Nova 8201-R How To Assemble

HOW TO ASSEMBLE
& INSTALL YOUR
TOILET SUPPORT RAILS
Item Number: 8201-R
Capacity not to exceed 300 lb
ARM COMPONENT ASSEMBLY
Assemble arm components of Toilet
Safety Frame as shown below:
R
3
Replace toilet seat, and
insert original bolts through
mounting bracket holes and
into toilet seat mounting holes
(Figure 3). Use original nuts to
tighten.
Easy assembly
INSTALLATION
1
L
4
Figure 3
a. (2) Armrests
b. (2) Securing Screws
c. (1)
a.
b.
Read all instructions carefully and consult with a qualified professional before installing
Toilet Safety Frame to avoid possible injury. NOVA Medical Products shall have no liability
for any damage or injury resulting from improper installations or misuse of this product.
Figure 1
Take off existing toilet seat
and lid by removing the
screws in the rear (Figure 1).
Figure 4
Depress push buttons and install
arms into bracket (Figure 4).
Adjust the Toilet Seat Rail arm
width by engaging push buttons
in desired holes of mounting
bracket tube.
WHAT'S IN THE BOX
d. (1)
e. (1)
Bracket f. (2) Rear Frame Supports
d.
c.
WARNING
2
Place mounting bracket on
surface of toilet bowl and
align the holes (Figure 2). The
bracket tube should be closest
to the tank.
5
Ensure the Toilet Safety Frame's
rubber sleeves rest securely on the
front of the toilet rim under toilet
seat and lid (Figure 5).
Left Front Leg
Right Front Leg
e.
f.
Figure 2
Figure 5
*Rev. Jan 05, 2017
