5 INTERFACES

POS80K supports serial, Ethernet, cash drawer and USB interfaces.

5.1 USB

5.2 Cash Drawer Interface

Electrical characteristics
Driving voltage：DC 24V
⚫
Driving current：Maximum 0.8 A ( In 510 ms)
⚫
Detection signal for drawer status ： "L" = 0 ～ 0.5 V
Figure 5-1
PIN NO. SIGNAL NAME
1 VBUS
2
3
4
Figure 5-2
PIN NO. SIGNAL NAME
1
2 Drawer 1
3 DRSW
4
5 Drawer 2
6
22
D-
D+
GND
FG
VDR
GND
POS80K User Manual
"H" = 3 ～ 5 V
