Shure M75ECS Quick Start Manual

222 HARTREY
AYE.. EVANSTON,
IL.
60204 U.S.A.
MICROPHONES AND ELECTRONIC COMPONENTS
A R E A UOOE 312
Bbb.2200
.
CABLL S t *
JREMICRO
TWX:
910.231-0048 TELEX: 72-4381
THE
PREMIER FAMILY OF STEREO SOUND REPRODUCERS
MODEL M75ECS
STEREO DYNETIC@
EASY-MOUNT
PHONOGRAPH CARTRIDGE
CARTRIDGE AND STYLI SPECIFICATIONS
N75EC
10 X 18p
(.0004 X
,0007 in.)
Biradial
(Elliptical)
toptional 78 rpm Stylus:
Set amplifier to "MONO" or " A f B."
*Output voltagcs given for stereo cut record. For M O N O cut record,
output voltage at I ~ u l h left channel and rlght channel cartridge terminals
w i l l be 71% of ilgurcs above.
**Tracking
forces grealcr than maximum Indicated should not be used.
NET WEIGHT: 5.6 jirdnlh
INDUCTANCE: 720 i i ~ i l l l h e n r i e i
DC RESISTANCE: 630 olirns
OPTIMUM LOAD: 47,000 ohms resistance in parallel with 400 t o 500
picofarads
total capacitance per channel. Load
resistance
can be up to
70,000 ohms wlth almost no audible change in frequency response. Total
capacitancc includes both tone arm wirlng and amplitier input circuit.
FOUR-CHANNEL: 7h1s Stereo Dynetic@ cartrldge is compatible with all
four-channel matrix systems.
MONOPHONIC OPERATION: Set functlon switch on amplifier to "MONO"
or "A+B." If amplifier is not equipped with thls switch, connect left and
right channels In parallel.
N75-3t
64 microns
LO025 in.)
Spher~cal
CONNECTIONS (see Figure 1):
Right
"hot" lead (usually red) to
"R," right ground (usually green)
ckz$JE
t o "RG." Left "hot" lead (usually
LEFT
white) to "L," left ground (us-
C H A N N E L
ually blue) to "LG." If metal head
is causing ground loop hum, re-
move the ground tab. The metal-
lic cartridge shield is disconnect-
Brow11
ed from the right channel ground
bv the removal of the ground tab.
Dark
Green
CAUTION: D o not make solder
collnections to cartridge terminals.
STYLUS REPLACEMENT (see Fig-
ure 2): Grasp molded housing of
stylus and gently pull forward out
of cartridge. Insert replacement
stylus into socket and press until
housing mates with cartridge case.
"EASY-MOUNT" MOUNTING [12.7
mrn (1/2 in.) mounting centers]:
Mounting screws are provided.
1. Remove stylus guard and stylus
(see Stylus Replacement).
2. Remove cartridge from snap-in
bracket (see Figure 3).
3. Attach bracket to tone arm
head or plug-in shell in ac-
FIGURE 2
cordance with turntable manu-
facturer's instructions. General-
9.3 mV
ly, the top of the bracket
, s ~ E ~ ~ caRTR,oei
wsr
BE
PLACED
should be flat against the top
'\
~ " . ~ ~ . T " . ~ ~ T ~ ~ ? ~ ~ & ~ ~ ~ ~ ~ : E
:F1","k%E("I
of the head or shell.
/'
6.2
mV
4 Connect leads to cartridge (see
F~gure 1).
20 to
20,000
Hz
-
-
.
- -
5. Insert cartridge into snap-in
Ly-~--l'i
bracket (see Figure 31.
L i , i ~ HERE liTn
T ~ ~ M B N A L FOR R E M O Y A ~
OF CIIRTRIOmE
FROM BRiiCXET
6. Reinsert stylus (see Stylus Re-
placement). FIGURE 3
RECOMMENDED STYLUS CLEANING: Use a camel's hair brush (No. 2 size
or
smaller), trimmed to
approximately
6 mm (1/4 in.), dlpped in alcohol or
an alcohol-d~st~lled water
solution.
Commerrial cleaning solut~ons may cause
stylus damage or corrosion. Always blush stylus from back to front; never
brush or wlpe stylus from front to back or slde to side.
TO PRESERVE STYLUS LIFE:
1. Follow turntable or tone arm lnstructlons when adjusling antlskating
force.
2. D o not handle the tone arm while i t is in operation slnce this may
cause the arm to sweep across the record.
3. If i t is necessary to manually place the tone arm In the record groove
while turntable is rotating, release it as soon as Lhe stylus engages the
record groove.
4. Correct Improper set-down adluslment or malfunction of the turntable
changing rneclianism to prevent the stylus from ~ t r i k i n g the edge of the
turntable or record. D o not stack more records than turntable manufac-
turer recommends.
5. Take care to properly insert the stylus into the cartridge assembly and
the cartrldge and shell assembly into the tone arm receptacle.
6. Use proper vertlcal tracking force setling for each cartridge.
7. D o not use badly warped, cracked or Imperfect records.
8 .
When dusting the turntable protect the stylus with the stylus guard.
SPECIAL NOTE:
To maintain the original performance standards of your
cartridge, be certain that any replacement stylus you buy bears the fol-
lowing
certification
on the package: "This Dynet~c@ stylus is precision
manufactured by Shure Brothers Inc." AVOID INFERIOR IMITATIONS. THEY
WILL SERIOUSLY DEGRADE THE PERFORMANCE OF YOUR CARTRIDGE.
ALL GENUINE "DYNETICO" STYLI ARE MANUFACTURED BY SHURE
BROTHERS INC. LOOK FOR THE NAME SHURE O N THE STYLUS GRIP.
For more information on your Shure stylus, write for booklet: "A Visit t o
the Small World of a Stylus."
FULL ONE-YEAR WARRANTY: Shure Brothers Incorporated ("Shure"),
222 Hartrey Avenue, Evanston, Illinois 60204, warrants to the owner of this
product that i t w i l l be free, in normal use, of any defects in workrnanshlp
and materials for a period of one year from date of purchase. You should
retain proof of date of purchase. Shure is not liable for any consequential
damages. If thls Shure product has any defects as described above, care-
fully repack the unit and return i t prepaid to:
Shure Brothers lncorporated
Attention: Service Department
1501 West Shure Drive
Arlington Heights, Illinois 60004
If you are not in the United States, return the unit to your dealer or
Authorized Service Center for repair. The unit w i l l be repalred or replaced
and returned to you promptly, and if i t cannot be repalred or replaced,
you may elect to receive a refund. This warranty does not include stylus wear.
PATENT NOTICE: Cartridge and stylus manufactured under one or more
of the
following
U.S. patents: 3,055,968, 3,077,521, 3,077,522, and 3,463,889.
Copyright 1979,
Shure Brothers Inc
27A1234 (SF) Prlnted in U.S.A.
20 to
20,000
Hz
within
2 dB
-
-
-
20 dB
at
1 k H z
-
2 to 4
grams
1 %
to
3
grams
400 Hz
-
26 cm/sec
1,000 Hz
-
37 cm/sec
10,000 Hz
-
12 cm/sec
at 3 grams
. .
