Canaropa 9500FL Installation Instructions

9500FL EXIT DEVICE - FIRE RATED (F) LESS BOTTOM SURFACE ROD (L)
9500
INSTALLATION INSTRUCTIONS
SERIES
Top latch
strike
Latch
release
Thru-bolt
sexnuts
Top rod
guide
Main
chassis
assembly
Thru-bolt
sexnuts
Horizontal
Reference
Line
Auxiliary fire latch assembly
LEFT HAND REVERSED SHOWN

GENERAL NOTES

1. Fire exit hardware is to be installed only on fire doors bearing the marking "Fire Door To Be Equipped with Fire
Exit Hardware".
2. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening. The exit device manufacturer makes no representations or warranties concerning what such impact may
be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and
installing a new fire rated opening, please consult with a code specialist or local code official (Authority Having
Jurisdiction) to ensure compliance with all applicable codes and ratings.
3. The door surface must be flat and properly reinforced at the exit device mounting locations. If door is not
reinforced, the door surface may collapse or bow-in, causing malfunction in the exit device operation.
Top latch
4. Door must be properly fitted and hung.
chassis
5. The 3' exit device model can be cut to fit doors from 30 to 36" (762 to 914 mm) in width (refer to section 5 on page 2).
assembly
The 4' exit device model can be cut to fit doors from 36 to 48" (914 to 1219mm) in width (refer to section 5 on page 2).
6. Determine door handing (see illustration below). Exit device is handed. If handing change is required refer to handing
instructions below.
7. For wood doors or hollow metal doors use through bolts, and for metal reinforced doors drill & tap and use machine screws.
(Refer to template document).
Machine
screws
Top latch
chassis cover
Top rod
Lift arm
Vertical
Reference
Line
Before installing exit device, verify or note the following:
Rail assembly
Push / touch pad
RIGHT HAND REVERSED
Main
chassis

HANDING CHANGE INSTRUCTIONS

cover
To change hand of device: use 2 1/4" (57.2 mm) long pin to
knock out lift lever pin, remove lift lever and reassemble at other
end of main chassis assembly by reinserting lift lever pin
(see figure below)
Use 2 1/4" long pin
to knock out lift lever
pin and re-orient lift
lever (as shown)
Through bolt
Rail mounting
sexnut
bracket
Sliding cover
If Alarm Panel or Request for Exit
is used refer to the installation
instructions supplied with these kits.
CAUTION:
Exit device components must be
installed flush to a flat surface

DOOR HANDING

Lift
lever
pin
9500FL-INST-EN-R2016-09
End cap
LEFT HAND REVERSED
Lift
lever
pin
Lift
lever
1/2
