TOSHIBA
SERVICE MANUAL
LCD TV/DVD COMBINATION
22DV501B
Updating history
Currently there are no updates available.
Please check back at a later time for any future
updates.
TOSHIBA WEB-ZEUS
file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\fcover.html
Ver. 1.00
>> terms and conditions
>> privacy policy
Copyright © 1995-2011 TOSHIBA Corporation, All Rights Reserved.
Page 1 of 1
Print this page
5
5
6
6
10/2/2013
Advertisement
Related Manuals for Toshiba 22DV501B
Summary of Contents for Toshiba 22DV501B
- Page 1 Ver. 1.00 Updating history Currently there are no updates available. Please check back at a later time for any future updates. >> terms and conditions >> privacy policy TOSHIBA WEB-ZEUS Copyright © 1995-2011 TOSHIBA Corporation, All Rights Reserved. file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\fcover.html 10/2/2013...
- Page 3 7. TV will give the CD out. Caution: At this time, the updating process is not finished, you shouldn't power off/on the TV. 8. Wait until the DVD background screen as shown below, appears again. It may take around 3 minutes. file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\firmware.html 10/2/2013...
- Page 4 Page 2 of 3 9. Firmware update is completed. DVD Service Menu Setup 1. Select DVD mode from the Sources on RC. 2. In DVD mode, press "DISPLAY" button on the RC You will see the DVD menu. file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\firmware.html 10/2/2013...
- Page 5 If not, adjust the settings by RC cursor buttons. DIVX Support off Region Code "2" for EU 5. After finishing the adjustments, press the DISPLAY button again for exit. >> terms and conditions >> privacy policy TOSHIBA WEB-ZEUS Copyright © 1995-2011 TOSHIBA Corporation, All Rights Reserved. file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\firmware.html 10/2/2013...
- Page 6 Setting "Last Status" item to 'On' enable TV open with the closing status. Otherwise, if "La Status" item is set 'Off' TV opens with standby status. Volume Limit Sets the maximum value the volume can have. "Volume Limit" can take values between 0-63. Fixed Volume Enable file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\hotel_mode.html 10/2/2013...
- Page 7 Disables either only INSTALL menu or all menus, both in analog and digital (IDTV) mode. All Menus : All menus (MAIN, SOUND, PICTURE, SETTINGS, INSTALLATION) are invisible. OSD Disable = Disable Setup Menus : Only SETUP menus are invisible. Invisabel Setup Menus are: file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\hotel_mode.html 10/2/2013...
- Page 8 Previously copied nvram files (Flashx.bin) are copied into TV. If there is no flash file or some of them are available on USB, the available ones are copied. If no USB is connected, nothing happens. >> terms and conditions >> privacy policy TOSHIBA WEB-ZEUS Copyright © 1995-2011 TOSHIBA Corporation, All Rights Reserved. file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\hotel_mode.html 10/2/2013...
- Page 9 · · · · · · WK : Week WK01 WK02 WK03 WK04 · · · · · · WK53 Model/Panel Information Model Panel Main Vestel Model Panel Module Product Code 19DV501B 75027051 75027049 LG TLG1 10072930 (OLD) file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\model_panel_id.html 10/2/2013...
- Page 10 10075085 LTA32AP06-L02 32DV501B 75027096 75028152 10075273 LTA32AP06-L02 Panel vendor Marking Panel Vendor Marking Panel Vendor Marking Panel Vendor SHARP SAMSUNG LPL/LGD >> terms and conditions >> privacy policy TOSHIBA WEB-ZEUS Copyright © 1995-2011 TOSHIBA Corporation, All Rights Reserved. file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\model_panel_id.html 10/2/2013...
