Intex Excursion 4 Set Manual page 8

(98IO) "ISO" BOAT W / MOTOR MOUNTING (TYPE II) ENGLISH 4.875" X 7.25" 05/13/2022
Mariner 3 / Set
3
1 2
11
Mariner 4 / Set
1 2 3
8
11
" " - Recommended seating arrangement of the occupants.
Grab handle
1
All around grab line
2
Seat or seat cushion
3
Inflatable floor or removable slats floor
4
Oar lock
5
Oar holder
6
Gear pouch or accessory bag
7
NOTE: Only use Intex Motor Mount Kit (#68624).
Drawings for illustration purpose only. Actual product may vary. Not to scale.
SAVE THESE INSTRUCTIONS
4 7
8 6
4
5 7
6
Descriptions
Page 7
10
12
9
10
12
9
8
Inflation valve / Keel valve
9
Fishing rod holder
10 Motor mount
11 Boston valve
12 Rock guard
13 Inflatable keel
