Summary of Contents for SLS Lab Pro
- Page 1 Operator Manual United Kingdom: Northern Ireland: slsinfo scientific-labs.com NI.sales scientific-labs.com International: Republic of Ireland: slsexport scientific-labs.com ROI.sales scientific-labs.com...
-
Page 3: Table Of Contents
Compliance with the Control of Noise at Work Regulations ........ 34 Service record ..................... 35 Notes ........................37 SLS Lab Pro ultrasonic baths are manufactured in the UK and conform to exacting international standards. SLS Lab Pro Digital Ultrasonic Baths... -
Page 4: Safety Instructions & General Use
Safety instructions & general use Safety Instructions The SLS Lab Pro digital ultrasonic baths are intended to be used to clean laboratory equipment. The SLS Lab Pro digital ultrasonic baths are designed for indoor use by a professional user. Electrical Connect to a 230 VAC fully earthed supply via a 3pin plug. -
Page 5: Installation
Installation The following parts and accessories are included with your SLS Lab Pro ultrasonic bath: 1x basket 1x lid 1x memory card 1x USB card reader 1x 2m length of drain hose 1x hose tail 1x power cable How to install? Screw the hose connector into the drain valve at the rear of the unit. -
Page 6: Controls
– Starts and ends the ultrasonic cycle KEY 2: Menu – Scroll through the menu KEY 3: Up/On – Adjust the settings in the options menu KEY 4: Down/Off – Adjust the settings in the options menu SLS Lab Pro Digital Ultrasonic Baths C6056801... -
Page 7: Quick Guide
Never use toxic, flammable, acidic, caustic, or corrosive solutions. Never breathe the fumes from strong solutions. Rinse the items in clean water once the cycle is complete. Subjecting the bath to improper treatment or misuse will invalidate the warranty. SLS Lab Pro Digital Ultrasonic Baths C6056801... -
Page 8: Operator Instructions
To immediately start the cycle using the already set cleaning parameters, press the key. Your SLS Lab Pro ultrasonic bath remembers the set parameters from the previous cycle. If the operator wants to run the same cleaning cycle, it is therefore not necessary to run through the menu each time. - Page 9 (The need for degassing is explained on page 25). You will need to degas the liquid to ensure good cleaning efficacy. By choosing YES, your SLS Lab Pro ultrasonic bath will run an automatic de-gas cycle. The following screen will display.
-
Page 10: Operator Menu
To scroll through the menu, press the MENU key. To exit the MENU at any time, press the 8 key. Your SLS Lab Pro ultrasonic bath remembers the set parameters from the previous cycle. If the operator wants to run the same cleaning cycle, it is therefore not necessary to run through the menu each time. - Page 11 Screen 1: Setting the temperature Your SLS Lab Pro ultrasonic bath is fitted with a thermostat and heaters to ensure the temperature of the cleaning liquid is maintained at the set temperature. Use the UP and DOWN keys to accurately set the desired temperature of the cleaning liquid between 5°C and 70°C.
- Page 12 Screen 2: Setting the cycle time Your SLS Lab Pro ultrasonic bath is factory pre-set with a cycle time of 15 minutes. Use this screen to amend the cycle time. Use the UP and DOWN keys to scroll through the numbers to increase or decrease the time of up to 99 minutes.
- Page 13 Use the ON and OFF keys to select the required option. (See page 25 for the importance of degassing.) If you turn the degas function ON, your SLS Lab Pro ultrasonic bath will run a degas cycle every time the cycle start key is depressed.
- Page 14 Screen 5: Frequency Leap Your SLS Lab Pro ultrasonic bath is equipped with Frequency LEAP technology to provide more homogeneous ultrasonic cleaning activity throughout the whole tank. Using advanced software and generators, the SLS Lab Pro ultrasonic bath uses Frequency LEAP to create a pseudo-random leaping action between a wider frequency range, reducing standing waves and improving the cleaning action.
-
Page 15: Starting The Cycle
Once all the Operator Menu options have been selected, the following screen will display. Your SLS Lab Pro ultrasonic bath is now ready for use. Press the 8 key to begin the cleaning cycle. When the bath is in operation, the following screen will display. -
Page 16: Cycle Abort Modes
The SLS Lab Pro ultrasonic bath will not operate again until the tank is filled to the correct level. If the power to the ultrasonic generator should fall below a certain level during operation, the cleaning cycle will stop, and the following screen will be displayed. -
Page 17: Cycle Abort Modes
If the unit overheats due to prolonged use, the following message will be displayed In each instance of a cycle abort, the cycle count in the Advanced Menu will still log the cycle as complete. SLS Lab Pro Digital Ultrasonic Baths C6056801... -
Page 18: Advanced Menu
You may exit the Advanced Menu at any time by pressing the 8 key. Screen 1: Serial Number The first screen shows the unique serial number of your SLS Lab Pro ultrasonic bath and the version of software. [The software version implemented on your bath may be different to that shown.]... - Page 19 5 hours, and 27 minutes. Screen 3: Clock Your SLS Lab Pro ultrasonic bath is fitted with a real time clock. This is factory set to the correct time and date but can be changed by the operator. To change the time and date, scroll through the settings by pressing the MENU key and amend by pressing the UP and DOWN keys.
- Page 20 Screen 5: Low power In its factory pre-set mode, the SLS Lab Pro ultrasonic bath will maintain the set liquid temperature. This means that it is consuming power when sitting idle (i.e., when the sonics are not running).
- Page 21 Screen 6: Liquid level sensor The SLS Lab Pro ultrasonic bath is fitted with a liquid level sensor to ensure it is not under-filled prior to or during the cycle. This ensures that the optimum cleaning process can occur and potential damage to the tank is minimised.
