard-flow auxiliary hydraulic system, some loaders are equipped with a reversible high-flow aux- iliary hydraulic system. The couplers are located on the right lift arm. High-flow auxiliary hydraulics are used for oper- ating certain hydraulic attachments (e.g., cold planer, snowblower) that require Figure 18 High-Flow Control...

  • Page 41: Operation

    CHAPTER 4 OPERATION Before starting the engine and operating the WARNING loader, review and comply with all safety rec- ommendations in the Safety chapter of this manual. Know how to stop the loader before starting it. Also, be sure to fasten and prop- erly adjust the seatbelt(s) and lower the operator restraint bar.
  • Page 42 Cold-Starting If the temperature is below 32°F (0°C), try the following to make starting the engine easier: Replace the engine oil with SAE 10W30 oil; Make sure the battery is fully charged; Install an engine block heater. An oil pan heater is recommended for starting in temperatures of 20°F (-7°C) or lower.
  • Page 43 Parking the Loader Park the loader away from traffic on level ground. If this is not possible, park the loader across the incline and block the tires to prevent movement. Jump-starting If the battery becomes discharged or does not have enough power to start the engine, use jumper cables and the following procedure to jump-start the loader engine.
  • Page 44 Allow sufficient time for the skid-steer loader alternator to build-up a charge in the battery before attempting to operate the loader or shut the engine off. Changing Attachments To prevent unexpected release of the attach- WARNING ment from the hitch, be sure to properly secure the hitch latch pins by rotating the latch levers all the way (manual All-Tach™...
  • Page 45 8. Manual hitch: Exercise the MANDATORY SAFETY SHUTDOWN PROCE- DURE (page 6). Exit the operator’s compartment and rotate the latch levers to the horizontal position to fully engage the latch pins. 9. Power hitch: Activate the switch to lock the hitch and fully engage the latch pins.
  • Page 46 Self-Leveling The feature is intended to automatically keep the attachment level while the lift arm is being raised. Using a Bucket Always maintain a safe distance from electric WARNING power lines and avoid contact with any elec- trically charged conductor or gas line. Accidental contact or rup- ture can result in electrocution or an explosion.
  • Page 47 Loading a Bucket Approach the pile with the lift arm fully lowered and the bucket tilted slightly for- ward until the edge contacts the ground. Drive forward, lifting the lift arm and tilting back the bucket to fill it. Back away from the pile (Figure 23).
  • Page 48 Scraping with a Bucket For scraping, the loader should be operated in the forward direction. Position the lift arm down against the loader frame. Tilt the bucket cutting edge forward at a slight angle to the surface being scraped. While traveling slowly forward with the bucket in Figure 25 Scraping this position, material can flow over the...
  • Page 49 Storing the Loader If your skid-steer loader is to be stored for a long period of time, the following procedure is suggested: 1. Fully inflate the tires. 2. Lubricate all grease zerks. 3. Check all fluid levels and replenish as necessary. 4.
  • Page 50 Lifting the Loader The loader can be lifted using a single-point or four-point lift kit, which is avail- able from your Gehl dealer. WARNING • Before lifting, check the lift kit for proper installation. • Never allow riders in the operator’s compartment while the loader is lifted.

