    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 1 General The BAS-0808 is an 8x8 analog stereo audio router with balanced in- and outputs. This state of the art router provides high performance circuits in SMD technology for maximum system performance. The BAS-0808 is designed for all demanding routing tasks in digital studio and broadcast environments.
  • Page 10: Power Connection

    BAS-0808 can also be delivered with DC ±15V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information.
  • Page 11: Ncb Connection

    Triton devices, with RJ45 connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router.
  • Page 12: Pin-Out And Cable Type

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data...
  • Page 13: Rj45 To 5-Pin Din Converter

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45.
  • Page 14 All manuals and user guides at all-guides.com BAS-0808 Rev. 2 o Universal Control Panel to control all devices above, with user configurable default level. Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. •...
  • Page 15: Router Configuration

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 5 Router configuration Router level Switch 1 - 4 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router.
  • Page 16: Router Mode

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 Router mode The BAS-0808 router allows switching in different modes. You can choose among: Balanced Stereo Balanced 2 Channel Stereo Balanced 4 Channel Stereo Switch 5 - 6 on the configuration switch set the router’s mode. The Triton Router Control System software must be configured according to the mode chosen on the router.
  • Page 17: Power Up Mode

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 Ch2 Signal Input Ch2 Signal Output Balanced 4 Channel Stereo Ch1 Signal Input Ch1 Signal Output Ch2 Signal Input Ch2 Signal Output Ch3 Signal Input Ch3 Signal Output Ch4 Signal Input Ch4 Signal Output...
  • Page 18: Connecting Audio Signals To The Bas-0808

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 6 Connecting audio signals to the BAS-0808 Below you will find our standard pin-out for DB25 audio contacts. This pin-out is used for both analog and digital audio routers. The same standard is used by Tascam and Fostex. Channel 1 + 24 - 12...
  • Page 19: Control And Connection Of Triton Systems, Interface Protocol

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 7 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 7.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters.
  • Page 20: Example: Several Units Connected By Ncb

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 7.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB.
  • Page 21: Commands

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 Commands 7.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled.
  • Page 22: Video Crosspoint Set Acknowledge

    All manuals and user guides at all-guides.com BAS-0808 Rev. 2 7.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled.
