Function description

View NO. Part name
①
Power switch
②
Power connection
③
Vents
④
External expansion test cabin interface
⑤
Water port
⑥
Expansion desiccant interface
⑦
LAN
⑧
USB
⑨
COM
Desiccant cartridge cover
10
Handle
11
CHAPTER 2
Function description
Switch "-"to turn on; switch to"O"to turn off
Connect power cable
Used for cooling
Used to expand the test cabin to adapt to special needs
Add /Drain water
External desiccant, good for using the instrument for a long time
LAN interface
USB interface
RS232/RS485 interface
Unscrew the cover of the desiccant cartridge,
take out the built-in drying chamber,
and replace the internal desiccant
For moving the instrument
HG6000 Product Introduction
