TSR Electric Storage Heaters
Assembly Instruction
Model Nos: 79341S
Cat. Nos:
TSR12AW
This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3.
These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
© GDC Group Ltd. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing.
A division of the GDC Group Ltd, Millbrook House, Grange Drive, Hedge End, Southampton SO30 2DF
Automatic
79351S
79361S
TSR18AW
TSR24AW
Manual
79344/6S
79354/6S 79364/6S
TSR12MW
TSR18MW TSR24MW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Newera TSR12AW and is the answer not in the manual?

Questions and answers

Summary of Contents for Creda Newera TSR12AW

  • Page 1 TSR Electric Storage Heaters Assembly Instruction Automatic Manual Model Nos: 79341S 79351S 79361S 79344/6S 79354/6S 79364/6S Cat. Nos: TSR12AW TSR18AW TSR24AW TSR12MW TSR18MW TSR24MW This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC ©...
  • Page 2 IMPORTANT PLEASE READ THIS LEAFLET CAREFULLY AND RETAIN FOR FURTHER USE NOTE ALSO THE INFORMATION GIVEN ON THE HEATER • The Installation must be carried out by trained personnel. • A means for disconnection must be incorporated in the fixed wiring by a double pole switch with a contact separation of a minimum of 3mm and in accordance with the current IEE Wiring Regulations.
  • Page 3 RAWLPLUG ‘RAWLOK R6054R’. Some authorities suggest UNIFIX LB 70/10mm. PLEASE DON’T TAKE CHANCES Site conditions may vary considerably and Creda cannot recommend the correct wall fixings to be used. It is the responsibility of the installer to ensure that adequate permanent fixing has been achieved.
  • Page 4 First, turn carton upside down Open bottom flaps on carton Packing corner fitments contain heater feet It is preferable to fit the heater feet whilst the heater is still in its carton. Turn the carton upside down and open the bottom flaps. The corner fitments contain both feet and the fixing kit.
  • Page 5 WALL FIXINGS - VERY IMPORTANT When bracket is securely fixed, replace You must fit a the heater under the bracket angle retaining screw at and align screw holes on heaters each end of the ends. There are two fixing slots at each end of heater.
  • Page 6 MAINS TERMINALS IMPORTANT: for earthing, loosen the earth screw sufficiently to wrap the mains’ earth wire around it between flat washer and cup washer, and retighten the earthing screw. Feed the mains cable through the cable clamp and make ENSURE THAT CABLE CLAMP connections as marked on the heater.
  • Page 7 Temporarily remove one central element to provide access for the rear rank of bricks. Loosen terminals on one of the elements and remove this to allow installation of rear rank of storage bricks. On heaters with 3 or 4 elements remove one of the central ones. Note the way the bricks are positioned in the heater.
  • Page 8 Check that the front insulation slab is properly attached to the inner front panel and refit panel (insulation innermost) to the heater by locating its bottom edge behind the front lip of the chassis, and inserting retaining screws along the top and both sides. With the bricks pushed well back, as mentioned earlier, and the insulation properly aligned, there should be no bulging of this panel and no undue force necessary to fix it.
