Float level gauge LT5
5.5.3 Floating roof tank
Installation procedure
1. Pass the measuring wire through the sheave elbow on the tank roof from the 90° sheave
elbow on the gauge head, and feed one end of the measuring wire into the tank.
2. Temporarily secure the other end in place.
3. Connect the measuring wire to the float inside the tank.
4. Connect the measuring wire and the measuring tape again on the tank top, and feed the
measuring tape to the gauge head side.
5. Check to ensure that the measuring tape is not twisted.
6. Close the sheave elbow' s cover.
This completes the installation procedure.
