Nova 8341-R Manual

HOW TO
INSTALL YOUR
Toilet Seat Riser
Item #'s 8341-R, 8342-R
Capacity not to exceed 300 lbs.
1
Remove all parts from box:
(1) toilet seat
(2) mounting screws
(2) metal washers
(2) plastic washers
(2) wing nuts
Clean and sanitize toilet seat.
3
Place the toilet seat riser on the
toilet bowl. The mounting holes on
the rear of the riser should line up
with the holes on the rear of the
toilet bowl.
5
Place plastic washers at end
of screws and then attach
the provided wing nuts to
each mounting screw. Do not
tighten completely yet.
Be sure the toilet seat is
straight and sits flush on the
seat and then fully tighten
WHAT'S IN THE BOX
2
4
NO tools required.
Quick assembly.
Follow these
SIMPLE STEPS
Remove the existing toilet seat
and lid from the toilet bowl by
unscrewing the seat screws located
at the rear of the seat.
Replace the toilet seat and lid so
the holes of the toilet seat, the
riser, and the bowl line up. Place
metal washer onto screw.
Insert the mounting bolts with
washer through top of the seat and
lid, seat riser, and toilet bowl.
Screw
Plastic
washer
Wingnut
