Measurement function icon and description

Signal display area of the
test instrument
Part name
Temperature setting
Temperature setting
Start/Stop
Programming
Measuring stabilization time
Signal display area of the
test instrument
Measuring stabilization time
Function description
Display the set temperature value, click to set
Display the set humidity value, click to set
Perform start/stop operation
Programmable control, setting of step and stabilization time;
setting of calibration point, stabilization time and error judgment, etc.,
to perform automatic calibration
Display the measured stabilization time
Display the relative difference between the currently measured humidity value and
the set value
CHAPTER 2
Programming
Start/Stop
HG6000 Product Introduction
Temperature setting
Humidity setting
13
