Section 3: Setup and Operation

1
You will receive Virtualine with mounting bracket attached
to the unit as shown in fig. Ideally, it is recommended to
use the marked holes to mount the unit on Ceiling or any
other available mounting surface.
3
Finally, be sure to loop the included steel safety cable
through the eyelet on the back of the Virtualine™ LED
SWITCH and around the nearest secure object, pipe, or
rail. This is to prevent injury in the unlikely event that the
primary mount fails.
CAUTION: The magnets in the magnetic mount accessory are very powerful! Do not allow the magnets to slam together,
as this may damage the magnets and they will be very difficult to separate. NEVER PUT YOUR FINGERS BETWEEN
THE MAGNETS AND THE MOUNTING SURFACE OR OTHER MAGNETS. The magnets are strong enough to cause
serious injury! The heatsink on the back of the Virtualine LED SWITCH must be kept clear to allow adequate airflow for
cooling. Do not cover the heatsink with any material.
2
Then affix the Virtualine™ LED SWITCH to your
mounting surface using hardware designed for that type
of mounting surface (drywall anchors for drywall without a
stud, concrete screws for concrete). Once the fixture is in
place, clear any dust or debris out of the rear heatsink
area before powering on the fixture.
4
✔
If you purchased the magnetic mount accessory, your
mounting bracket will already have the magnets installed.
Simply stick the magnets to the desired surface and loop
the included steel safety cable around the attachment
point to prevent the fixture from falling if the magnets fail.
The magnets hold with approximately 90 pounds (41 kg)
of force.
VirtuaLine™ SWITCH LED Line Projector