- Page 11 75026227 VX3A00624800 BAG, (680MM*680MM), 19EL833F, 50145606 E580 75023740 VX3A00467300 SNOW BOX ASSY, 22BV500B, 20467054 E590 75027064 20579476 ARTWORK TOSHIBA, 22DV501B, 20579476 >> terms and conditions >> privacy policy TOSHIBA WEB-ZEUS Copyright © 1995-2011 TOSHIBA Corporation, All Rights Reserved. file://T:\emms_tmp\DANIEL\22DV501B-WZ01\html\parts_list.html 10/2/2013...
- Page 12 S810 C843 +12V S809 +12V TRF_SMPS_SAFE_17IPS17_19-22 C844 R896 +14.5V STPS_3P_10L60CFP 12V_VCC 0R22 S813 TR801 STPS_3P_10L60CFP D827 L810 S820 +14.5V R813 KA78R12 IC804 Q804 D813 BC848B R812 VDIS Q808 C813 C809 C810 C811 FDC642P S801 D807 STPS_3P_10L60CFP BA159 STBY_ON/OFF Q806 R844 D826 BC848B C802...
- Page 13 TR200 TRF_INV_15_LIPS HB_B LAMP_3 PL200 PL201 LAMP_1 LAMP_4 F102 +14.5V HB_A LAMP_2 FUSE_SMD_7A/32VDC_1206 LAMP_RETURN_4 LAMP_RETURN_2 F101 FUSE_SMD_7A/32VDC_1206 PL102 TR100 LAMP_2 TRF_INV_SAFE_22 BC858B R103 BC858B Gate_H Q108 D140 R140 Q102 HB_A LAMP_1 R100 Q100 STD30PF03L BKL_ON/OFF 100k 1N4148_SOD123 BC848B Q106 VCC_IC LAMP_2 HB_A Q107...
- Page 14 PL803 PL802 DVD_SENSE 12V_VCC DVD_Y_IN DVD_SPDIF A/D_DIM DVD_C_IN DVD_IR BKL_ON/OFF 12V_VCC 12V_VCC +5V_VCC +5V_VCC S806 SOFT_SWITCH +5VSTBY A/D_DIM LED CONVERTER SOKETI BKL_ON/OFF STBY_ON/OFF PIN2 PL808 PL804 S811 DVD_SENSE DVD_Y_IN DVD_C_IN DVD_Y_IN DVD_SPDIF S812 DVD_C_IN DVD_IR DVD_SENSE 12V_VCC 12V_VCC +5V_VCC +5V_VCC DVD_SPDIF DVD_IR +5VSTBY...
- Page 16 VCC3 R933 R934 R939 R917 680k 680k 680k 680k D906 R935 R940 R912 R918 RS1008_SOD123 680k 680k 680k 680k C922 C912 R929 R930 R937 R920 680k 680k 680k 680k C908 C943 R931 R938 R911 R921 S903 680k 680k 680k 680k S905 S912 D900...
- Page 17 S805 S806 +Vaux D801 +24VREG +12V C808 IC803 BA159 C801 L805 S808 TR800 +3V3STBY_1 100p TRF_SMT_SAFE_15 NTGS3446 470p R855 +3V3 VCC_OFF 100R R826 VCCSTBY C834 D804 VCC_OFF STBY_ON/OFF R827 BA159 R850 Q813 BC848B DRAIN1 VF_MAIN RS1008_SOD123 IC807 D808 L804 +5VSTBY D803 +5VSTBY +5VSTBY...
- Page 18 STEP UP DEVRELERI IC302 IC301 NCP303 NCP303 XC9111 FAN5331 L300 RS1008_SOD123 100u D301 C318 220u VESTEL 26"32"42" LCD POWER SUPPLY 17PW25-4 DC/DC CONVERTER 4V2 SECTION Author DATE Sheet Ver. SMPS GROUP 11.10.2010...
- Page 19 L400 TR400 TRF_SMPS_SAFE_EE5154_26_32 +Vaux D931 +12V DIODE_OUT UF5402 D932 UF5402 D933 UF5402 D934 UF5402 D935 UF5402 RECT_AC D936 UF5402 D937 UF5402 D938 UF5402 DRAIN...