  • Page 51: Service

    The following areas of component service, replacement and adjustments require special tools and knowledge for proper servicing and should be performed only by your authorized Gehl skid-steer loader dealer: hydrostatic drive components, hydraulic system pumps, valves, hydraulic cylinders, electrical components (other than battery, circuit breakers).
  • Page 52 Fresh Air Intake Filter (heater option) 184708 Recirculation Air Filter (heater option) 184709 Note: Part numbers may change. Your Gehl dealer will always have the latest part numbers. Important: To ensure continued warranty coverage, only genuine Gehl replace- ment filters are to be used.
  • Page 53 2. Using a jack or hoist capable of lifting at the fully-equipped weight of the loader (with all attached options), lift the rear of the loader until the rear tires are off the ground. 3. Stack wooden blocks under the flat part of the loader chassis. They should run parallel with, but not touch, the rear tires.
  • Page 54 Tilting Back the ROPS/FOPS The ROPS/FOPS is designed to protect the operator from flying objects and provide protection if the loader tips or rolls over, provided the operator is secured inside the ROPS/FOPS by the seat belt and restraint bar. For service, unbolt the ROPS/FOPS and tilt it back slowly, moving the control han- dles out of the way.
  • Page 55 Engine Speed Control The throttle does not require routine adjustment. Refer to the Service Manual for the initial setup procedure. The throttle lever friction pad pressure can be adjusted if the throttle lever does not hold its position. Belleville washers and a lock nut on the throttle lever are used for making this adjustment.
  • Page 56 System Lubricant Use Petro Canada HVI60, Mobil DTE 15M or equivalent which contains anti-rust, anti-foam and anti-oxidation additives, and Hydraulic conforms to ISO VG46. System Oil Capacity: 4640/4840: 12 U.S. gallons (45 L) 5640/6640: 16 U.S. gallons (61 L) Use hydraulic system oil or SAE grade 15W40 motor oil. Chaincase Oil Capacity (each side): 8 U.S.
  • Page 57 50/500 Figure 33 Service Locations 10 Hours 500 Hours Lubrication Procedure 250 Hours (or Daily) (or Yearly) Check Engine Oil Level (page 57) Check Hydraulic Oil Level (page 59) Grease Lift Arm, Hitch, Cylinder Pivots and Latch Pins Check Oil Level in Chaincases (page 54) Change Engine Oil and Filter (page 58) Change Hydraulic Oil Filter (page 59) Change Hydraulic Oil (page 60)
  • Page 58 Chaincases There is a chaincase on each side of the loader. Refer to the Maintenance Interval Chart (page 75) for change intervals. Refer to the Lubrication chart (page 53). Checking and Adding Oil 1. Park the loader on a level surface. Stop the engine.
  • Page 59 Checking Chain Tension 1. Raise the loader following the Loader Raising Procedure (page 48). 2. Rotate each tire by hand. The proper amount of chain defection should be 1/8 in. to 1 in. (3 to 25 mm) forward and rearward. If the chain defection is more than 1 in.
  • Page 60 The outer element should be replaced only when the restriction indicator turns red. The inner element should be replaced every third time the outer element is replaced, unless the outer element is damaged or the inner element is visibly dirty. Along with a daily check of the restriction indicator, check that the air cleaner intake hose and clamps, and the mounting bracket hardware are properly secure.
  • Page 61 Inner Element Note: Replace the inner element only if it is visibly dirty or if the outer element has been replaced three times. Before removing the inner element from the housing, clean out any dirt built up in the housing. Leave the inner element installed during this step to prevent debris from entering the engine intake manifold.
  • Page 62 Figure 37 Engine Service Compo- 4. Engine Oil Fill Cap nents 5. Radiator/Cooler 1. Air Cleaner 6. Muffler 2. Fuel Filter 7. Engine Oil Filter 3. Engine Oil Drain Valve 8. Engine Oil Dipstick Changing Engine Oil and Filter Note: For new units, the initial oil change should be after the first 50 hours. Important: Always dispose of waste lubricating oil according to local regula- tions or take to a recycling center for dis-...
  • Page 63 Changing Fuel Filter The loader has a fuel filter located on the left side of the engine, in front of the battery. Follow the ROPS/FOPS and Lock Mechanism procedure (page 50) to lift up the ROPS and access the filter. Clamp off the fuel line to stop fuel flow BEFORE replacing the filter.
  • Page 64 5. Refill the hydraulic oil reservoir with oil. Refer to the Lubrication chart (page 52). 6. Spin off the old hydraulic filter element and spin on the new filter element. Changing Hydraulic Oil The hydraulic oil must be replaced if it becomes contaminated, after major repairs and after 1000 hours or one year of use.
  • Page 65 Cooling System Important: Check the cooling system daily to prevent overheating, loss of perfor- mance and engine damage. Cleaning the Cooling System Allow sufficient time for the oil cooler to cool WARNING before working on or near it. Parts get extremely hot during operation and can burn you.
  • Page 66 Checking Tire Pressure Correct tire pressure should be maintained for all tires to enhance operating sta- bility and extend tire life. Refer to the charts below for proper inflation pressures. Inflation Inflation Pressure Pressure 4640/4840 Tire 5640/6640 Tire 10 x 16.5 8-ply 12 x 16.5 10-ply Heavy-Duty Floatation Heavy-Duty Floatation...
  • Page 67 Electrical System Circuit Breakers The circuit breakers for the inside electrical system are located on the right instrument panel. Battery Before servicing the battery or electrical WARNING system, be sure the battery disconnect switch is in the OFF position. The battery on the loader is a 12-volt, wet cell battery. To access the battery, open the engine access cover, unlatch and open the rear grille.
  • Page 68 Notes 917001/CP0905 https://tractormanualz.com/...