- Page 22 To continue using your SLS Lab Pro ultrasonic bath, refill with liquid up to the level sensor, switch the unit off and on again. If the bath is run dry this will invalidate the warranty on your SLS Lab Pro ultrasonic bath.
- Page 23 When the ON button is pressed, both the heater and the ultrasonic generator will turn on, irrespective of any other programmed settings. You will then be sure that the SLS Lab Pro ultrasonic bath is operating in the mode required for accurate portable appliance testing.
-
Page 24: Using The Memory Card
Using the memory card The SLS Lab Pro ultrasonic bath is fitted with a memory card slot which allows digital validation of every cleaning cycle. Simply insert a memory card into the slot located at the front of the unit to ensure that information on each cycle is saved. -
Page 25: Recording The Data
One available USB port To record the saved data: Always ensure the memory card is inserted into the SLS Lab Pro ultrasonic bath prior to turning the power on. The results of each cycle will be saved to the card until the card is removed. -
Page 26: Ultrasonic Cleaning Detergents
SLS2046 1250 Each of these detergents is available from SLS. The required detergent dose may vary depending on the component being cleaned and the level of contamination. We recommend a dosage of between 2 and 5% for all detergents other than Sonozyme. -
Page 27: Technical Information
Cleaning time Your SLS Lab Pro ultrasonic bath is factory preset with a cleaning time of 15 minutes. Some components may take longer or shorter to clean effectively depending on the contaminants and the level of contamination. -
Page 28: Specifications
Altitude above sea level Up to 2,000 m (6,500 ft) Operating Environment Indoor use only Tank External Tank Internal Basket Internal Dimensions (mm) Dimensions (mm) Dimensions (mm) SLS2030 SLS2038 SLS2040 SLS2042 SLS2044 SLS2046 SLS Lab Pro Digital Ultrasonic Baths C6056801... - Page 29 32 to 38kHz Heater range: 5 to 70 °C Working Tank Ultrasonic Total Power Heating capacity capacity power power (W) (litres) max. (litres) SLS2030 SLS2038 10.5 SLS2040 12.5 SLS2042 SLS2044 17.5 18.5 SLS2046 1050 SLS Lab Pro Digital Ultrasonic Baths C6056801...
-
Page 30: Troubleshooting And Problem Solving
Troubleshooting and Problem Solving SLS have dedicated After Sales teams who are able to resolve any problems that occur with your SLS Lab Pro digital ultrasonic baths. However, on many occasions it is possible that the problem can be rectified by the operator. - Page 31 If we are unable to solve your problem over the phone, we may suggest returning your product to SLS. Where appropriate, we operate a Return To Base (RTB) warranty and repairs policy. SLS Lab Pro Digital Ultrasonic Baths...
-
Page 32: Returning Equipment
More information on decontamination guidelines, as well as copies of decontamination certificates can be found at www.ultrawave.co.uk. If you require further information, please contact the SLS After Sales Department by emailing slsaftersales@Scientific-labs.com or calling +44(0)115 982 1111. -
Page 33: Maintenance
Portable Appliance Testing should be conducted with water in the bath. Service We recommend that your SLS Lab Pro ultrasonic bath is serviced and tested by an approved engineer on an annual basis. More regular periodic testing can be done by the operator to ensure that your ultrasonic bath is operating at optimum efficiency. -
Page 34: Warranty
Warranty The warranty on SLS Lab Pro ultrasonic bath s applies to defects appearing within 36 months of the date of sale, or 6000 hours usage (whichever comes first) because of faulty material or manufacture. Genuine defective items returned to SLS will be replaced or repaired free of charge at discretion. -
Page 35: Weee Compliance
WEEE Compliance SLS are complying with the WEEE regulations by contracting-our obligations to a Producer Compliance scheme. Once it is deemed that this Q-Series model is no longer effective, please contact SLS to arrange collection by our compliance scheme provider, who will pick up the machine from your premises. -
Page 36: Compliance With The Control Of Noise At Work Regulations
Guidance on the 2005 Regulations can be found in the free HSE leaflet 'Noise at Work'(INDG362 (rev 2) and in HSE's priced book 'Controlling Noise at Work' (L108) (ISBN 0 7176 6164 4) available from HSE Books or from bookshops. http://www.hse.gov.uk/noise/regulations.htm http://www.opsi.gov.uk/si/si2005/20051643.htm https://www.legislation.gov.uk/uksi/1989/1790/contents/made https://www.hse.gov.uk/pubns/indg362.pdf https://books.hse.gov.uk SLS Lab Pro Digital Ultrasonic Baths C6056801... -
Page 37: Service Record
Service record We recommend that your SLS Lab Pro ultrasonic bath is serviced at least once every 12 months. This record must be maintained by the engineer conducting the service. There are no user serviceable parts inside. All service and repair should be referred to qualified engineers only. - Page 38 Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due SLS Lab Pro Digital Ultrasonic Baths C6056801...
-
Page 39: Notes
Notes ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ SLS Lab Pro Digital Ultrasonic Baths C6056801... - Page 41 Tel: +44(0) 115 982 1111 slsinfo@scientific-labs.com www.scientificlabs.co.uk Northern Ireland Tel: +44(0) 28 9262 1100 NI.sales@scientific-labs.com www.scientificlabs.co.uk Republic of Ireland Tel: +353(0) 1 4069464 ROI.sales@scientific-labs.com www.scientificlabs.ie International Tel: +44(0) 115 977 5060 slsexport@scientific-labs.com www.scientificlabs.com United Kingdom: Northern Ireland: slsinfo scientific-labs.com NI.sales scientific-labs.com International: Republic of Ireland: slsexport scientific-labs.com...
