Melec NOX8 Installation Manual

V4
80W LED FLOODLIGHT
Product information
The NOX 80W Floodlight is our latest development of this iconic LED floodlight range.
Featuring an ultra-efficient offset bracket that installers demand, super slim body,
power selectable, and illumination specifications that lead the category, NOXV4 is the
brightest choice by far. Supported by an M-Elec 7year warranty.
Perfect for use with NOXBOX™
Fast and Easy Wiring
TECHNICAL INFORMATION STANDARD MODELS
Total Power:
Lumen Output:
Colour Temp:
IP Rating:
Efficacy:
CRI:
Beam Angle:
Temp Range:
Dimmable:
Power Supply:
Average Life:
Max Current
Draw:
Power Factor:
IK Rating
Dimensions
WxHxD:
Weight:
Warranty:
Construction:
Kit Includes:
*Total power consumed including driver
** Average life is calculated on expected average lifespan
INSTALLATION GUIDE
1. Do not remove any part of the fitting.
2. Install fitting using correct equipment and components (eg.
Expansion bolts for masonry)
3. Connect wires using M-Elec's newest junction box Noxbox™
(to be purchased separately) or other suitable enclosure.
Min 90°
ML-NOX8-V4-WW
11,859lm
3000K
160lm/W
120x90°
-20° to +50°
Yes 0-10V
120-277V AC Towin dimmable driver
50,000 hrs**
407x347x85mm
ADC12 Aluminum heat sink with Akzonobel power coating & PC lens
1 x LED floodlight,
1 x 1m pre-stripped flex, 1x User Manual
50mm
Max 155°
ML-NOX8-V4-W
80W*
11,874lm
5700K
IP65
159lm/W
70+
1.1 A
>0.9
IK10
4.44kg
7 Years
L - Brown
N - Blue
E - Green/Yellow