  • Page 69: Troubleshooting

    CHAPTER 6 TROUBLESHOOTING Electrical System Problem Possible Cause Remedy Battery disconnect switch is Turn battery disconnect OFF position. switch to ON. Circuit breakers on engine Check circuit and locate panel have tripped or problem causing breaker to malfunctioned. trip (breaker resets automatically).
  • Page 70 Electrical System Problem Possible Cause Remedy Seat or restraint bar switch Contact your dealer. malfunctioning or not actuated. Poor connections to starter Verify relay connections. relay in instrument panel. Battery terminal or cables Clean terminal, cables and loose or corroded. retighten.
  • Page 71 Engine Problem Possible Cause Remedy Engine cranking speed too Battery requires recharging slow. or replacing, or, in cold temperatures, pre-warm the engine. Auxiliary valve engaged. Return control valves to neutral. Fuel tank empty. Refill fuel tank. Glow plug module Check connection and Engine turns over malfunctioning.
  • Page 72 Hydrostatic Drive System Problem Possible Cause Remedy Hydraulic oil viscosity too Allow longer warm-up or heavy. replace oil with proper No response from viscosity oil. either hydrostatic drive or the lift/tilt Hydraulic oil too low. Check for low oil level in systems.
  • Page 73 Hydrostatic Drive System Problem Possible Cause Remedy Drive system overloaded Improve efficiency of continuously. operation. Lift/tilt or auxiliary system Improve efficiency of overloaded continuously. operation. Drive motor(s) or hydrostatic Contact your dealer. pump(s) have internal damage or leakage. Hydrostatic drive overheating.
  • Page 74 Hydraulic System Problem Possible Cause Remedy Hydraulic oil viscosity too Allow longer warm-up or heavy. replace oil with proper viscosity oil. Air in hydraulic system. Cycle lift and tilt cylinders to maximum stroke and Hydrostatic (drive) maintain pressure for short system is noisy.
  • Page 75 Hydraulic System Problem Possible Cause Remedy Restraint bar raised. Lower restraint bar. Hydraulic oil viscosity too Allow longer warm-up or heavy. replace with proper viscosity oil. Hydraulic oil level low. Check oil level in reservoir. If Lift/Tilt controls fail oil is low, check for external to respond.
  • Page 76 Hydraulic System Problem Possible Cause Remedy Control valve in “float” Take control out of “float” No down pressure on position. position. the bucket. Tilt cylinders malfunctioning. Contact your dealer. Oil leaking past tilt cylinder Contact your dealer. seals (internal or external). Bucket drifts down Self-leveling valve is Contact your dealer.
  • Page 77 Hydraulic System Problem Possible Cause Remedy Lift arm support device Raise lift arm and remove engaged. support device. Restraint bar not lowered. Check electrical connections to solenoid. Repair or replace Lift arm will not lower as needed. or raise. Lift solenoid valve Lower restraint bar.
  • Page 78 Hydraulic System Problem Possible Cause Remedy Restraint bar raised. Lower the restraint bar. Spool lock solenoid Check electrical connections malfunctioning. to solenoid, repair connections as needed. If still not functioning properly, contact your dealer. Restraint bar or switch Contact your dealer. High-flow auxiliary malfunctioning.

