BOOKSHELF WITH STAGGERED SHELVES
Carefully review assembly and care instructions before using this product. Save this document for future reference.
Assemble components on a soft, clean surface to avoid scratching or damaging the finish.
WARNING
CHOKING HAZARD — This item contains small parts that can be swallowed. Keep children and pets away during assembly.
Biblioteca Classic
Purchase Date:
/
/
Order/Customer Reference Number:
Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell.
Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with
the date of purchase as well as photos of the merchandise defect, must be provided. Photos are used to determine
the cause of defects and for future quality control. Register your warranty at
If you have any questions, comments or concerns, feel free to contact us by phone at 833-982-1977, by email:
customerservice@sunnydazedecor.com, or via our contact us page at
RTA-058
10/2022
https://tiny.cc/SunnydazeWarranty
https://tiny.cc/SunnydazeContact
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
No.
Parts
A
Bottom Panel
B
Large Shelf
C
Left Panel
D
Right Panel
E
Left Shelf
F
Right Shelf
G
Top Back Panel
H
Bottom Back Panel
I
Toe Board
J
Top Panel
K
Divider Panel
No.
Hardware
1
Wood Dowel
2
Spreading Bolt
3
Cam Lock
4
Tack Glide
5
Cover Cap
6
Corner Brace
7
M6 x 9/16" Screw
8
5/32" x 1" Screw
9
Wall Anchor
Tools Required
Phillips Screwdriver
Rubber Mallet
Power Drill
with 1/4" Drill Bit
Qty.
1
1
1
1
3
3
1
1
2
1
1
Qty.
40
20
20
6
20
2
2
2
2
(not included)
