Floodlight range
15W LED FLOODLIGHT
Product information
With its integrated PE cell, offset bracket and selectable power switch the MR range of floodlights is perfect for
most domestic installation applications. Available in a 15W, 10-30W or 40-60W wattages these floodlights are easy
to install and offer a simple solution to keep in the van that will suit a wide variety of applications.
Total Power:
Lumen Output:
Colour Temp:
IP Rating:
Efficacy:
CRI:
Beam Angle:
Temp Range:
Dimmable:
Power Supply:
Average Life:
Inrush Current:
Current Draw:
Power Factor:
IK Rating
LM Rating
Dimensions:
Weight:
Warranty:
Construction:
*Total power consumed including driver
** Average life is calculated on expected average lifespan
T. 1300 222 445 | www.melec.com.au
ML-MRFLD-15-W
15W*
747LM
5700K
IP65
133LM/W
105°
-20°C~+40°C
NO
100-277VAC
50,000HRS**
0.2A
0.0625A
0.9
IK06
LM80
151.1x136.3x43.2mm
0.46KG
5 Years
ADC12 Aluminum heat sink with Akzonobel power coating; Glass cover
For further information about our warranties please go to: melec.com.au/legal/warranties
70
20.5
110
227
