Canaropa 9500PV Installation Instructions

9500PV EXIT DEVICE - PANIC (P) SURFACE VERTICAL RODS (V)
9500

INSTALLATION INSTRUCTIONS

SERIES
Top latch
strike
Latch release
Top rod
guide
Main chassis
assembly
Horizontal
reference
line
Bottom
rod
guide
Bottom rod
Height
adjust pin
Bottom latch strike
Vertical
reference
line
LEFT HAND REVERSED SHOWN
GENERAL NOTES
Before installing exit device, verify or note the following:
1. The door surface must be flat and properly reinforced at the exit device mounting locations. If door is not
reinforced, the door surface may collapse or bow-in, causing malfunction in the exit device operation.
2. Door must be properly fitted and hung.
3. The 3' exit device model can be cut to fit doors from 30 to 36" (762 to 914 mm) in width (refer to section 5 on page 2).
The 4' exit device model can be cut to fit doors from 36 to 48" (914 to 1219 mm) in width (refer to section 5 on page 2).
Top latch
4. Determine door handing (see illustration below). Exit device is handed. If handing change is required refer to handing
chassis
instructions below.
assembly
5. For wood doors or hollow metal doors use through bolts (not supplied), and for metal reinforced doors drill & tap and use
machine screws. (Refer to Template document).
Top latch
chassis cover
Top rod
Lift arm
Main slide
Bottom latch
chassis cover
Bottom latch/bolt
chassis assembly
Rail assembly
Push / touch pad
Main
RIGHT HAND REVERSED
chassis
cover
HANDING CHANGE INSTRUCTIONS
To change hand of device: use 2 1/4" (57.2 mm) long pin to
knock out lift lever pin, remove lift lever and reassemble at other
end of main chassis assembly by reinserting lift lever pin
(see figure below)
Use 2 1/4" long pin
to knock out lift lever
pin and re-orient lift
lever (as shown)
Rail
mounting
bracket
Sliding cover
If Alarm or dogging panel is used, install panel as per the
appropriate installation instructions supplied with the panel
Dogging hex key
CAUTION:
Exit device components must be
installed flush to a flat surface
DOOR HANDING
Lift
lever
pin
9500PV-INST-EN-R2016-09
End cap
LEFT HAND REVERSED
Lift
lever
pin
Lift
lever
1/2
