Nova 8343-R How To Assemble

HOW TO
ASSEMBLE YOUR
Toilet Seat Riser with Arms
Item # 8343-R, 8344-R
Capacity not to exceed 300 lb
Seat Riser
1
Remove all parts from box:
(1) Seat Riser, (2) arms (left and right), (2) mounting screws, (2) metal washers, (2)
plastic washers and (2) wing nuts
2
To attach the arms to the Seat Riser, align each arm with the Seat Riser tubing. The
longer side of the arm should be facing the front of the Seat Riser. Press the brass
buttons on the arm tubes and insert the arm tubing into the Seat Riser tubing. You
should hear a click when the brass buttons are through the first tubing holes (the
second tubing hole on the Seat Riser is for assembly purposes only).
3
Remove the existing toilet seat and lid from the toilet frame by unscrewing seat
screws located at the rear of the toilet seat.
4
Place the Seat Riser on the toilet frame. The mounting holes on the rear of the Seat
Riser should line up with the mounting holes on the rear of the toilet frame.
5
Place toilet seat on Seat Riser and align mounting holes with toilet frame. Place the
metal washers onto the mounting screws, and place into mounting holes of toilet
seat, the Seat Riser, and toilet frame. Then place the plastic washers and the wing
nuts onto the mounting screws. Do not tighten the wing nuts completely.
6
Be sure the toilet seat is straight and sits flush on the Seat Riser, then tighten the
wing nuts.
Questions?
Please contact us at
1-800-557-6682
info@novamedicalproducts.com
novamedicalproducts.com
Thank you for choosing NOVA!
Arms (left and right)
IMPORTANT WARNING!
READ THESE DIRECTIONS CAREFULLY BEFORE USE
FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY
• Be sure Seat Riser is in place and secure before each use
• Do not stand on Seat Riser
• Arms must be secure in Seat Riser
CARE • QUALITY
THE NOVA
Mounting Screws, Metal Washers,
Plastic Washers and Wing Nuts
• INNOVATION
PROMISE
No tools required
All parts included
Easy to follow
step by step
instructions