  • Page 79: Maintenance

    CHAPTER 7 MAINTENANCE This Maintenance Interval Chart was developed to match the Service chapter of this manual. Detailed information on each service procedure may be found in the Ser- vice chapter. A Maintenance Log follows the chart for recording the maintenance performed.
  • Page 80 Maintenance Log Date Hours Service Procedure 917001/CP0905 https://tractormanualz.com/...
  • Page 81 Maintenance Log Date Hours Service Procedure 917001/CP0905 https://tractormanualz.com/...
  • Page 82 Maintenance Log Date Hours Service Procedure 917001/CP0905 https://tractormanualz.com/...

  • Page 83: Specifications

    CHAPTER 8 SPECIFICATIONS Loader Specifications Specification 4640 4640 Turbo Operating Weight 6200 lbs (2812 kg) 6250 lbs (2835 kg) Shipping Weight 5715 lbs (2592 kg) 5545 lbs (2515 kg) 1500 lbs (680 kg) 1500 lbs (680 kg) Rated Operating Load (capacity) Engine Make...
  • Page 84 Specification 4840 Operating Weight 6480 lbs (2939 kg) Shipping Weight 5825 lbs (2642 kg) 1700 lbs (771 kg) Rated Operating Load (capacity) Engine Make Deutz Model F4M2011 Displacement 190 in (3.1 L) Power (net) 61.2 hp (45 kW) @ 2500 rpm Peak Torque 144 ft-lb (195 N·m) @ 1700 rpm...
  • Page 85 Specification 5640 5640 Turbo Operating Weight 7380 lbs (3348 kg) 7430 lbs (3370 kg) Shipping Weight 6740 lbs (3057 kg) 6790 lbs (3080 kg) 2000 lbs (907 kg) 2000 lbs (907 kg) Rated Operating Load (capacity) Engine Make Deutz Deutz Model F4M2011 BF4M2011...
  • Page 86 Specification 6640 Operating Weight 7800 lbs (3538 kg) Shipping Weight 7160 lbs (3247 kg) 2400 lbs (1089 kg) Rated Operating Load (capacity) Engine Make Deutz Model BF4M2011 Displacement 190 in (3.1 L) Power (net) 82 hp (61 kW) @ 2500 rpm Peak Torque 199 ft-lb (270 N·m) @ 1600 rpm...
  • Page 87 Standard Features Fuel Level Gauge Hydraloc™ System – Brakes and Interlock for Starter, Lift Cylinders, Engine Coolant Temperature Tilt Cylinders, Wheel Drives, Gauge and Indicator Light Dual-Element Air Cleaner with Hourmeter Visual Indicator Oil Pressure Indicator Light Anti-Vandalism Rear Door Battery Charge Indicator Light Pre-Heat Starting Assist Seatbelt Indicator Light and...
  • Page 88 Dimensional Specifications 10.8 ft (0.3 m ) Bucket SL4640 w/10 x 16.5 Tires inches A Overall Operation Height – Fully Raised 149.0 3785 B Height to Hinge Pin – Fully Raised 115.5 2934 C Overall Height – Top of ROPS 78.0...
  • Page 89 10.8 ft (0.3 m ) Bucket SL4840 w/10 x 16.5 Tires inches A Overall Operation Height – Fully Raised 149.0 3785 B Height to Hinge Pin – Raised 115.5 2934 C Overall Height – of ROPS 78.0 1981 D Overall Length – Down 126.3 3207 E Dump Angle at Full Height...
  • Page 90 15.3 ft (0.43 m ) Bucket SL5640 w/12 x 16.5 Tires inches A Overall Operation Height – Fully Raised 162.0 4115 B Height to Hinge Pin – Fully Raised 123.0 3124 C Overall Height – Top of ROPS 81.0 2057 D Overall Length –...
  • Page 91 15.3 ft (0.43 m ) Bucket SL6640 w/12 x 16.5 Tires inches A Overall Operation Height – Fully Raised 167.0 4242 B Height to Hinge Pin – Fully Raised 123.0 3124 C Overall Height – of ROPS 81.0 2057 D Overall Length – Bucket Down 141.5 3594 E Dump Angle at Full Height...
  • Page 92 Capacities and Ratings SL 4640/4840 Models Note: Use the Common Materials and Densities table (page 90) for selecting the appropriate bucket. Dirt/Construction Buckets SL4640 SL4840 Description Weight Rating Rating 465 lbs 1393 lbs 1567 lbs 68 in/15.3 ft (1727 mm/0.43 m...
  • Page 93 SL 5640/6640 Models Note: Use the Common Materials and Densities table (page 90) for selecting the appropriate bucket. Dirt/Construction Buckets SL5640 SL6640 Description Weight Rating Rating 465 lbs 1594 lbs 2135 lbs 68 in/15.3 ft (1727 mm 0.43 m (211 kg) (723 kg) (968 kg) 500 lbs...
  • Page 94 Common Materials and Densities Density Material lbs/ft kg/m Ashes 35-50 560-800 Brick-common 1792 Cement 1760 Charcoal Clay, wet-dry 80-100 1280-1600 Coal 53-63 848-1008 Concrete 1840 Cinders Coal-anthracite 1504 Coke Earth-dry loam 70-90 1121-1442 Earth-wet loam 80-100 1281-1602 Granite 93-111 1488-1776 Gravel-dry 1602 Gravel-wet...
  • Page 95 Bucket Selection To use the table, find the material to be loaded and read its maximum density. Then multiply the volumetric rating of the attachment by the material density to determine if the attachment can safely be used. See page for a listing of attach- ments and their load ratings.
  • Page 96 Notes 917001/CP0905 https://tractormanualz.com/...

