Installation - Magic Chef MC110AMST User Manual

COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as dents or broken
door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the
light brown Mica cover that is attached to the oven cavity to protect the magnetron.

INSTALLATION

7. Select a level surface that provide enough open space for the intake and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls.
One side must be open. The minimum installation height is 3.0ft (91.6cm).
1. Leave a minimum clearance of 12 inches (30cm) above the oven.
2. Do not remove the legs from the bottom of the oven.
3. Blocking the intake and/or outlet openings can damage the oven.
4. Place the oven as far away from radios and TV as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
8. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same
as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near
or over a heat source, the oven could be damaged and the warranty would be void.
WARNING:
Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a
heat source, the oven could be damaged and the warranty would be void.
The accessible surface may be hot during operation.
EN-11