  • Page 97: Torque Specifications

    CHAPTER 9 TORQUE SPECIFICATIONS Use these torque values when tightening hardware (excluding locknuts, and self- tapping, thread-forming, and sheet metal screws) unless otherwise specified. UNIFIED GRADE 2 GRADE 5 GRADE 8 NATIONAL LUBED LUBED LUBED THREAD 8-32 8-36 10-24 10-32 1/4-20 1/4-28 5/16-18...

  • Page 98: Warranty

    (12) months from the Warranty Start Date, except as set forth below. GEHL CONSTRUCTION WARRANTY SERVICE INCLUDES: Genuine Gehl parts and labor costs required to repair or replace equipment at the selling dealer’s business location. GEHL MAKES NO REPRESENTATIONS OR WARRANTIES OF...

  • Page 99: Index

    INDEX Control/Indicator Switch ..CONTROLS and SAFETY Accessory Plug ... . EQUIPMENT ... . Adjustments ....Cooling System .
  • Page 100 Operation ....Ride Control System ..Heater and Air Conditioner ROPS/FOPS ....Operation .
  • Page 101 Hydrostatic Drive System . . Wheel Nuts ....Two-Speed Transmission ..Work Lights ....WARRANTY .
  • Page 102 917001/CP0905 https://tractormanualz.com/...
  • Page 103 WRONG WRONG Never exceed rated Always carry attachment operating load. as low as possible. Do not travel or turn with the lift arm raised. Load, unload and turn on flat level surface. WRONG WRONG Never carry riders. Never modify equipment. Keep bystanders away Use only attachments from work area.
  • Page 104 State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling battery. ® Gehl Company 143 Water Street, P.O. Box 179, West Bend, WI 53095-0179 U.S.A. www.gehl.com © 2005 GEHL COMPANY https://tractormanualz.com/...
